详解Android代码混淆实战

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
buildTypes {
    release {
      //开启混淆,删除无用代码
      minifyEnabled true
      //开启删除无用资源
      shrinkResources true
      proguardFiles getDefaultProguardFile('proguard-android.txt'), 'proguard-rules.pro'
    }
    debug {
      //在debug环境下使用混淆，方便调试
      signingConfig signingConfigs.debug
      minifyEnabled false
      proguardFiles getDefaultProguardFile('proguard-android.txt'), 'proguard-rules.pro'
      manifestPlaceholders = [
          // UAT 测试环境
          GETUI_APP_ID  : "FZi793fjp9654LfeDPcR29",
          GETUI_APP_KEY  : "YrVmZT4KTp65hqAtZbCj79",
          GETUI_APP_SECRET: "aLf186Rb617uj7jeNnUB89"
      ]
    }
  }
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
##################################通过混淆配置#################################
# 代码混淆压缩比，在0~7之间，默认为5，一般不做修改
-optimizationpasses 5

# 混合时不使用大小写混合，混合后的类名为小写
-dontusemixedcaseclassnames

# 指定不去忽略非公共库的类
-dontskipnonpubliclibraryclasses

# 这句话能够使我们的项目混淆后产生映射文件
# 包含有类名->混淆后类名的映射关系
-verbose

# 指定不去忽略非公共库的类成员
-dontskipnonpubliclibraryclassmembers

# 不做预校验，preverify是proguard的四个步骤之一，Android不需要preverify，去掉这一步能够加快混淆速度。
-dontpreverify
-dontoptimize

# 混淆时是否记录日志
-verbose
-ignorewarnings

# 保留Annotation不混淆
-keepattributes *Annotation*

# 避免混淆泛型
-keepattributes Signature
-keepattributes Exceptions,InnerClasses

-dontnote com.google.vending.licensing.ILicensingService
-dontnote com.android.vending.licensing.ILicensingService

# 抛出异常时保留代码行号
-keepattributes SourceFile,LineNumberTable
-keepattributes Deprecated,Synthetic,EnclosingMethod

# 重命名抛出异常时的文件名称
-renamesourcefileattribute SourceFile

# 指定混淆是采用的算法，后面的参数是一个过滤器
# 这个过滤器是谷歌推荐的算法，一般不做更改
-optimizations !code/simplification/cast,!field/*,!class/merging/*

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
#############################################
#
# Android开发中一些需要保留的公共部分
#
#############################################

# 保留我们使用的四大组件，自定义的Application等等这些类不被混淆
# 因为这些子类都有可能被外部调用
-keep public class * extends android.app.Activity
-keep public class * extends android.app.Application
-keep public class * extends android.app.Service
-keep public class * extends android.content.BroadcastReceiver
-keep public class * extends android.content.ContentProvider
-keep public class * extends android.app.backup.BackupAgentHelper
-keep public class * extends android.preference.Preference
-keep public class * extends android.view.View
#-keep public class com.android.vending.licensing.ILicensingService

# 保留support下的所有类及其内部类
-keep class android.support.** {*;}

# 保留继承的
-keep public class * extends android.support.v4.**
-keep public class * extends android.support.v7.**
-keep public class * extends android.support.annotation.**

# 保留R下面的资源
-keep class **.R$* {*;}

# 保留本地native方法不被混淆
-keepclasseswithmembernames class * {
  native <methods>;
}

# 保留在Activity中的方法参数是view的方法，
# 这样以来我们在layout中写的onClick就不会被影响
-keepclassmembers class * extends android.app.Activity{
  public void *(android.view.View);
}

# 保留枚举类不被混淆
-keepclassmembers enum * {
  public static **[] values();
  public static ** valueOf(java.lang.String);
}

# 保留我们自定义控件（继承自View）不被混淆
-keep public class * extends android.view.View{
  *** get*();
  void set*(***);
  public <init>(android.content.Context);
  public <init>(android.content.Context, android.util.AttributeSet);
  public <init>(android.content.Context, android.util.AttributeSet, int);
}

# 保留Parcelable序列化类不被混淆
-keep class * implements android.os.Parcelable {
  public static final android.os.Parcelable$Creator *;
}

# 保留Serializable序列化的类不被混淆
-keepclassmembers class * implements java.io.Serializable {
  static final long serialVersionUID;
  private static final java.io.ObjectStreamField[] serialPersistentFields;
  !static !transient <fields>;
  !private <fields>;
  !private <methods>;
  private void writeObject(java.io.ObjectOutputStream);
  private void readObject(java.io.ObjectInputStream);
  java.lang.Object writeReplace();
  java.lang.Object readResolve();
}

# 对于带有回调函数的onXXEvent、**On*Listener的，不能被混淆
-keepclassmembers class * {
  void *(**On*Event);
  void *(**On*Listener);
}

# webView处理，项目中没有使用到webView忽略即可
-keepclassmembers class fqcn.of.javascript.interface.for.webview {
  public *;
}
-keepclassmembers class * extends android.webkit.webViewClient {
  public void *(android.webkit.WebView, java.lang.String, android.graphics.Bitmap);
  public boolean *(android.webkit.WebView, java.lang.String);
}
-keepclassmembers class * extends android.webkit.webViewClient {
  public void *(android.webkit.webView, jav.lang.String);

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
#网络请求等与外界通信不能混淆
-keep class com.xxxxx.function.**.net.** { *; }
-keep class com.xxxxx.function.**.bean.** { *; }
-keep class com.xxxxx.common.net.** { *; }
-keep class com.xxxxx.common.bean.** { *; }
#加密不能混淆
-keep class com.xxxxx.crypt.** {*;}

#数据库实体类不能混淆
-keep class com.xxxxxx.function.**.dao.** { *; }
#工具类不混淆
-keep class com.xxxxx.common.utils.** { *; }
#greenDAO 3
#-keepclassmembers class * extends org.greenrobot.greendao.AbstractDao {
#public static java.lang.String TABLENAME;
#}
#-keep class **$Properties
#-dontwarn org.greenrobot.greendao.database.**
#-dontwarn rx.**
#greenDAO 3

# Fresco
#-keep class com.facebook.** {*;}
#-keep interface com.facebook.** {*;}
#-keep enum com.facebook.** {*;}

# OkHttp3
-dontwarn com.squareup.okhttp3.**
-keep class com.squareup.okhttp3.** { *;}
-dontwarn okio.**

#Picasso
#-dontwarn com.squareup.okhttp.**

#zxing
-dontwarn com.google.zxing.**
-keep class com.google.zxing.** { *; }

#webview
-dontwarn com.tencent.**

#eventbus不能混淆
-keepattributes *Annotation*
-keepclassmembers class ** {
  @org.greenrobot.eventbus.Subscribe <methods>;
}
-keep enum org.greenrobot.eventbus.ThreadMode { *; }

# Only required if you use AsyncExecutor
-keepclassmembers class * extends org.greenrobot.eventbus.util.ThrowableFailureEvent {
  <init>(java.lang.Throwable);
}
#如果项目中倒入了de.greenrobot.even的beta1版本，需要添加此行代码
-keepclassmembers class ** {
  public void onEvent*(**);
}

#高德
-dontwarn com.amap.api.**
-keep class com.amap.api.** {*;}

#bugout
-dontwarn com.qamaster.android.**
-dontwarn com.testin.agent.**
-keepattributes InnerClasses
-keep class com.testin.agent.** { *; }
-keepattributes SourceFile, LineNumberTable

#butterknife
-keep class butterknife.** { *; }
-dontwarn butterknife.internal.**
-keep class **$$ViewBinder { *; }
-keepclasseswithmembernames class * {
  @butterknife.* <fields>;
}
-keepclasseswithmembernames class * {
  @butterknife.* <methods>;
}

#sharesdk
-keep class cn.sharesdk.**{*;}
-keep class com.sina.**{*;}
-keep class **.R$* {*;}
-keep class **.R{*;}
-dontwarn cn.sharesdk.**
-dontwarn **.R$*
-dontwarn com.tencent.**
-keep class com.tencent.** {*;}

# rx
-dontwarn rx.**
-keepclassmembers class rx.** { *; }
# retrolambda
-dontwarn java.lang.invoke.*

# Glide specific rules #
-keep public class * implements com.bumptech.glide.module.GlideModule
-keep public enum com.bumptech.glide.load.resource.bitmap.ImageHeaderParser$** {
  **[] $VALUES;
  public *;
}

#友盟统计
-keep class com.umeng.message.protobuffer.* {
   public <fields>;
     public <methods>;
}
-keep class com.umeng.message.* {
   public <fields>;
     public <methods>;
}

#ormLite
-keep public class * extends com.j256.ormlite.android.apptools.OrmLiteSqliteOpenHelper
-keep public class * extends com.j256.ormlite.android.apptools.OpenHelperManager
-keepclassmembers class * {@com.j256.ormlite.field.DatabaseField *;}
-keep class com.j256.ormlite.** {*;}

# Gson specific classes
-keep class sun.misc.Unsafe { *; }
-keep class com.google.gson.stream.** { *; }

#zbar
-keep class net.sourceforge.zbar.**{*;}

-keep class com.nineoldandroids.** {*;}

#身份证ocr
-keep class com.yd.ocr.idcard.** { *; }
-keep class com.googlecode.** { *; }
-keep class org.opencv.** { *; }

#讯飞语音
-keep class com.iflytek.** { *; }

# FastJson 混淆代码
-dontwarn com.alibaba.fastjson.**
-keep class com.alibaba.fastjson.** { *; }
-keepattributes Signature
-keepattributes *Annotation*
