Skywalking部署及使用

1
tar -zxvf apache-skywalking-apm-6.5.0.tar.gz

1
2
cluster:
  standalone:

1
2
3
4
5
6
7
8
9
10
11
core:
  default:
    # Mixed: Receive agent data, Level 1 aggregate, Level 2 aggregate
    # Receiver: Receive agent data, Level 1 aggregate
    # Aggregator: Level 2 aggregate
    role: ${SW_CORE_ROLE:Mixed} # Mixed/Receiver/Aggregator
    restHost: ${SW_CORE_REST_HOST:0.0.0.0}
    restPort: ${SW_CORE_REST_PORT:12800}
    restContextPath: ${SW_CORE_REST_CONTEXT_PATH:/}
    gRPCHost: ${SW_CORE_GRPC_HOST:0.0.0.0}
    gRPCPort: ${SW_CORE_GRPC_PORT:11800}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
storage:
  elasticsearch:
    nameSpace: ${SW_NAMESPACE:""} #会相应修改es中存储的索引的前缀
    clusterNodes: ${SW_STORAGE_ES_CLUSTER_NODES:172.28.51.150:9200} #es访问地址
    protocol: ${SW_STORAGE_ES_HTTP_PROTOCOL:"http"} #支持http和https#    trustStorePath: ${SW_SW_STORAGE_ES_SSL_JKS_PATH:"../es_keystore.jks"}#    trustStorePass: ${SW_SW_STORAGE_ES_SSL_JKS_PASS:""}
    user: ${SW_ES_USER:"elastic"}
    password: ${SW_ES_PASSWORD:"XXXXX"}
    indexShardsNumber: ${SW_STORAGE_ES_INDEX_SHARDS_NUMBER:2}
    indexReplicasNumber: ${SW_STORAGE_ES_INDEX_REPLICAS_NUMBER:0}
    # Those data TTL settings will override the same settings in core module.
    recordDataTTL: ${SW_STORAGE_ES_RECORD_DATA_TTL:7} # Unit is day
    otherMetricsDataTTL: ${SW_STORAGE_ES_OTHER_METRIC_DATA_TTL:45} # Unit is day
    monthMetricsDataTTL: ${SW_STORAGE_ES_MONTH_METRIC_DATA_TTL:18} # Unit is month
    # Batch process setting, refer to https://www.elastic.co/guide/en/elasticsearch/client/java-api/5.5/java-docs-bulk-processor.html
    bulkActions: ${SW_STORAGE_ES_BULK_ACTIONS:1000} # Execute the bulk every 1000 requests
    flushInterval: ${SW_STORAGE_ES_FLUSH_INTERVAL:10} # flush the bulk every 10 seconds whatever the number of requests
    concurrentRequests: ${SW_STORAGE_ES_CONCURRENT_REQUESTS:2} # the number of concurrent requests
    resultWindowMaxSize: ${SW_STORAGE_ES_QUERY_MAX_WINDOW_SIZE:10000}
    metadataQueryMaxSize: ${SW_STORAGE_ES_QUERY_MAX_SIZE:5000}
    segmentQueryMaxSize: ${SW_STORAGE_ES_QUERY_SEGMENT_SIZE:200}

1
2
3
4
thread_pool.index.queue_size: 1000 #只适用于ElasticSearch 6
thread_pool.write.queue_size: 1000 #适用于ElasticSearch 6 and 7

index.max_result_window: 1000000 #trace页面出错时记得设置

1
2
3
4
5
6
7
8
9
server:
  port: 8080 #访问页面使用的端口

collector:
  path: /graphql
  ribbon:
    ReadTimeout: 10000
    # Point to all backend's restHost:restPort, split by ,
    listOfServers: 127.0.0.1:12800

1
2
3
4
5
6
7
8
9
10
#!/usr/bin/env sh

PRG="$0"
PRGDIR=`dirname "$PRG"`
OAP_EXE=oapService.sh
WEBAPP_EXE=webappService.sh

"$PRGDIR"/"$OAP_EXE"

"$PRGDIR"/"$WEBAPP_EXE"

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
# 不同的namespace会导致调用链路追踪中断
agent.namespace=${SW_AGENT_NAMESPACE:hmall}

# 页面上展示的service的名称，也可以通过-Dskywalking.agent.service_name=xxx指定
agent.service_name=${SW_AGENT_NAME:gateway}

# 平台的调用地址，也可以通过-Dskywalking.collector.backend_service=127.0.0.1:80指定
collector.backend_service=${SW_AGENT_COLLECTOR_BACKEND_SERVICES:172.28.51.141:11800}

# 忽略指定后缀的请求收集
agent.ignore_suffix=${SW_AGENT_IGNORE_SUFFIX:.jpg,.jpeg,.js,.css,.png,.bmp,.gif,.ico,.mp3,.mp4,.html,.svg}


# 每3秒的采样率，负数代表100%
agent.sample_n_per_3_secs=${SW_AGENT_SAMPLE:-1}
