matlab color设置

127 阅读 0 评论 84 点赞

我是靠谱客的博主清脆棒球，这篇文章主要介绍matlab color设置，现在分享给大家，希望可以做个参考。

复制代码

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
% colormap_plot
% author: CHF
% date: 2021.04.11
% colormap_plot

clc;
clear all;
close all;

max_color_value = 100;

% jet_color = colormap(hsv(max_color_value));
% jet_color = colormap(cool(max_color_value));
% jet_color = colormap(hot(max_color_value));
% jet_color = colormap(pink(max_color_value));
% jet_color = colormap(gray(max_color_value));
% jet_color = colormap(pink(max_color_value));
% jet_color = colormap(bone(max_color_value));
jet_color = colormap(jet(max_color_value));
% jet_color = colormap(copper(max_color_value));
% jet_color = colormap(prim(max_color_value));
% jet_color = colormap(flag(max_color_value));

x = linspace(0,6*pi,1000);

y = sin(x);

color_index = ceil(y*50 + 50);

for i = 1:1:length(y),

    selected_color = jet_color(color_index(i),:);

    plot(x(i), y(i), 'o','color',selected_color);

    hold on;
end
colorbar;
