#include <windows.h>
#include <stdio.h>
#include <GL/freeglut.h>

int main(int argc, char** argv)
{
	glutInit(&argc, argv);
	glutInitDisplayMode(GLUT_SINGLE | GLUT_RGB | GLUT_DEPTH);
	glutInitWindowSize(300, 300);
	glutInitWindowPosition(100, 100);
	glutCreateWindow("OpenGL Version");
	const GLubyte* szVendor = glGetString(GL_VENDOR);
	const GLubyte* szRender = glGetString(GL_RENDERER);
	const GLubyte* szGLVersion = glGetString(GL_VERSION);
	const GLubyte* szGluVersion = gluGetString(GLU_VERSION);
	printf("OpenGL实现厂商的名字：%sn", szVendor);
	printf("渲染器标识符：%sn", szRender);
	printf("OpenGL实现的版本号：%sn", szGLVersion);
	printf("GLU工具库版本：%sn", szGluVersion);

	system("pause");

	return 0;
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
#include <GL/freeglut.h>

void renderScene(void)
{
    glClear(GL_COLOR_BUFFER_BIT | GL_DEPTH_BUFFER_BIT);
    glLoadIdentity();
    glBegin(GL_TRIANGLES);
    glVertex3f(-0.5, -0.5, 0.0);
    glVertex3f(0.5, 0.0, 0.0);
    glVertex3f(0.0, 0.5, 0.0);
    glEnd();
    glutSwapBuffers();
}

int main(int argc, char** argv)
{
    glutInit(&argc, (char**)argv);
    glutInitDisplayMode(GLUT_DEPTH | GLUT_DOUBLE | GLUT_RGBA);
    glutInitWindowPosition(100, 100);
    glutInitWindowSize(800, 480);
    glutCreateWindow("第一个glut程序");
    glutDisplayFunc(renderScene);

    glutMainLoop();
    return 0;
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
#include <stdio.h>
#include <GL/glew.h>
#include <GL/freeglut.h>

GLuint VBO;

static void RenderSceneCB()
{
    glClear(GL_COLOR_BUFFER_BIT);

    glEnableVertexAttribArray(0);
    glBindBuffer(GL_ARRAY_BUFFER, VBO);
    glVertexAttribPointer(0, 3, GL_FLOAT, GL_FALSE, 0, 0);

    glDrawArrays(GL_TRIANGLES, 0, 3);

    glDisableVertexAttribArray(0);

    glutSwapBuffers();
}

static void InitializeGlutCallbacks()
{
    glutDisplayFunc(RenderSceneCB);
}

static void CreateVertexBuffer()
{
    Vector3f Vertices[3];
    Vertices[0] = Vector3f(-1.0f, -1.0f, 0.0f);
    Vertices[1] = Vector3f(1.0f, -1.0f, 0.0f);
    Vertices[2] = Vector3f(0.0f, 1.0f, 0.0f);

 	glGenBuffers(1, &VBO);
	glBindBuffer(GL_ARRAY_BUFFER, VBO);
	glBufferData(GL_ARRAY_BUFFER, sizeof(Vertices), Vertices, GL_STATIC_DRAW);
}

int main(int argc, char** argv)
{
    glutInit(&argc, argv);
    glutInitDisplayMode(GLUT_DOUBLE|GLUT_RGBA);
    glutInitWindowSize(1024, 768);
    glutInitWindowPosition(100, 100);
    glutCreateWindow("glut + VBO + triangle ");

    InitializeGlutCallbacks();

    // Must be done after glut is initialized!
    GLenum res = glewInit();
    if (res != GLEW_OK) {
      fprintf(stderr, "Error: '%s'n", glewGetErrorString(res));
      return 1;
    }

    glClearColor(0.0f, 0.0f, 0.0f, 0.0f);

    CreateVertexBuffer();

    glutMainLoop();

    return 0;
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
//使用VAO VBO绘制矩形
#include <GL/glew.h>
#include <GL/freeglut.h>

GLuint vboId;//vertex buffer object句柄
GLuint vaoId;//vertext array object句柄

//自定义初始化函数
void myInit()
{
	glClearColor(0.0, 0.0, 0.0, 0.0);
	//创建顶点数据
	const GLfloat vertices[] = {
		-0.5f,-0.5f,0.0f,1.0f,
		0.5f,-0.5f,0.0f,1.0f,
		0.5f,0.5f,0.0f,1.0f,
		-0.5f,0.5f,0.0f,1.0f,
	};

	//创建VAO对象
	glGenVertexArrays(1, &vaoId);
	glBindVertexArray(vaoId);

	//创建VBO对象
	glGenBuffers(1, &vboId);
	glBindBuffer(GL_ARRAY_BUFFER, vboId);
	//传入VBO数据
	glBufferData(GL_ARRAY_BUFFER, sizeof(vertices), vertices, GL_STATIC_DRAW);
	//解除VBO绑定
	glBindBuffer(GL_ARRAY_BUFFER, 0);
}

//调整窗口大小回调函数
void reshape(int w, int h)
{
	glViewport(0, 0, (GLsizei)w, (GLsizei)h);
}

//绘制回调函数
void display(void)
{
	glClear(GL_COLOR_BUFFER_BIT);

	//绑定VBO
	glBindBuffer(GL_ARRAY_BUFFER, vboId);
	glEnableVertexAttribArray(0);

	//解释顶点数据方式
	glVertexAttribPointer(0, 4, GL_FLOAT, GL_FALSE, 0, 0);

	//绘制模型
	glDrawArrays(GL_TRIANGLE_FAN, 0, 4);

	glBindBuffer(GL_ARRAY_BUFFER, 0);
	glDisableVertexAttribArray(0);

	glutSwapBuffers();
}

int main(int argc, char **argv)
{
	glutInit(&argc, argv);
	glutInitDisplayMode(GLUT_RGBA | GLUT_DOUBLE);
	glutInitWindowPosition(100, 100);
	glutInitWindowSize(512, 512);
	glutCreateWindow("Rectangle demo");

    //初始化一个GLEW库,确保OpenGL API对程序完全可用。
	GLenum err = glewInit();
    if (GLEW_OK != err)
    {
       /* Problem: glewInit failed, something is seriously wrong. */
       fprintf(stderr, "Error: %sn", glewGetErrorString(err));
       return;
    }

	//自定义初始化，生成VAO，VBO对象
	myInit();

	//设置回调函数
	glutReshapeFunc(reshape);
	glutDisplayFunc(display);
	glutMainLoop();
	return 0;
}


1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
#include <iostream>
#include <GL/glew.h>
#include <GL/freeglut.h>

void display()
{
	glClear(GL_COLOR_BUFFER_BIT | GL_DEPTH_BUFFER_BIT);

	glDrawArrays(666, 666, 666);

	glutSwapBuffers();
}

void keyboard(unsigned char key, int, int)
{
	if (key == 27) exit(EXIT_SUCCESS);
}

void GLAPIENTRY debug(GLenum source, GLenum type, GLuint id, GLenum severity, GLsizei length, const GLchar* message, const void* userParam)
{
	std::cout << std::hex
	          << "source:0x" << source << std::endl
	          << "type:0x" << type << std::endl
	          << "id:0x" << id << std::endl
	          << "severity:0x" << severity << std::endl
	          << "length:" << length << std::endl
	          << "message:" << message << std::endl
	          << "userParam:" << userParam << std::endl
	          << std::dec;
}

int main(int argc, char* argv[])
{
	glutInit(&argc, argv);
	glutInitContextFlags(GLUT_FORWARD_COMPATIBLE | GLUT_DEBUG);
	glutInitContextProfile(GLUT_COMPATIBILITY_PROFILE);
	glutInitContextVersion(3, 3);

	glutInitDisplayMode(GLUT_DOUBLE | GLUT_RGBA | GLUT_DEPTH);
	glutCreateWindow("");
	glutDisplayFunc(display);
	glutKeyboardFunc(keyboard);

	glewInit();

	glDebugMessageCallback(debug, nullptr);

	glutMainLoop();
	return 0;
}
