详解Android文件描述符

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
struct task_struct
{
// 进程状态
long               state;
// 虚拟内存结构体
struct mm_struct *mm;
// 进程号
pid_t              pid;
// 指向父进程的指针
struct task_struct*parent;
// 子进程列表
struct list_head children;
// 存放文件系统信息的指针
struct fs_struct* fs;
// 存放该进程打开的文件指针数组
struct files_struct *files;
};

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
/*
 * Open file table structure
 */
struct files_struct {
  /*
   * read mostly part
   */
    atomic_t count;//自动增量
    bool resize_in_progress;
    wait_queue_head_t resize_wait;

    struct fdtable __rcu *fdt; //fdtable类型指针
    struct fdtable fdtab;  //fdtable变量实例
  /*
   * written part on a separate cache line in SMP
   */
    spinlock_t file_lock ____cacheline_aligned_in_smp;
    unsigned int next_fd;
    unsigned long close_on_exec_init[1];//执行exec时需要关闭的文件描述符初值结合（从主进程中fork出子进程）
    unsigned long open_fds_init[1];//todo 含义补充
    unsigned long full_fds_bits_init[1];//todo 含义补充
    struct file __rcu * fd_array[NR_OPEN_DEFAULT];//默认的文件描述符长度
};

1
2
3
4
5
6
7
8
struct fdtable {
    unsigned int max_fds;
    struct file __rcu **fd;      //指向文件对象指针数组的指针
    unsigned long *close_on_exec;
    unsigned long *open_fds;     //指向打开文件描述符的指针
    unsigned long *full_fds_bits;
    struct rcu_head rcu;
};

1
2
3
4
5
6
7
8
9
10
11
12
13
struct files_struct init_files = {
    .count      = ATOMIC_INIT(1),
    .fdt        = &init_files.fdtab,//指向当前fdtable
    .fdtab      = {
        .max_fds    = NR_OPEN_DEFAULT,
        .fd     = &init_files.fd_array[0],//指向files_struct中的fd_array
        .close_on_exec  = init_files.close_on_exec_init,//指向files_struct中的close_on_exec_init
        .open_fds   = init_files.open_fds_init,//指向files_struct中的open_fds_init
        .full_fds_bits  = init_files.full_fds_bits_init,//指向files_struct中的full_fds_bits_init
    },
    .file_lock  = __SPIN_LOCK_UNLOCKED(init_files.file_lock),
    .resize_wait    = __WAIT_QUEUE_HEAD_INITIALIZER(init_files.resize_wait),
};

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
struct file {
    union {
        struct llist_node   fu_llist; //用于通用文件对象链表的指针
        struct rcu_head     fu_rcuhead;//RCU(Read-Copy Update)是Linux 2.6内核中新的锁机制
    } f_u;
    struct path     f_path;//path结构体，包含vfsmount：指出该文件的已安装的文件系统，dentry：与文件相关的目录项对象
    struct inode        *f_inode;   /* cached value */
    const struct file_operations    *f_op;//文件操作，当进程打开文件的时候，这个文件的关联inode中的i_fop文件操作会初始化这个f_op字段

    /*
     * Protects f_ep_links, f_flags.
     * Must not be taken from IRQ context.
     */
    spinlock_t      f_lock;
    enum rw_hint        f_write_hint;
    atomic_long_t       f_count; //引用计数
    unsigned int        f_flags; //打开文件时候指定的标识，对应系统调用open的int flags参数。驱动程序为了支持非阻塞型操作需要检查这个标志
    fmode_t         f_mode;//对文件的读写模式，对应系统调用open的mod_t mode参数。如果驱动程序需要这个值，可以直接读取这个字段
    struct mutex        f_pos_lock;
    loff_t          f_pos; //目前文件的相对开头的偏移
    struct fown_struct  f_owner;
    const struct cred   *f_cred;
    struct file_ra_state    f_ra;

    u64         f_version;
#ifdef CONFIG_SECURITY
    void            *f_security;
#endif
    /* needed for tty driver, and maybe others */
    void            *private_data;

#ifdef CONFIG_EPOLL
    /* Used by fs/eventpoll.c to link all the hooks to this file */
    struct list_head    f_ep_links;
    struct list_head    f_tfile_llink;
#endif /* #ifdef CONFIG_EPOLL */
    struct address_space    *f_mapping;
    errseq_t        f_wb_err;
    errseq_t        f_sb_err; /* for syncfs */
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
//初始化
private void init(){
   //init
  if(null != mHandlerThread){
     mHandlerThread = new HandlerThread("fd-test");
     mHandlerThread.start();
     mHandler = new Handler(mHandlerThread.getLooper());
  }
}

//释放handlerThread
private void release(){
   if(null != mHandler){
      mHandler.removeCallbacksAndMessages(null);
      mHandler = null;
   }
   if(null != mHandlerThread){
      mHandlerThread.quitSafely();
      mHandlerThread = null;
   }
}

1
2
3
4
5
6
7
8
9
10
11
12
public void run() {
    mTid = Process.myTid();
    Looper.prepare();
    synchronized (this) {
        mLooper = Looper.myLooper();
        notifyAll();
    }
    Process.setThreadPriority(mPriority);
    onLooperPrepared();
    Looper.loop();
    mTid = -1;
}

1
2
3
4
private Looper(boolean quitAllowed) {
    mQueue = new MessageQueue(quitAllowed);
    mThread = Thread.currentThread();
}

1
2
3
4
MessageQueue(boolean quitAllowed) {
    mQuitAllowed = quitAllowed;
    mPtr = nativeInit();//native层代码
}

1
2
3
4
5
6
7
8
9
static jlong android_os_MessageQueue_nativeInit(JNIEnv* env, jclass clazz) {
    NativeMessageQueue* nativeMessageQueue = new NativeMessageQueue();
    if (!nativeMessageQueue) {
        jniThrowRuntimeException(env, "Unable to allocate native queue");
        return 0;
    }
    nativeMessageQueue->incStrong(env);
    return reinterpret_cast<jlong>(nativeMessageQueue);
}

1
2
3
4
5
6
7
NativeMessageQueue::NativeMessageQueue() :mPollEnv(NULL), mPollObj(NULL), mExceptionObj(NULL) {
    mLooper = Looper::getForThread();
    if (mLooper == NULL) {
        mLooper = new Looper(false);
        Looper::setForThread(mLooper);
    }
}

1
2
3
4
5
6
7
8
9
10
11
12
Looper::Looper(bool allowNonCallbacks): mAllowNonCallbacks(allowNonCallbacks),
      mSendingMessage(false),
      mPolling(false),
      mEpollRebuildRequired(false),
      mNextRequestSeq(0),
      mResponseIndex(0),
      mNextMessageUptime(LLONG_MAX) {
    mWakeEventFd.reset(eventfd(0, EFD_NONBLOCK | EFD_CLOEXEC));//eventfd
    LOG_ALWAYS_FATAL_IF(mWakeEventFd.get() < 0, "Could not make wake event fd: %s", strerror(errno));
    AutoMutex _l(mLock);
    rebuildEpollLocked();
}

1
2
3
4
5
6
7
/**
 * [eventfd(2)](http://man7.org/linux/man-pages/man2/eventfd.2.html) creates a file descriptor
 * for event notification.
 *
 * Returns a new file descriptor on success, and returns -1 and sets `errno` on failure.
 */
int eventfd(unsigned int __initial_value, int __flags);

1
2
3
4
5
6
7
8
9
10
11
private void ioTest(){
    try {
        File file = new File(getCacheDir(), "testFdFile");
        file.createNewFile();
        FileOutputStream out = new FileOutputStream(file);
        //do something
        out.close();
    }catch (Exception e){
        e.printStackTrace();
    }
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
private void ioTest() {
    FileOutputStream out = null;
    try {
        File file = new File(getCacheDir(), "testFdFile");
        file.createNewFile();
        out = new FileOutputStream(file);
        //do something
        out.close();
    } catch (Exception e) {
        e.printStackTrace();
    } finally {
        if (null != out) {
            try {
                out.close();
            } catch (IOException e) {
                e.printStackTrace();
            }
        }
    }
}

1
2
3
4
5
6
7
8
public FileOutputStream(File file, boolean append) throws FileNotFoundException
{
   //......
  this.fd = new FileDescriptor();
   //......
  open(name, append);
   //......
}

1
2
3
4
5
6
7
8
9
10
11
12
/**
 * Opens a file, with the specified name, for overwriting or appending.
 * @param name name of file to be opened
 * @param append whether the file is to be opened in append mode
 */
private native void open0(String name, boolean append)
    throws FileNotFoundException;

private void open(String name, boolean append)
    throws FileNotFoundException {
    open0(name, append);
}

1
2
3
4
5
JNIEXPORT void JNICALL
FileOutputStream_open0(JNIEnv *env, jobject this, jstring path, jboolean append) {
    fileOpen(env, this, path, fos_fd,
             O_WRONLY | O_CREAT | (append ? O_APPEND : O_TRUNC));
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
void fileOpen(JNIEnv *env, jobject this, jstring path, jfieldID fid, int flags)
{
    WITH_PLATFORM_STRING(env, path, ps) {
        FD fd;
        //......
        fd = handleOpen(ps, flags, 0666);
        if (fd != -1) {
            SET_FD(this, fd, fid);
        } else {
            throwFileNotFoundException(env, path);
        }
    } END_PLATFORM_STRING(env, ps);
}


FD handleOpen(const char *path, int oflag, int mode) {
    FD fd;
    RESTARTABLE(open64(path, oflag, mode), fd);//调用open，获取fd
    if (fd != -1) {
        //......
        if (result != -1) {
            //......
        } else {
            close(fd);
            fd = -1;
        }
    }
    return fd;
}

1
2
3
#define SET_FD(this, fd, fid)
    if ((*env)->GetObjectField(env, (this), (fid)) != NULL)
        (*env)->SetIntField(env, (*env)->GetObjectField(env, (this), (fid)),IO_fd_fdID, (fd))

1
2
3
4
static void FileOutputStream_initIDs(JNIEnv *env) {
    jclass clazz = (*env)->FindClass(env, "java/io/FileOutputStream");
    fos_fd = (*env)->GetFieldID(env, clazz, "fd", "Ljava/io/FileDescriptor;");
}

1
2
3
4
5
6
7
8
9
10
11
12
13
public void get() {
    db = ordersDBHelper.getReadableDatabase();
    Cursor cursor = db.query(...);
    while (cursor.moveToNext()) {
      //......
    }
    if(flag){
       //某种原因导致retrn
       return;
    }
    //不调用close，fd就会泄漏
    cursor.close();
}

1
2
3
4
5
6
7
8
9
10
11
public Cursor query(CursorFactory factory, String[] selectionArgs) {
    final SQLiteQuery query = new SQLiteQuery(mDatabase, mSql, mCancellationSignal);
    final Cursor cursor;
      //......
      if (factory == null) {
          cursor = new SQLiteCursor(this, mEditTable, query);
      } else {
          cursor = factory.newCursor(mDatabase, this, mEditTable, query);
      }
      //......
}

1
2
3
4
5
6
7
8
9
10
11
12
13
@Override
public final boolean moveToNext() {
    return moveToPosition(mPos + 1);
}
public final boolean moveToPosition(int position) {
    // Make sure position isn't past the end of the cursor
    final int count = getCount();
    if (position >= count) {
        mPos = count;
        return false;
    }
    //......
}

1
2
3
4
5
6
7
8
9
10
11
@Override
public int getCount() {
    if (mCount == NO_COUNT) {
        fillWindow(0);
    }
    return mCount;
}
private void fillWindow(int requiredPos) {
    clearOrCreateWindow(getDatabase().getPath());
    //......
}

1
2
3
4
5
6
7
protected void clearOrCreateWindow(String name) {
    if (mWindow == null) {
        mWindow = new CursorWindow(name);
    } else {
        mWindow.clear();
    }
}

1
2
3
4
5
public CursorWindow(String name, @BytesLong long windowSizeBytes) {
    //......
    mWindowPtr = nativeCreate(mName, (int) windowSizeBytes);
    //......
}

1
2
3
4
5
6
7
static jlong nativeCreate(JNIEnv* env, jclass clazz, jstring nameObj, jint cursorWindowSize) {
    //......
    CursorWindow* window;
    status_t status = CursorWindow::create(name, cursorWindowSize, &window);
    //......
    return reinterpret_cast<jlong>(window);
}

1
2
3
4
5
6
7
status_t CursorWindow::create(const String8& name, size_t size, CursorWindow** outCursorWindow) {
    String8 ashmemName("CursorWindow: ");
    ashmemName.append(name);
    status_t result;
    int ashmemFd = ashmem_create_region(ashmemName.string(), size);
    //......
}

1
2
3
4
5
private void addView() {
    View windowView = LayoutInflater.from(getApplication()).inflate(R.layout.layout_window, null);
    //重复调用
    mWindowManager.addView(windowView, wmParams);
}

1
2
3
4
5
6
public void addView(View view, ViewGroup.LayoutParams params, Display display, Window parentWindow) {
    //......
    root = new ViewRootImpl(view.getContext(), display);
    //......
    root.setView(view, wparams, panelParentView);
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
public void setView(View view, WindowManager.LayoutParams attrs, View panelParentView) {
    //......
    //创建inputchannel
    if ((mWindowAttributes.inputFeatures
        & WindowManager.LayoutParams.INPUT_FEATURE_NO_INPUT_CHANNEL) == 0) {
        mInputChannel = new InputChannel();
    }
    //远程服务接口
    res = mWindowSession.addToDisplay(mWindow, mSeq, mWindowAttributes,
        getHostVisibility(), mDisplay.getDisplayId(), mWinFrame,
        mAttachInfo.mContentInsets, mAttachInfo.mStableInsets,
        mAttachInfo.mOutsets, mAttachInfo.mDisplayCutout, mInputChannel);//mInputChannel 作为参数传过去
    //......
    if (mInputChannel != null) {
        if (mInputQueueCallback != null) {
            mInputQueue = new InputQueue();
            mInputQueueCallback.onInputQueueCreated(mInputQueue);
        }
        //创建 WindowInputEventReceiver 对象
        mInputEventReceiver = new WindowInputEventReceiver(mInputChannel,
            Looper.myLooper());
    }
}

1
2
3
4
5
6
7
8
9
public int addToDisplay(IWindow window, int seq, WindowManager.LayoutParams attrs,
        int viewVisibility, int displayId, Rect outFrame, Rect outContentInsets,
        Rect outStableInsets,
        DisplayCutout.ParcelableWrapper outDisplayCutout, InputChannel outInputChannel,
        InsetsState outInsetsState, InsetsSourceControl[] outActiveControls) {
    return mService.addWindow(this, window, seq, attrs, viewVisibility, displayId, outFrame,
            outContentInsets, outStableInsets, outDisplayCutout, outInputChannel,
            outInsetsState, outActiveControls, UserHandle.getUserId(mUid));
}

1
2
3
4
5
6
7
8
9
10
11
12
public int addWindow(Session session, IWindow client, int seq,
        LayoutParams attrs, int viewVisibility, int displayId, Rect outFrame,
        Rect outContentInsets, Rect outStableInsets, Rect outOutsets,
        DisplayCutout.ParcelableWrapper outDisplayCutout, InputChannel outInputChannel) {
        //......
        final boolean openInputChannels = (outInputChannel != null
        && (attrs.inputFeatures & INPUT_FEATURE_NO_INPUT_CHANNEL) == 0);
        if  (openInputChannels) {
            win.openInputChannel(outInputChannel);
        }
        //......
}

1
2
3
4
5
6
7
void openInputChannel(InputChannel outInputChannel) {
    //......
    InputChannel[] inputChannels = InputChannel.openInputChannelPair(name);
    mInputChannel = inputChannels[0];
    mClientChannel = inputChannels[1];
    //......
}

1
2
3
4
5
6
7
8
9
10
int socketpair(int domain, int type, int protocol, int sv[2]) {
    //创建一对匿名的已经连接的套接字
    int rc = __socketpair(domain, type, protocol, sv);
    if (rc == 0) {
        //跟踪文件描述符
        FDTRACK_CREATE(sv[0]);
        FDTRACK_CREATE(sv[1]);
    }
    return rc;
}

1
2
3
4
5
if (Build.VERSION.SDK_INT >= VersionCodes.L) {
    linkTarget = Os.readlink(file.getAbsolutePath());
} else {
    //通过 readlink 读取文件描述符信息
}
