MVVM+DataBinding+RxJava+Retofit实现一个简单的新闻demo

1
2
3
4
 dataBinding {
            enabled true
        }

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
 //ViewModel与LiveData
    implementation "android.arch.lifecycle:extensions:1.1.1"

    // 依赖RxAndroid 2X 的依赖库
    // 增加RxJava 2X 的依赖库
    implementation 'io.reactivex.rxjava2:rxandroid:2.1.1'
    implementation 'io.reactivex.rxjava2:rxjava:2.2.9'

    // Retrofit库
    implementation 'com.squareup.retrofit2:retrofit:2.0.2'

    // Okhttp库
    implementation 'com.squareup.okhttp3:okhttp:3.1.2'

    //Gson依赖
    implementation 'com.squareup.retrofit2:converter-gson:2.0.2'

    //图片加载
    implementation 'com.github.bumptech.glide:glide:4.11.0'

1
2
 <uses-permission android:name="android.permission.INTERNET"/>

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
public class MainActivity extends AppCompatActivity {

    private ActivityMainBinding binding;

    private MainViewModel viewModel;

    private NewsRecyclerAdapter adapter;

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        binding = DataBindingUtil.setContentView(this,R.layout.activity_main);
        init();
        initData();
    }

    //调整每个item之间的距离
    class SpaceItemDecoration extends RecyclerView.ItemDecoration {
        int mSpace;

        @Override
        public void getItemOffsets(@NonNull Rect outRect, @NonNull View view, @NonNull RecyclerView parent, @NonNull RecyclerView.State state) {
            super.getItemOffsets(outRect, view, parent, state);
            outRect.bottom = mSpace;
            if (parent.getChildAdapterPosition(view) == 0) {
                outRect.top = mSpace;
            }
        }

        public SpaceItemDecoration(int space) {
            this.mSpace = space;
        }
    }

    private void init() {
        //初始化ViewModel
        viewModel = ViewModelProviders.of(this).get(MainViewModel.class);
        viewModel.request();
        Log.i("sjh","我是你爸爸");
    }

    private void initData() {
        binding.setModel(viewModel);
        //数据请求
        viewModel.getNewsList().observe(this, new Observer<List<News.NewslistBean>>() {
            @Override
            public void onChanged(List<News.NewslistBean> newslistBeans) {
                LinearLayoutManager linearLayoutManager = new LinearLayoutManager(binding.getRoot().getContext());
                binding.recyclerView.setLayoutManager(linearLayoutManager);
                adapter = new NewsRecyclerAdapter(binding.getRoot().getContext());
                binding.recyclerView.addItemDecoration(new SpaceItemDecoration(5));
                binding.recyclerView.setAdapter(adapter);
                adapter.addAll(newslistBeans);
            }
        });
    }
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
public class MainViewModel extends ViewModel {

    //当数据请求成功回调
    protected MutableLiveData<List<News.NewslistBean>> newsList=new MutableLiveData<>();

    public void request() {

        //RxJava切换线程
        Observable.create(new ObservableOnSubscribe<News>() {
            @Override
            public void subscribe(@NonNull final ObservableEmitter<News> emitter) throws Exception {
                // Retrofit进行网络请求
                Retrofit retrofit = new Retrofit.Builder()
                        .baseUrl("http://api.tianapi.com/")
                        .addConverterFactory(GsonConverterFactory.create())
                        .build();

                GetRequest_Interface request = retrofit.create(GetRequest_Interface.class);

                Call<News> call = request.getCall();

                call.enqueue(new Callback<News>() {
                    @Override
                    public void onResponse(Call<News> call, Response<News> response) {
                        News news = response.body();
                        emitter.onNext(news); //将news通过发射器发送给Observer
                    }

                    @Override
                    public void onFailure(Call<News> call, Throwable t) {
                        System.out.println("连接失败");
                        System.out.println(t.getMessage());
                    }
                });
            }
        })
        .subscribeOn(Schedulers.io())  // 为上面代码分配io线程
        .observeOn(AndroidSchedulers.mainThread())   // 为下面代码分配主线程
        .subscribe(new Observer<News>() {
            @Override
            public void onSubscribe(@NonNull Disposable d) {

            }

            @Override
            public void onNext(@NonNull News news) {
                if (news != null) {
                    newsList.postValue(news.getNewslist());
                }
            }

            @Override
            public void onError(@NonNull Throwable e) {

            }

            @Override
            public void onComplete() {

            }
        });
    }

    public MutableLiveData<List<News.NewslistBean>> getNewsList() {
        return newsList;
    }
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
public class NewsRecyclerAdapter extends RecyclerView.Adapter<BindingViewHolder> {
    private LayoutInflater layoutInflater;
    private OnItemClickListener mListener; //item的点击监听器
    private List<News.NewslistBean> list;

    public interface OnItemClickListener {
        void onItemClickListener(News.NewslistBean news);
    }

    public NewsRecyclerAdapter(Context context) {
        this.layoutInflater = LayoutInflater.from(context);
        this.list = new ArrayList<>();
    }

    @NonNull
    @Override
    public BindingViewHolder onCreateViewHolder(@NonNull ViewGroup parent, int viewType) {
        ViewDataBinding binding = DataBindingUtil.inflate(layoutInflater, R.layout.item_news_fragment,parent,false);
        return new BindingViewHolder(binding);
    }

    @Override
    public void onBindViewHolder(@NonNull BindingViewHolder holder, int position) {
        final News.NewslistBean news = list.get(position);
        ViewDataBinding binding = holder.getBinding();
        binding.setVariable(BR.news,news);
        binding.executePendingBindings();

        holder.itemView.setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(View v) {
                if (mListener != null) {
                    mListener.onItemClickListener(news);
                }
            }
        });
    }

    @Override
    public int getItemCount() {
        return list.size();
    }

    public void setOnItemClickListener(OnItemClickListener listener) {
        this.mListener = listener;
    }

    public void addAll(List<News.NewslistBean> news) {
        list.addAll(news);
    }
}

1
2
3
4
5
6
7
public class DataBindingUtil {
    @BindingAdapter("BaseUrl")
    public static void loadImage(ImageView view, String url){
        Glide.with(view.getContext()).load(url).into(view);
    }
}

1
2
3
4
5
6
7
8
9
public interface GetRequest_Interface {
    @GET("social/index?key=d44ec13840090282a1af867dec47bbbd&num=50")
    Call<News> getCall();
    // 注解里传入 网络请求 的部分URL地址
    // Retrofit把网络请求的URL分成了两部分：一部分放在Retrofit对象里，另一部分放在网络请求接口里
    // 如果接口里的url是一个完整的网址，那么放在Retrofit对象里的URL可以忽略
    // getCall()是接受网络请求数据的方法
}

1
2
3
4
5
6
7
8
9
10
11
12
public class BindingViewHolder<T extends ViewDataBinding> extends RecyclerView.ViewHolder {
    private T mBinding;
    public BindingViewHolder(@NonNull T binding) {
        super(binding.getRoot());
        mBinding = binding;
    }

    public T getBinding() {
        return mBinding;
    }
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
/**
 * 新闻实体类
 * */
public class News extends BaseObservable {


    /**
     * code : 200
     * msg : success
     * newslist : [{"id":"2f5ef5351c8139baecf39b97133db3d3","ctime":"2021-03-13 09:45","title":"这段东北女法官庭审视频火出圈了 也就看了100来遍","description":"","source":"中华社会","picUrl":"https://img0.utuku.imgcdc.com/300x200/news/20210313/9a6cc7ae-37f5-4bba-8e0e-fcd23e1eac54.jpg","url":"https://news.china.com/social/1007/20210313/39375399.html"}]
     */

    private Integer code;
    private String msg;
    private List<NewslistBean> newslist;

    public Integer getCode() {
        return code;
    }

    public void setCode(Integer code) {
        this.code = code;
    }

    public String getMsg() {
        return msg;
    }

    public void setMsg(String msg) {
        this.msg = msg;
    }

    public List<NewslistBean> getNewslist() {
        return newslist;
    }

    public void setNewslist(List<NewslistBean> newslist) {
        this.newslist = newslist;
    }

    public class NewslistBean extends BaseObservable{
        /**
         * id : 2f5ef5351c8139baecf39b97133db3d3
         * ctime : 2021-03-13 09:45
         * title : 这段东北女法官庭审视频火出圈了 也就看了100来遍
         * description :
         * source : 中华社会
         * picUrl : https://img0.utuku.imgcdc.com/300x200/news/20210313/9a6cc7ae-37f5-4bba-8e0e-fcd23e1eac54.jpg
         * url : https://news.china.com/social/1007/20210313/39375399.html
         */

        private String id;
        private String ctime;
        private String title;
        private String description;
        private String source;
        private String picUrl;
        private String url;

        @Bindable
        public String getId() {
            return id;
        }

        public void setId(String id) {
            this.id = id;
            notifyPropertyChanged(BR.id);
        }

        @Bindable
        public String getCtime() {
            return ctime;
        }

        public void setCtime(String ctime) {
            this.ctime = ctime;
            notifyPropertyChanged(BR.ctime);
        }

        @Bindable
        public String getTitle() {
            return title;
        }

        public void setTitle(String title) {
            this.title = title;
            notifyPropertyChanged(BR.title);
        }

        @Bindable
        public String getDescription() {
            return description;
        }

        public void setDescription(String description) {
            this.description = description;
            notifyPropertyChanged(BR.description);
        }

        @Bindable
        public String getSource() {
            return source;
        }

        public void setSource(String source) {
            this.source = source;
            notifyPropertyChanged(BR.source);
        }

        @Bindable
        public String getPicUrl() {
            return picUrl;
        }

        public void setPicUrl(String picUrl) {
            this.picUrl = picUrl;
            notifyPropertyChanged(BR.picUrl);
        }

        @Bindable
        public String getUrl() {
            return url;
        }

        public void setUrl(String url) {
            this.url = url;
            notifyPropertyChanged(BR.url);
        }
    }
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
<?xml version="1.0" encoding="utf-8"?>
<layout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools">

    <data>
        <variable
            name="model"
            type="com.example.retrofit.MainViewModel" />
    </data>

    <LinearLayout
        android:layout_width="match_parent"
        android:layout_height="match_parent"
        android:orientation="vertical"
        tools:context=".MainActivity">

        <androidx.recyclerview.widget.RecyclerView
            android:id="@+id/recyclerView"
            android:layout_width="match_parent"
            android:layout_height="match_parent"/>

    </LinearLayout>
</layout>

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
<?xml version="1.0" encoding="utf-8"?>
<layout xmlns:tools="http://schemas.android.com/tools"
    xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto">

    <data>
        <variable
            name="news"
            type="com.example.retrofit.News.NewslistBean" />
    </data>

    <LinearLayout
        android:layout_width="match_parent"
        android:layout_height="100dp"
        android:gravity="center_vertical"
        android:orientation="horizontal"
        android:padding="12dp"
        android:background="#FFF">

        <ImageView
            android:id="@+id/imageView13"
            android:layout_width="70dp"
            android:layout_height="70dp"
            android:scaleType="centerCrop"
            app:BaseUrl="@{news.picUrl}"/>

        <LinearLayout
            android:layout_width="match_parent"
            android:layout_height="match_parent"
            android:layout_marginLeft="8dp"
            android:orientation="vertical">

            <TextView
                android:id="@+id/textView13"
                android:layout_marginTop="10dp"
                android:layout_width="match_parent"
                android:layout_height="wrap_content"
                android:singleLine="true"
                android:text="@{news.title}"
                android:textSize="16sp"
                android:textStyle="bold"
                android:textColor="#000"/>

            <TextView
                android:id="@+id/textView15"
                android:layout_width="match_parent"
                android:layout_height="wrap_content"
                android:layout_marginTop="30dp"
                android:maxLines="2"
                android:text="@{news.ctime}"
                android:textSize="12sp"/>

        </LinearLayout>
    </LinearLayout>
</layout>
