一文了解Node.js中的多进程模型

const cluster = require('cluster');
const http = require('http');
const numCPUs = require('os').cpus().length;

if (cluster.isMaster) {
  // Fork workers.
  for (let i = 0; i < numCPUs; i++) {
    cluster.fork();
  }

  cluster.on('exit', function(worker, code, signal) {
    console.log('worker ' + worker.process.pid + ' died');
  });
} else {
  // Workers can share any TCP connection
  // In this case it is an HTTP server
  http.createServer(function(req, res) {
    res.writeHead(200);
    res.end("hello worldn");
  }).listen(8000);
}

'use strict';

const childOrPrimary = 'NODE_UNIQUE_ID' in process.env ? 'child' : 'master';
module.exports = require(`internal/cluster/${childOrPrimary}`);

// internal/cluster/master.js
cluster.isWorker = false;
cluster.isMaster = true;

// internal/cluster/child.js
cluster.isWorker = true;
cluster.isMaster = false;

// lib/internal/cluster/master.js

// 初始化cluster
const cluster = new EventEmitter();
// 创建监听地址与server对应的map
const handles = new SafeMap();
// 初始化
cluster.isWorker = false;
cluster.isMaster = true;
cluster.workers = {};
cluster.settings = {};
cluster.SCHED_NONE = SCHED_NONE;  // Leave it to the operating system.
cluster.SCHED_RR = SCHED_RR;      // Master distributes connections.

// 自增的子进程id
let ids = 0;

// 向cluster添加fork方法
cluster.fork = function(env) {
  // 初始化cluster.settings
  cluster.setupMaster();
  // 为当前fork的子进程生成当前cluster内的唯一id
  const id = ++ids;
  // 创建子进程
  const workerProcess = createWorkerProcess(id, env);
  // 创建对应的worker实例
  const worker = new Worker({
    id: id,
    process: workerProcess
  });

  // 省略一些worker的事件监听....

  // 监听内部消息事件，并交由onmessage处理
  worker.process.on('internalMessage', internal(worker, onmessage));
  // cluster发出fork事件
  process.nextTick(emitForkNT, worker);
  // 将worker实例放在cluster.workers中维护
  cluster.workers[worker.id] = worker;
  // 返回worker
  return worker;
};

// 创建子进程函数
function createWorkerProcess(id, env) {
  // 将主进程的env、调用cluster.fork时传入的env以及NODE_UNIQUE_ID env构建成一个env对象
  const workerEnv = { ...process.env, ...env, NODE_UNIQUE_ID: `${id}` };
  // 执行参数
  const execArgv = [...cluster.settings.execArgv];

  // 省略debug模式相关逻辑...

  // 调用child_process模块的fork函数创建子进程并返回，至此子进程实例创建完成
  return fork(cluster.settings.exec, cluster.settings.args, {
    cwd: cluster.settings.cwd,
    env: workerEnv,
    serialization: cluster.settings.serialization,
    silent: cluster.settings.silent,
    windowsHide: cluster.settings.windowsHide,
    execArgv: execArgv,
    stdio: cluster.settings.stdio,
    gid: cluster.settings.gid,
    uid: cluster.settings.uid
  });
}

// 内部消息事件处理函数
function onmessage(message, handle) {
  const worker = this;

  if (message.act === 'online')
    online(worker);
  // 当子进程向主进程发出queryServer消息后，执行queryServer函数，创建server
  else if (message.act === 'queryServer')
    queryServer(worker, message);
  else if (message.act === 'listening')
    listening(worker, message);
  else if (message.act === 'exitedAfterDisconnect')
    exitedAfterDisconnect(worker, message);
  else if (message.act === 'close')
    close(worker, message);
}

// 获取server
function queryServer(worker, message) {
  // Stop processing if worker already disconnecting
  if (worker.exitedAfterDisconnect)
    return;

  // 创建当前子进程监听地址信息的key
  const key = `${message.address}:${message.port}:${message.addressType}:` +
              `${message.fd}:${message.index}`;
  // 在handles map中查询是否有已经创建好的该监听地址的server
  let handle = handles.get(key);

  // 没有对应的server则进行创建
  if (handle === undefined) {
    let address = message.address;

    // Find shortest path for unix sockets because of the ~100 byte limit
    if (message.port < 0 && typeof address === 'string' &&
        process.platform !== 'win32') {

      address = path.relative(process.cwd(), address);

      if (message.address.length < address.length)
        address = message.address;
    }

    // 主、子进程处理连接的方式，默认为轮询
    let constructor = RoundRobinHandle;
    // UDP is exempt from round-robin connection balancing for what should
    // be obvious reasons: it's connectionless. There is nothing to send to
    // the workers except raw datagrams and that's pointless.
    if (schedulingPolicy !== SCHED_RR ||
        message.addressType === 'udp4' ||
        message.addressType === 'udp6') {
      constructor = SharedHandle;
    }

    // 将监听地址信息传入构造函数创建监听实例
    handle = new constructor(key, address, message);
    // 缓存监听实例
    handles.set(key, handle);
  }

  // 向server添加自定义信息，用于server发出listening事件后透传到worker
  if (!handle.data)
    handle.data = message.data;

  // 添加server发出listening事件后的回调函数通知子进程
  handle.add(worker, (errno, reply, handle) => {
    const { data } = handles.get(key);

    if (errno)
      handles.delete(key);  // Gives other workers a chance to retry.

    send(worker, {
      errno,
      key,
      ack: message.seq,
      data,
      ...reply
    }, handle);
  });
}

// lib/internal/cluster/round_robin_handle.js

// 构造函数，参数为server对应的key，ip地址(对于http(s)来说)，监听相关信息
function RoundRobinHandle(key, address, { port, fd, flags }) {
  // 初始化handle
  this.key = key;
  this.all = new SafeMap();
  this.free = new SafeMap();
  this.handles = [];
  this.handle = null;
  this.server = net.createServer(assert.fail);

  // 监听文件描述符，不讨论
  if (fd >= 0)
    this.server.listen({ fd });
  // 监听ip:port
  else if (port >= 0) {
    this.server.listen({
      port,
      host: address,
      // Currently, net module only supports `ipv6Only` option in `flags`.
      ipv6Only: Boolean(flags & constants.UV_TCP_IPV6ONLY),
    });
  // 监听UNIX socket，不讨论
  } else
    this.server.listen(address);  // UNIX socket path.

  // 注册server发出listening事件的回调函数
  this.server.once('listening', () => {
    this.handle = this.server._handle;
    this.handle.onconnection = (err, handle) => this.distribute(err, handle);
    this.server._handle = null;
    this.server = null;
  });
}

// 添加worker，server发出listening事件后调用master.js中传入的回调函数
RoundRobinHandle.prototype.add = function(worker, send) {
  assert(this.all.has(worker.id) === false);
  this.all.set(worker.id, worker);

  const done = () => {
    if (this.handle.getsockname) {
      const out = {};
      this.handle.getsockname(out);
      // TODO(bnoordhuis) Check err.
      send(null, { sockname: out }, null);
    } else {
      send(null, null, null);  // UNIX socket.
    }

    this.handoff(worker);  // In case there are connections pending.
  };

  if (this.server === null)
    return done();

  // Still busy binding.
  this.server.once('listening', done);
  this.server.once('error', (err) => {
    send(err.errno, null);
  });
};

// 删除worker，轮询时不再分配给该worker
RoundRobinHandle.prototype.remove = function(worker) {
  const existed = this.all.delete(worker.id);

  if (!existed)
    return false;

  this.free.delete(worker.id);

  if (this.all.size !== 0)
    return false;

  for (const handle of this.handles) {
    handle.close();
  }
  this.handles = [];

  this.handle.close();
  this.handle = null;
  return true;
};

// 轮询调度函数
RoundRobinHandle.prototype.distribute = function(err, handle) {
  ArrayPrototypePush(this.handles, handle);
  const [ workerEntry ] = this.free; // this.free is a SafeMap

  if (ArrayIsArray(workerEntry)) {
    const { 0: workerId, 1: worker } = workerEntry;
    this.free.delete(workerId);
    this.handoff(worker);
  }
};

// 将handle交给worker
RoundRobinHandle.prototype.handoff = function(worker) {
  if (!this.all.has(worker.id)) {
    return;  // Worker is closing (or has closed) the server.
  }

  const handle = ArrayPrototypeShift(this.handles);

  if (handle === undefined) {
    this.free.set(worker.id, worker);  // Add to ready queue again.
    return;
  }

  // 向该worker发出newconn事件
  const message = { act: 'newconn', key: this.key };

  sendHelper(worker.process, message, handle, (reply) => {
    if (reply.accepted)
      handle.close();
    else
      this.distribute(0, handle);  // Worker is shutting down. Send to another.

    this.handoff(worker);
  });
};

// lib/_http_server.js

function Server(options, requestListener) {
  ....
}

ObjectSetPrototypeOf(Server.prototype, net.Server.prototype);
ObjectSetPrototypeOf(Server, net.Server);

// lib/net.js

Server.prototype.listen = function(...args) {

  // 由于篇幅原因，省略一些参数nomolize和其他监听的处理

  // 经过这段逻辑中，会调用listenInCluster函数去真正的监听端口
  if (typeof options.port === 'number' || typeof options.port === 'string') {
    validatePort(options.port, 'options.port');
    backlog = options.backlog || backlogFromArgs;
    // start TCP server listening on host:port
    if (options.host) {
      lookupAndListen(this, options.port | 0, options.host, backlog,
                      options.exclusive, flags);
    } else { // Undefined host, listens on unspecified address
      // Default addressType 4 will be used to search for master server
      listenInCluster(this, null, options.port | 0, 4,
                      backlog, undefined, options.exclusive);
    }
    return this;
  }

  // 省略...
};

// 集群监听函数
function listenInCluster(server, address, port, addressType,
                         backlog, fd, exclusive, flags) {
  exclusive = !!exclusive;

  if (cluster === undefined) cluster = require('cluster');

  // 判断是否是master，单进程中cluster.isMaster默认为true，然后进行监听并返回
  if (cluster.isMaster || exclusive) {
    // Will create a new handle
    // _listen2 sets up the listened handle, it is still named like this
    // to avoid breaking code that wraps this method
    server._listen2(address, port, addressType, backlog, fd, flags);
    return;
  }

  // 在子进程中，会将监听地址信息传入cluster实例中的_getServer函数从而获取一个faux handle
  const serverQuery = {
    address: address,
    port: port,
    addressType: addressType,
    fd: fd,
    flags,
  };

  // Get the master's server handle, and listen on it
  cluster._getServer(server, serverQuery, listenOnMasterHandle);

  // 获取net server回调函数，拿到faux handle之后，调用_listen2函数，即setupListenHandle函数
  function listenOnMasterHandle(err, handle) {
    err = checkBindError(err, port, handle);

    if (err) {
      const ex = exceptionWithHostPort(err, 'bind', address, port);
      return server.emit('error', ex);
    }

    // Reuse master's server handle
    server._handle = handle;
    // _listen2 sets up the listened handle, it is still named like this
    // to avoid breaking code that wraps this method
    server._listen2(address, port, addressType, backlog, fd, flags);
  }
}

// 启用监听handle
function setupListenHandle(address, port, addressType, backlog, fd, flags) {
  debug('setupListenHandle', address, port, addressType, backlog, fd);

  // 如同英文注释所说的那样，如果没有监听句柄，则创建，有监听句柄则跳过
  // If there is not yet a handle, we need to create one and bind.
  // In the case of a server sent via IPC, we don't need to do this.
  if (this._handle) {
    debug('setupListenHandle: have a handle already');
  } else {
    debug('setupListenHandle: create a handle');

    let rval = null;

    // 篇幅原因，创建监听句柄的代码...

    this._handle = rval;
  }

  // 在this上设置的faux handle上设置onconnection函数用于监听连接进入
  this._handle.onconnection = onconnection;
}

// lib/internal/cluster/child.js

// 初始化
const cluster = new EventEmitter();
// 存储生成的 faux handle
const handles = new SafeMap();
// 存储监听地址与监听地址index的对应关系
const indexes = new SafeMap();
cluster.isWorker = true;
cluster.isMaster = false;
cluster.worker = null;
cluster.Worker = Worker;

// 子进程启动时会执行该函数，进行初始化，同时在执行完毕后，会删除 env 中的 NODE_UNIQUE_ID 环境变量
// 详细代码见 lib/internal/bootstrap/pre_excution.js 中的 initializeClusterIPC 函数
cluster._setupWorker = function() {
  // 初始化worker实例
  const worker = new Worker({
    id: +process.env.NODE_UNIQUE_ID | 0,
    process: process,
    state: 'online'
  });

  cluster.worker = worker;

  // 处理断开连接事件
  process.once('disconnect', () => {
    worker.emit('disconnect');

    if (!worker.exitedAfterDisconnect) {
      // Unexpected disconnect, master exited, or some such nastiness, so
      // worker exits immediately.
      process.exit(0);
    }
  });

  // IPC 内部通信事件监听
  process.on('internalMessage', internal(worker, onmessage));
  send({ act: 'online' });

  function onmessage(message, handle) {
    // 如果为新连接，则执行 onconnection 函数将得到的句柄传入子进程中启动的HTTP Server
    if (message.act === 'newconn')
      onconnection(message, handle);
    else if (message.act === 'disconnect')
      ReflectApply(_disconnect, worker, [true]);
  }
};

// 添加获取server函数，会在net server监听端口时被执行
// `obj` is a net#Server or a dgram#Socket object.
cluster._getServer = function(obj, options, cb) {
  let address = options.address;

  // Resolve unix socket paths to absolute paths
  if (options.port < 0 && typeof address === 'string' &&
      process.platform !== 'win32')
    address = path.resolve(address);

  // 生成地址信息的的key
  const indexesKey = ArrayPrototypeJoin(
    [
      address,
      options.port,
      options.addressType,
      options.fd,
    ], ':');

  // 检查是否缓存了indexedKey，如果没有，则表明是新的监听地址，在 master.js 中会生成新的net server
  let index = indexes.get(indexesKey);

  if (index === undefined)
    index = 0;
  else
    index++;

  // 设置 indexesKey 与 index的对应关系
  indexes.set(indexesKey, index);

  // 传递地址信息及index
  const message = {
    act: 'queryServer',
    index,
    data: null,
    ...options
  };

  message.address = address;

  // Set custom data on handle (i.e. tls tickets key)
  if (obj._getServerData)
    message.data = obj._getServerData();

  // 向主进程发送queryServer消息
  send(message, (reply, handle) => {
    if (typeof obj._setServerData === 'function')
      obj._setServerData(reply.data);

    // 根据相应负载均衡handle添加worker时的处理，执行相应的负载均衡代码，并执行 cb 函数
    // 轮询是没有传递handle的，对应代码在 RoundRobinHandle.prototype.add 内
    if (handle)
      shared(reply, handle, indexesKey, cb);  // Shared listen socket.
    else
      rr(reply, indexesKey, cb);              // Round-robin.
  });

  obj.once('listening', () => {
    cluster.worker.state = 'listening';
    const address = obj.address();
    message.act = 'listening';
    message.port = (address && address.port) || options.port;
    send(message);
  });
};

// 创建 faux handle，并保存其对应关系
// Round-robin. Master distributes handles across workers.
function rr(message, indexesKey, cb) {
  if (message.errno)
    return cb(message.errno, null);

  let key = message.key;

  function listen(backlog) {
    // TODO(bnoordhuis) Send a message to the master that tells it to
    // update the backlog size. The actual backlog should probably be
    // the largest requested size by any worker.
    return 0;
  }

  function close() {
    // lib/net.js treats server._handle.close() as effectively synchronous.
    // That means there is a time window between the call to close() and
    // the ack by the master process in which we can still receive handles.
    // onconnection() below handles that by sending those handles back to
    // the master.
    if (key === undefined)
      return;

    send({ act: 'close', key });
    handles.delete(key);
    indexes.delete(indexesKey);
    key = undefined;
  }

  function getsockname(out) {
    if (key)
      ObjectAssign(out, message.sockname);

    return 0;
  }

  // 创建Faux handle
  // Faux handle. Mimics a TCPWrap with just enough fidelity to get away
  // with it. Fools net.Server into thinking that it's backed by a real
  // handle. Use a noop function for ref() and unref() because the control
  // channel is going to keep the worker alive anyway.
  const handle = { close, listen, ref: noop, unref: noop };

  if (message.sockname) {
    handle.getsockname = getsockname;  // TCP handles only.
  }

  assert(handles.has(key) === false);
  // 保存faux handle
  handles.set(key, handle);
  // 执行 net 模块调用 cluster._getServer 函数传进来的回调函数
  cb(0, handle);
}

// 处理请求
// Round-robin connection.
function onconnection(message, handle) {
  // 获取faux handle的key
  const key = message.key;
  // 获取faux hadle
  const server = handles.get(key);
  const accepted = server !== undefined;

  send({ ack: message.seq, accepted });

  // 调用在 net 模块中 setupListenHandle 函数里为该 faux handle 设置的连接处理函数处理请求
  if (accepted)
    server.onconnection(0, handle);
}

+---------+           +---------+          +---------+
|  Master |           |  Agent  |          |  Worker |
+---------+           +----+----+          +----+----+
     |      fork agent     |                    |
     +-------------------->|                    |
     |      agent ready    |                    |
     |<--------------------+                    |
     |                     |     fork worker    |
     +----------------------------------------->|
     |     worker ready    |                    |
     |<-----------------------------------------+
     |      Egg ready      |                    |
     +-------------------->|                    |
     |      Egg ready      |                    |
     +----------------------------------------->|
