1.hadoop系列之docker-compose部署

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
version: "3"

services:
  namenode:
    image: bde2020/hadoop-namenode:2.0.0-hadoop3.2.1-java8
    container_name: namenode
    restart: always
    ports:
      - 9870:9870
      - 9000:9000
    volumes:
      - hadoop_namenode:/hadoop/dfs/name
    environment:
      - CLUSTER_NAME=test
    env_file:
      - ./hadoop.env

  datanode:
    image: bde2020/hadoop-datanode:2.0.0-hadoop3.2.1-java8
    container_name: datanode
    restart: always
    volumes:
      - hadoop_datanode:/hadoop/dfs/data
    environment:
      SERVICE_PRECONDITION: "namenode:9870"
    env_file:
      - ./hadoop.env

  resourcemanager:
    image: bde2020/hadoop-resourcemanager:2.0.0-hadoop3.2.1-java8
    container_name: resourcemanager
    restart: always
    ports:
      - 8088:8088
    environment:
      SERVICE_PRECONDITION: "namenode:9000 namenode:9870 datanode:9864"
    env_file:
      - ./hadoop.env

  nodemanager:
    image: bde2020/hadoop-nodemanager:2.0.0-hadoop3.2.1-java8
    container_name: nodemanager
    restart: always
    environment:
      SERVICE_PRECONDITION: "namenode:9000 namenode:9870 datanode:9864 resourcemanager:8088"
    env_file:
      - ./hadoop.env

  historyserver:
    image: bde2020/hadoop-historyserver:2.0.0-hadoop3.2.1-java8
    container_name: historyserver
    restart: always
    environment:
      SERVICE_PRECONDITION: "namenode:9000 namenode:9870 datanode:9864 resourcemanager:8088"
    volumes:
      - hadoop_historyserver:/hadoop/yarn/timeline
    env_file:
      - ./hadoop.env

volumes:
  hadoop_namenode:
  hadoop_datanode:
  hadoop_historyserver:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
CORE_CONF_fs_defaultFS=hdfs://namenode:9000
CORE_CONF_hadoop_http_staticuser_user=root
CORE_CONF_hadoop_proxyuser_hue_hosts=*
CORE_CONF_hadoop_proxyuser_hue_groups=*
CORE_CONF_io_compression_codecs=org.apache.hadoop.io.compress.SnappyCodec

HDFS_CONF_dfs_webhdfs_enabled=true
HDFS_CONF_dfs_permissions_enabled=false
HDFS_CONF_dfs_namenode_datanode_registration_ip___hostname___check=false

YARN_CONF_yarn_log___aggregation___enable=true
YARN_CONF_yarn_log_server_url=http://historyserver:8188/applicationhistory/logs/
YARN_CONF_yarn_resourcemanager_recovery_enabled=true
YARN_CONF_yarn_resourcemanager_store_class=org.apache.hadoop.yarn.server.resourcemanager.recovery.FileSystemRMStateStore
YARN_CONF_yarn_resourcemanager_scheduler_class=org.apache.hadoop.yarn.server.resourcemanager.scheduler.capacity.CapacityScheduler
YARN_CONF_yarn_scheduler_capacity_root_default_maximum___allocation___mb=8192
YARN_CONF_yarn_scheduler_capacity_root_default_maximum___allocation___vcores=4
YARN_CONF_yarn_resourcemanager_fs_state___store_uri=/rmstate
YARN_CONF_yarn_resourcemanager_system___metrics___publisher_enabled=true
YARN_CONF_yarn_resourcemanager_hostname=resourcemanager
YARN_CONF_yarn_resourcemanager_address=resourcemanager:8032
YARN_CONF_yarn_resourcemanager_scheduler_address=resourcemanager:8030
YARN_CONF_yarn_resourcemanager_resource__tracker_address=resourcemanager:8031
YARN_CONF_yarn_timeline___service_enabled=true
YARN_CONF_yarn_timeline___service_generic___application___history_enabled=true
YARN_CONF_yarn_timeline___service_hostname=historyserver
YARN_CONF_mapreduce_map_output_compress=true
YARN_CONF_mapred_map_output_compress_codec=org.apache.hadoop.io.compress.SnappyCodec
YARN_CONF_yarn_nodemanager_resource_memory___mb=16384
YARN_CONF_yarn_nodemanager_resource_cpu___vcores=8
YARN_CONF_yarn_nodemanager_disk___health___checker_max___disk___utilization___per___disk___percentage=98.5
YARN_CONF_yarn_nodemanager_remote___app___log___dir=/app-logs
YARN_CONF_yarn_nodemanager_aux___services=mapreduce_shuffle

MAPRED_CONF_mapreduce_framework_name=yarn
MAPRED_CONF_mapred_child_java_opts=-Xmx2048m
MAPRED_CONF_mapreduce_map_memory_mb=2048
MAPRED_CONF_mapreduce_reduce_memory_mb=4096
MAPRED_CONF_mapreduce_map_java_opts=-Xmx3072m
MAPRED_CONF_mapreduce_reduce_java_opts=-Xmx4096m
MAPRED_CONF_yarn_app_mapreduce_am_env=HADOOP_MAPRED_HOME=/opt/hadoop-3.2.1/
MAPRED_CONF_mapreduce_map_env=HADOOP_MAPRED_HOME=/opt/hadoop-3.2.1/
MAPRED_CONF_mapreduce_reduce_env=HADOOP_MAPRED_HOME=/opt/hadoop-3.2.1/

1
2
docker-compose up -d
