Spring Cloud Gateway 扩展支持动态限流

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
spring:
  cloud:
    gateway:
      routes:
      - id: requestratelimiter_route
        uri: lb://pigx-upms
        order: 10000
        predicates:
        - Path=/admin/**
        filters:
        - name: RequestRateLimiter
          args:
            redis-rate-limiter.replenishRate: 1
            redis-rate-limiter.burstCapacity: 3
            key-resolver: "#{@remoteAddrKeyResolver}" #SPEL表达式去的对应的bean
        - StripPrefix=1

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
public GatewayFilter apply(Config config) {
	KeyResolver resolver = getOrDefault(config.keyResolver, defaultKeyResolver);
	RateLimiter<Object> limiter = getOrDefault(config.rateLimiter,
			defaultRateLimiter);
	boolean denyEmpty = getOrDefault(config.denyEmptyKey, this.denyEmptyKey);
	HttpStatusHolder emptyKeyStatus = HttpStatusHolder
			.parse(getOrDefault(config.emptyKeyStatus, this.emptyKeyStatusCode));

	return (exchange, chain) -> {
				return exchange.getResponse().setComplete();
			});
		});
	};
}

1
2
3
4
5
6
7
8
9
10
11
12
<!--Spring Cloud Alibaba 封装的 sentinel 模块-->
<dependency>
    <groupId>com.alibaba.cloud</groupId>
    <artifactId>spring-cloud-alibaba-sentinel-gateway</artifactId>
</dependency>

<!--使用nacos 保存限流规则-->
<dependency>
    <groupId>com.alibaba.csp</groupId>
    <artifactId>sentinel-datasource-nacos</artifactId>
</dependency>

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
spring:
  application:
    name: sentinel-spring-cloud-gateway
  cloud:
    gateway:
      enabled: true
      discovery:
        locator:
          lower-case-service-id: true
      routes:
      - id: pigx_route
        uri: https://api.readhub.cn
        predicates:
        - Path=/topic/**
    sentinel:
      datasource.ds1.nacos:
        server-addr: 127.0.0.1:8848
        data-id: gw-flow
        group-id: DEFAULT_GROUP
        ruleType: gw-api-group
      filter:
        enabled: true

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
public Mono<Void> filter(ServerWebExchange exchange, GatewayFilterChain chain) {
    Route route = exchange.getAttribute(ServerWebExchangeUtils.GATEWAY_ROUTE_ATTR);

    Mono<Void> asyncResult = chain.filter(exchange);
    if (route != null) {
        String routeId = route.getId();
        Object[] params = paramParser.parseParameterFor(routeId, exchange,
            r -> r.getResourceMode() == SentinelGatewayConstants.RESOURCE_MODE_ROUTE_ID);
        String origin = Optional.ofNullable(GatewayCallbackManager.getRequestOriginParser())
            .map(f -> f.apply(exchange))
            .orElse("");
        asyncResult = asyncResult.transform(
            new SentinelReactorTransformer<>(new EntryConfig(routeId, EntryType.IN,
                1, params, new ContextConfig(contextName(routeId), origin)))
        );
    }

    Set<String> matchingApis = pickMatchingApiDefinitions(exchange);
    for (String apiName : matchingApis) {
        Object[] params = paramParser.parseParameterFor(apiName, exchange,
            r -> r.getResourceMode() == SentinelGatewayConstants.RESOURCE_MODE_CUSTOM_API_NAME);
        asyncResult = asyncResult.transform(
            new SentinelReactorTransformer<>(new EntryConfig(apiName, EntryType.IN, 1, params))
        );
    }

    return asyncResult;
}
