在anti-spoofing中，在OULU数据集上求APCER,BPCER,ACER上的一个注意事项

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
#创建一个用于验证集测试的类变量
pad_meter_val = PADMeter()
#图像送入模型
output,_ = model(img)
#预测概率
class_output = nn.functional.softmax(output, dim=1)
#测量TP,TN,FP,FN
pad_meter_val.update(target.cpu().data.numpy(),class_output.cpu().data.numpy())
#求eer,阈值thr
pad_meter_val.get_eer_and_thr()
#用阈值thr求hter,apcer,bpcer
pad_meter_val.get_hter_apcer_etal_at_thr(pad_meter_val.threshold)
#用阈值thr求acc
pad_meter_val.get_accuracy(pad_meter_val.threshold)
####################################################
#创建一个用于测试集测试的类变量
pad_meter_test = PADMeter()
#图像送入模型
output,_ = model(img)
#预测概率
class_output1 = nn.functional.softmax(output, dim=1)
#得到TP,TN,FP,FN
pad_meter_test.update(target.cpu().data.numpy(),class_output1.cpu().data.numpy())
#在验证集得到的阈值下，测量测试集的hter,apcer等指标
pad_meter_test.get_hter_apcer_etal_at_thr(pad_meter_val.threshold)
#验证集得到的阈值下，测量测试集的acc指标
pad_meter_test.get_accuracy(pad_meter_val.threshold)

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
import math
import numpy as np
from sklearn.metrics import roc_curve, accuracy_score
from sklearn.metrics import roc_auc_score
from torch import nn

class PADMeter(object):
    """Presentation Attack Detection Meter"""

    def __init__(self):
        self.reset()

    def reset(self):
        self.label = np.ones(0)
        self.output = np.ones(0)
        self.threshold = None
        self.grid_density = 10000

    def update(self, label, output):
        #一般取softmax之后，第1维度上的第1列数据
        if len(output.shape) > 1 and output.shape[1] > 1:
            output = output[:, 1]
        elif len(output.shape) > 1 and output.shape[1] == 1:
            output = output[:, 0]
        #拼接，将新的数据拼接到已有的后方
        self.label = np.hstack([self.label, label])
        self.output = np.hstack([self.output, output])

    def get_tpr(self, fixed_fpr):
        fpr, tpr, thr = roc_curve(self.label, self.output)
        tpr_filtered = tpr[fpr <= fixed_fpr]
        if len(tpr_filtered) == 0:
            self.tpr = 0.0
        self.tpr = tpr_filtered[-1]

    def eval_stat(self, thr):

        pred = self.output >= thr
        TN = np.sum((self.label == 0) & (pred == False))
        FN = np.sum((self.label == 1) & (pred == False))
        FP = np.sum((self.label == 0) & (pred == True))
        TP = np.sum((self.label == 1) & (pred == True))
        if TN + FP == 0:
            TN += 0.0001
        if TP + FN == 0:
            TP += 0.0001
        return TN, FN, FP, TP

    def get_eer_and_thr(self):

        thresholds = []
        Min, Max = min(self.output), max(self.output)
        for i in range(self.grid_density + 1):
            thresholds.append(Min + i * (Max - Min) / float(self.grid_density))
        min_dist = 1.0
        min_dist_stats = []
        for thr in thresholds:
            TN, FN, FP, TP = self.eval_stat(thr)
            far = FP / float(TN + FP)
            frr = FN / float(TP + FN)
            dist = math.fabs(far - frr)
            if dist < min_dist:
                min_dist = dist
                min_dist_stats = [far, frr, thr]

        # for exception
        if len(min_dist_stats) >= 2:
            self.eer = (min_dist_stats[0] + min_dist_stats[1]) / 2.0
            self.threshold = min_dist_stats[2]
        else:
            self.eer = 0.5
            self.threshold = 0.5

    def get_hter_apcer_etal_at_thr(self, thr=None):
        if thr is None:
            self.get_eer_and_thr()
            thr = self.threshold
        TN, FN, FP, TP = self.eval_stat(thr)

        far = FP / float(TN + FP)
        frr = FN / float(TP + FN)
        fpr = FP / float(FP + TN)
        tpr = TP / float(TP + FN)
        fpr1, tpr1, _ = roc_curve(self.label, self.output, pos_label=1)
        # print(type(fpr),fpr.shape,fpr.size())
        # TPR@FPR=e-2
        # tpr1 = np.array(tpr)
        # fpr1 = np.array(fpr)
        # print(type(fpr1), fpr1.shape,len(fpr1))
        # print(fpr1)
        score_1 = tpr1[np.where(fpr1 >= 0.01)[0][0]]
        # TPR@FPR=e-3
        score_2 = tpr1[np.where(fpr1 >= 0.001)[0][0]]
        # TPR@FPR=e-4
        score_3 = tpr1[np.where(fpr1 >= 0.0001)[0][0]]
        self.TN = TN
        self.FN = FN
        self.FP = FP
        self.TP = TP
        self.apcer = far
        self.bpcer = frr
        self.acer = (self.apcer + self.bpcer) / 2.0
        self.hter = (far + frr) / 2.0
        self.fpr = fpr
        self.tpr = tpr
        self.score1 = score_1
        self.score2 = score_2
        self.score3 = score_3
        try:
            self.auc = roc_auc_score(self.label, self.output)
        except ValueError:
            pass

    def get_accuracy(self, thr=None):
        if thr == None:
            self.get_eer_and_thr()
            thr = self.threshold
        TN, FN, FP, TP = self.eval_stat(thr)
        self.accuracy = accuracy = float(TP + TN) / len(self.output)
