Android使用ViewPager实现类似laucher左右拖动效果

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
<?xml version="1.0" encoding="utf-8"?>
<FrameLayout xmlns:android="http://schemas.android.com/apk/res/android"
 android:layout_width="fill_parent"
 android:layout_height="fill_parent"
 android:orientation="vertical" >

 <android.support.v4.view.ViewPager
 android:id="@+id/guidePages"
 android:layout_width="fill_parent"
 android:layout_height="wrap_content"/>

 <RelativeLayout
 android:layout_width="fill_parent"
 android:layout_height="wrap_content"
 android:orientation="vertical" >
 <LinearLayout
 android:id="@+id/viewGroup"
 android:layout_width="fill_parent"
 android:layout_height="wrap_content"
 android:layout_alignParentBottom="true"
 android:layout_marginBottom="30dp"
 android:gravity="center_horizontal"
 android:orientation="horizontal" >
 </LinearLayout>
 </RelativeLayout>

</FrameLayout>

1
2
3
4
5
6
7
8
9
10
11
12
13
<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
 android:layout_width="fill_parent"
 android:layout_height="fill_parent"
 android:orientation="vertical" >

 <ImageView
 android:layout_width="fill_parent"
 android:layout_height="fill_parent"
 android:background="@drawable/feature_guide_0" >
 </ImageView>

</LinearLayout>

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
package com.andyidea.guidedemo;

import java.util.ArrayList;

import android.app.Activity;
import android.os.Bundle;
import android.os.Parcelable;
import android.support.v4.view.PagerAdapter;
import android.support.v4.view.ViewPager;
import android.support.v4.view.ViewPager.OnPageChangeListener;
import android.view.LayoutInflater;
import android.view.View;
import android.view.ViewGroup;
import android.view.ViewGroup.LayoutParams;
import android.view.Window;
import android.widget.ImageView;

public class GuideViewDemoActivity extends Activity {

 private ViewPager viewPager;
 private ArrayList<View> pageViews;
 private ViewGroup main, group;
 private ImageView imageView;
 private ImageView[] imageViews;

 /** Called when the activity is first created. */
 @Override
 public void onCreate(Bundle savedInstanceState) {
 super.onCreate(savedInstanceState);
 this.requestWindowFeature(Window.FEATURE_NO_TITLE);

 LayoutInflater inflater = getLayoutInflater();
 pageViews = new ArrayList<View>();
 pageViews.add(inflater.inflate(R.layout.item01, null));
 pageViews.add(inflater.inflate(R.layout.item02, null));
 pageViews.add(inflater.inflate(R.layout.item03, null));
 pageViews.add(inflater.inflate(R.layout.item04, null));

 imageViews = new ImageView[pageViews.size()];
 main = (ViewGroup)inflater.inflate(R.layout.main, null);

 // group是R.layou.main中的负责包裹小圆点的LinearLayout.
 group = (ViewGroup)main.findViewById(R.id.viewGroup);

 viewPager = (ViewPager)main.findViewById(R.id.guidePages);

 for (int i = 0; i < pageViews.size(); i++) {
  imageView = new ImageView(GuideViewDemoActivity.this);
  imageView.setLayoutParams(new LayoutParams(20,20));
  imageView.setPadding(20, 0, 20, 0);
  imageViews[i] = imageView;
  if (i == 0) {
  //默认选中第一张图片
  imageViews[i].setBackgroundResource(R.drawable.page_indicator_focused);
  } else {
  imageViews[i].setBackgroundResource(R.drawable.page_indicator);
  }
  group.addView(imageViews[i]);
 }

 setContentView(main);

 viewPager.setAdapter(new GuidePageAdapter());
 viewPager.setOnPageChangeListener(new GuidePageChangeListener());
 }

 /** 指引页面Adapter */
 class GuidePageAdapter extends PagerAdapter {

 @Override
 public int getCount() {
  return pageViews.size();
 }

 @Override
 public boolean isViewFromObject(View arg0, Object arg1) {
  return arg0 == arg1;
 }

 @Override
 public int getItemPosition(Object object) {
  // TODO Auto-generated method stub
  return super.getItemPosition(object);
 }

 @Override
 public void destroyItem(View arg0, int arg1, Object arg2) {
  // TODO Auto-generated method stub
  ((ViewPager) arg0).removeView(pageViews.get(arg1));
 }

 @Override
 public Object instantiateItem(View arg0, int arg1) {
  // TODO Auto-generated method stub
  ((ViewPager) arg0).addView(pageViews.get(arg1));
  return pageViews.get(arg1);
 }

 @Override
 public void restoreState(Parcelable arg0, ClassLoader arg1) {
  // TODO Auto-generated method stub

 }

 @Override
 public Parcelable saveState() {
  // TODO Auto-generated method stub
  return null;
 }

 @Override
 public void startUpdate(View arg0) {
  // TODO Auto-generated method stub

 }

 @Override
 public void finishUpdate(View arg0) {
  // TODO Auto-generated method stub

 }
 }

 /** 指引页面改监听器 */
 class GuidePageChangeListener implements OnPageChangeListener {

 @Override
 public void onPageScrollStateChanged(int arg0) {
  // TODO Auto-generated method stub

 }

 @Override
 public void onPageScrolled(int arg0, float arg1, int arg2) {
  // TODO Auto-generated method stub

 }

 @Override
 public void onPageSelected(int arg0) {
  for (int i = 0; i < imageViews.length; i++) {
  imageViews[arg0]
   .setBackgroundResource(R.drawable.page_indicator_focused);
  if (arg0 != i) {
   imageViews[i]
    .setBackgroundResource(R.drawable.page_indicator);
  }
  }

 }

 }

}
