webrtc源码分析

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
bool MainWnd::PreTranslateMessage(MSG* msg) {
  bool ret = false;
  if (msg->message == WM_CHAR) {
    if (msg->wParam == VK_TAB) {
      HandleTabbing();
      ret = true;
    } else if (msg->wParam == VK_RETURN) {
      OnDefaultAction();
      ret = true;
    } else if (msg->wParam == VK_ESCAPE) {
      if (callback_) {
        if (ui_ == STREAMING) {
          callback_->DisconnectFromCurrentPeer();
        } else {
          callback_->DisconnectFromServer();
        }
      }
    }
  } else if (msg->hwnd == NULL && msg->message == UI_THREAD_CALLBACK) {
  //通过此函数把SDP，ICE等信息发送到服务器
    callback_->UIThreadCallback(static_cast<int>(msg->wParam),
                                reinterpret_cast<void*>(msg->lParam));

    ret = true;
  }
  return ret;
}

1
2
3
4
5
6
7
8
9
10
LRESULT CALLBACK MainWnd::WndProc(HWND hwnd, UINT msg, WPARAM wp, LPARAM lp) {
   OnMessage//点击UI界面分发的消息主要通过此函数处理。
   //bool MainWnd::OnMessage(UINT msg, WPARAM wp, LPARAM lp, LRESULT* result)，实现包括连接peer功能。
}


LRESULT Win32Window::WndProc(HWND hwnd, UINT uMsg,
                             WPARAM wParam, LPARAM lParam) {
     OnMessage//收到服务器的消息通过此函数处理，并调用OnSocketNotify处理消息。
  }

1
2
3
4
5
  if (ui_ == STREAMING && remote_renderer && local_renderer) {
    AutoLock<VideoRenderer> local_lock(local_renderer);
    AutoLock<VideoRenderer> remote_lock(remote_renderer);
    ......
    }

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
bool MainWnd::OnMessage(UINT msg, WPARAM wp, LPARAM lp, LRESULT* result) {
  switch (msg) {
    case WM_ERASEBKGND:
      *result = TRUE;
      return true;

    case WM_PAINT:
      OnPaint();
      return true;

    case WM_SETFOCUS:
      if (ui_ == CONNECT_TO_SERVER) {
        SetFocus(edit1_);
      } else if (ui_ == LIST_PEERS) {
        SetFocus(listbox_);
      }
      return true;

    case WM_SIZE:
      if (ui_ == CONNECT_TO_SERVER) {
        LayoutConnectUI(true);
      } else if (ui_ == LIST_PEERS) {
        LayoutPeerListUI(true);
      }
      break;

    case WM_CTLCOLORSTATIC:
      *result = reinterpret_cast<LRESULT>(GetSysColorBrush(COLOR_WINDOW));
      return true;

    case WM_COMMAND:
      if (button_ == reinterpret_cast<HWND>(lp)) {
        if (BN_CLICKED == HIWORD(wp))
          OnDefaultAction();
      } else if (listbox_ == reinterpret_cast<HWND>(lp)) {
        if (LBN_DBLCLK == HIWORD(wp)) {
          OnDefaultAction();
        }
      }
      return true;

    case WM_CLOSE:
      if (callback_)
        callback_->Close();
      break;
  }
  return false;
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
  if (ui_ == CONNECT_TO_SERVER) {
    std::string server(GetWindowText(edit1_));
    std::string port_str(GetWindowText(edit2_));
    int port = port_str.length() ? atoi(port_str.c_str()) : 0;
    callback_->StartLogin(server, port);
  } else if (ui_ == LIST_PEERS) {
    LRESULT sel = ::SendMessage(listbox_, LB_GETCURSEL, 0, 0);
    if (sel != LB_ERR) {
      LRESULT peer_id = ::SendMessage(listbox_, LB_GETITEMDATA, sel, 0);
      if (peer_id != -1 && callback_) {
        callback_->ConnectToPeer(peer_id);
      }
    }
  } else {
    MessageBoxA(wnd_, "OK!", "Yeah", MB_OK);
  }

1
2
3
4
5
 if (ParseEntry(control_data_.substr(pos, eol - pos), &name, &id,
                &connected) && id != my_id_) {
   peers_[id] = name;
   callback_->OnPeerConnected(id, name);
   }

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
void Conductor::UIThreadCallback(int msg_id, void* data)
{
 case SEND_MESSAGE_TO_PEER: {//SEND_MESSAGE_TO_PEER 表示把当前的信息发送给服务器
      LOG(INFO) << "SEND_MESSAGE_TO_PEER";
      std::string* msg = reinterpret_cast<std::string*>(data);//SDP信息
        if (!client_->SendToPeer(peer_id_, *msg) && peer_id_ != -1) {
          LOG(LS_ERROR) << "SendToPeer failed";
          DisconnectFromServer();
        }
}
 case NEW_STREAM_ADDED: {//当建立p2p连接时，收到远程流，并且用于显示
   webrtc::MediaStreamInterface* stream =
       reinterpret_cast<webrtc::MediaStreamInterface*>(
       data);
   webrtc::VideoTrackVector tracks = stream->GetVideoTracks();
   // Only render the first track.
   if (!tracks.empty()) {
     webrtc::VideoTrackInterface* track = tracks[0];
     main_wnd_->StartRemoteRenderer(track);
   }
   stream->Release();
   break;
 }
 }

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
void Win32Socket::OnSocketNotify(SOCKET socket, int event, int error) {
    case FD_READ:
      if (error != ERROR_SUCCESS) {
        ReportWSAError("WSAAsync:read notify", error, addr_);
      } else {
        SignalReadEvent(this);
      }
      break;

    case FD_WRITE:
      if (error != ERROR_SUCCESS) {
        ReportWSAError("WSAAsync:write notify", error, addr_);
      } else {
        SignalWriteEvent(this);
      }
      break;
}
