C#读取RFID卡号源码

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
using System;
using System.Collections.Generic;
using System.ComponentModel;
using System.Data;
using System.Drawing;
using System.Linq;
using System.Text;
using System.Threading.Tasks;
using System.Windows.Forms;
using System.Runtime.InteropServices;  //调用动态库一定要加入这个引用


namespace idcardreader
{
    public partial class Form1 : Form
    {
        //------------------------------------------------------------------------------------------------------------------------------------------------------
        //外部函数声明：让设备发出声响
        [DllImport("OUR_IDR_x64.dll", EntryPoint = "idr_beep", CallingConvention = CallingConvention.StdCall)]
        static extern byte idr_beep(UInt32 xms);//xms单位为毫秒

	//------------------------------------------------------------------------------------------------------------------------------------------------------
        //读取设备编号，可做为软件加密狗用,也可以根据此编号在公司网站上查询保修期限
        [DllImport("OUR_IDR_x64.dll", EntryPoint = "pcdgetdevicenumber", CallingConvention = CallingConvention.StdCall)]
        static extern byte pcdgetdevicenumber(byte[] devicenumber);//devicenumber用于返回编号


        //------------------------------------------------------------------------------------------------------------------------------------------------------
        //只读卡号
        [DllImport("OUR_IDR_x64.dll", EntryPoint = "idr_read", CallingConvention = CallingConvention.StdCall)]
        public static extern byte idr_read(byte[] serial);//serial返回卡号


	//------------------------------------------------------------------------------------------------------------------------------------------------------
        //只读卡号，只读一次，必须拿开卡才能再读到
        [DllImport("OUR_IDR_x64.dll", EntryPoint = "idr_read_once", CallingConvention = CallingConvention.StdCall)]
        public static extern byte idr_read_once(byte[] serial);//serial返回卡号



        //------------------------------------------------------------------------------------------------------------------------------------------------------
        //发送显示内容到读卡器
        //[DllImport("OUR_IDR.dll", EntryPoint = "lcddispfull", CallingConvention = CallingConvention.StdCall)]
        //static extern byte lcddispfull(string lcdstr);
        //参数：说明

        public Form1()
        {
            InitializeComponent();
        }

        private void button2_Click(object sender, EventArgs e)
        {
            byte status;//存放返回值
            byte[] myserial = new byte[5];//卡序列号
            status = idr_read(myserial);

            switch (status)
            {
                case 0:
                    idr_beep(50);

                    MessageBox.Show("读卡成功，卡号为" + System.Convert.ToString(myserial[1] * 256 * 256 * 256 + myserial[2] * 256 * 256 + myserial[3] * 256 + myserial[4]));
                    //MessageBox.Show("操作成功,卡号已在myserial中,卡号一般为myserial[0]卡厂商标识,myserial[1]到myserial[4]为卡号,用户可以组合为各种卡号编码。");

                    break;
                //......
                case 8:
                    MessageBox.Show("请将卡放在感应区");
                    break;

                default:
                    MessageBox.Show("返回码(对应的说明请看例子中的注释):" + status);
                    break;

            }

        }

        private void button7_Click(object sender, EventArgs e)
        {//嘀一声
            idr_beep(50);
        }

        private void button6_Click(object sender, EventArgs e)
        {//读取设备编号，可做为软件加密狗用
            byte[] devno = new byte[4];
            if (pcdgetdevicenumber(devno) == 0)
            {
                MessageBox.Show(System.Convert.ToString(devno[0]) + "-" + System.Convert.ToString(devno[1]) + "-" + System.Convert.ToString(devno[2]) + "-" + System.Convert.ToString(devno[3]));
                //ShowMessage(IntToStr(devno[0]) + "-" + IntToStr(devno[1]) + "-" + IntToStr(devno[2]) + "-" + IntToStr(devno[3]));
            }
        }


        private void button4_Click(object sender, EventArgs e)
        {
            byte status;//存放返回值
            byte[] myserial = new byte[5];//卡序列号
            status = idr_read_once(myserial);

            switch (status)
            {
                case 0:
                    idr_beep(50);
                    MessageBox.Show("读卡成功，卡号为" + System.Convert.ToString(myserial[1] * 256 * 256 * 256 + myserial[2] * 256 * 256 + myserial[3] * 256 + myserial[4]));
                    //MessageBox.Show("操作成功,卡号已在myserial中,卡号一般为myserial[0]卡厂商标识,myserial[1]到myserial[4]为卡号,用户可以组合为各种卡号编码。");

                    break;
                //......
                case 8:
                    MessageBox.Show("请将卡放在感应区");
                    break;

                default:
                    MessageBox.Show("返回码(对应的说明请看例子中的注释):" + status);
                    break;

            }
        }
    }
}
