Scrapy-redis爬虫分布式爬取的分析和实现

import redis
import six
from scrapy.utils.misc import load_object
DEFAULT_REDIS_CLS = redis.StrictRedis
# Sane connection defaults.
DEFAULT_PARAMS = {
 'socket_timeout': 30,
 'socket_connect_timeout': 30,
 'retry_on_timeout': True,
}
# Shortcut maps 'setting name' -> 'parmater name'.
SETTINGS_PARAMS_MAP = {
 'REDIS_URL': 'url',
 'REDIS_HOST': 'host',
 'REDIS_PORT': 'port',
}
def get_redis_from_settings(settings):
 """Returns a redis client instance from given Scrapy settings object.
 This function uses ``get_client`` to instantiate the client and uses
 ``DEFAULT_PARAMS`` global as defaults values for the parameters. You can
 override them using the ``REDIS_PARAMS`` setting.
 Parameters
 ----------
 settings : Settings
  A scrapy settings object. See the supported settings below.
 Returns
 -------
 server
  Redis client instance.
 Other Parameters
 ----------------
 REDIS_URL : str, optional
  Server connection URL.
 REDIS_HOST : str, optional
  Server host.
 REDIS_PORT : str, optional
  Server port.
 REDIS_PARAMS : dict, optional
  Additional client parameters.
 """
 params = DEFAULT_PARAMS.copy()
 params.update(settings.getdict('REDIS_PARAMS'))
 # XXX: Deprecate REDIS_* settings.
 for source, dest in SETTINGS_PARAMS_MAP.items():
  val = settings.get(source)
  if val:
   params[dest] = val
 # Allow ``redis_cls`` to be a path to a class.
 if isinstance(params.get('redis_cls'), six.string_types):
  params['redis_cls'] = load_object(params['redis_cls'])
 return get_redis(**params)
# Backwards compatible alias.
from_settings = get_redis_from_settings
def get_redis(**kwargs):
 """Returns a redis client instance.
 Parameters
 ----------
 redis_cls : class, optional
  Defaults to ``redis.StrictRedis``.
 url : str, optional
  If given, ``redis_cls.from_url`` is used to instantiate the class.
 **kwargs
  Extra parameters to be passed to the ``redis_cls`` class.
 Returns
 -------
 server
  Redis client instance.
 """
 redis_cls = kwargs.pop('redis_cls', DEFAULT_REDIS_CLS)
 url = kwargs.pop('url', None)
 if url:
  return redis_cls.from_url(url, **kwargs)
 else:
  return redis_cls(**kwargs)

import logging
import time
from scrapy.dupefilters import BaseDupeFilter
from scrapy.utils.request import request_fingerprint
from .connection import get_redis_from_settings
DEFAULT_DUPEFILTER_KEY = "dupefilter:%(timestamp)s"
logger = logging.getLogger(__name__)
# TODO: Rename class to RedisDupeFilter.
class RFPDupeFilter(BaseDupeFilter):
 """Redis-based request duplicates filter.
 This class can also be used with default Scrapy's scheduler.
 """
 logger = logger
 def __init__(self, server, key, debug=False):
  """Initialize the duplicates filter.
  Parameters
  ----------
  server : redis.StrictRedis
   The redis server instance.
  key : str
   Redis key Where to store fingerprints.
  debug : bool, optional
   Whether to log filtered requests.
  """
  self.server = server
  self.key = key
  self.debug = debug
  self.logdupes = True
 @classmethod
 def from_settings(cls, settings):
  """Returns an instance from given settings.
  This uses by default the key ``dupefilter:<timestamp>``. When using the
  ``scrapy_redis.scheduler.Scheduler`` class, this method is not used as
  it needs to pass the spider name in the key.
  Parameters
  ----------
  settings : scrapy.settings.Settings
  Returns
  -------
  RFPDupeFilter
   A RFPDupeFilter instance.
  """
  server = get_redis_from_settings(settings)
  # XXX: This creates one-time key. needed to support to use this
  # class as standalone dupefilter with scrapy's default scheduler
  # if scrapy passes spider on open() method this wouldn't be needed
  # TODO: Use SCRAPY_JOB env as default and fallback to timestamp.
  key = DEFAULT_DUPEFILTER_KEY % {'timestamp': int(time.time())}
  debug = settings.getbool('DUPEFILTER_DEBUG')
  return cls(server, key=key, debug=debug)
 @classmethod
 def from_crawler(cls, crawler):
  """Returns instance from crawler.
  Parameters
  ----------
  crawler : scrapy.crawler.Crawler
  Returns
  -------
  RFPDupeFilter
   Instance of RFPDupeFilter.
  """
  return cls.from_settings(crawler.settings)
 def request_seen(self, request):
  """Returns True if request was already seen.
  Parameters
  ----------
  request : scrapy.http.Request
  Returns
  -------
  bool
  """
  fp = self.request_fingerprint(request)
  # This returns the number of values added, zero if already exists.
  added = self.server.sadd(self.key, fp)
  return added == 0
 def request_fingerprint(self, request):
  """Returns a fingerprint for a given request.
  Parameters
  ----------
  request : scrapy.http.Request
  Returns
  -------
  str
  """
  return request_fingerprint(request)
 def close(self, reason=''):
  """Delete data on close. Called by Scrapy's scheduler.
  Parameters
  ----------
  reason : str, optional
  """
  self.clear()
 def clear(self):
  """Clears fingerprints data."""
  self.server.delete(self.key)
 def log(self, request, spider):
  """Logs given request.
  Parameters
  ----------
  request : scrapy.http.Request
  spider : scrapy.spiders.Spider
  """
  if self.debug:
   msg = "Filtered duplicate request: %(request)s"
   self.logger.debug(msg, {'request': request}, extra={'spider': spider})
  elif self.logdupes:
   msg = ("Filtered duplicate request %(request)s"
     " - no more duplicates will be shown"
     " (see DUPEFILTER_DEBUG to show all duplicates)")
   msg = "Filtered duplicate request: %(request)s"
   self.logger.debug(msg, {'request': request}, extra={'spider': spider})
   self.logdupes = False

from scrapy.utils.reqser import request_to_dict, request_from_dict
from . import picklecompat
class Base(object):
 """Per-spider queue/stack base class"""
 def __init__(self, server, spider, key, serializer=None):
  """Initialize per-spider redis queue.
  Parameters:
   server -- redis connection
   spider -- spider instance
   key -- key for this queue (e.g. "%(spider)s:queue")
  """
  if serializer is None:
   # Backward compatibility.
   # TODO: deprecate pickle.
   serializer = picklecompat
  if not hasattr(serializer, 'loads'):
   raise TypeError("serializer does not implement 'loads' function: %r"
       % serializer)
  if not hasattr(serializer, 'dumps'):
   raise TypeError("serializer '%s' does not implement 'dumps' function: %r"
       % serializer)
  self.server = server
  self.spider = spider
  self.key = key % {'spider': spider.name}
  self.serializer = serializer
 def _encode_request(self, request):
  """Encode a request object"""
  obj = request_to_dict(request, self.spider)
  return self.serializer.dumps(obj)
 def _decode_request(self, encoded_request):
  """Decode an request previously encoded"""
  obj = self.serializer.loads(encoded_request)
  return request_from_dict(obj, self.spider)
 def __len__(self):
  """Return the length of the queue"""
  raise NotImplementedError
 def push(self, request):
  """Push a request"""
  raise NotImplementedError
 def pop(self, timeout=0):
  """Pop a request"""
  raise NotImplementedError
 def clear(self):
  """Clear queue/stack"""
  self.server.delete(self.key)
class SpiderQueue(Base):
 """Per-spider FIFO queue"""
 def __len__(self):
  """Return the length of the queue"""
  return self.server.llen(self.key)
 def push(self, request):
  """Push a request"""
  self.server.lpush(self.key, self._encode_request(request))
 def pop(self, timeout=0):
  """Pop a request"""
  if timeout > 0:
   data = self.server.brpop(self.key, timeout)
   if isinstance(data, tuple):
    data = data[1]
  else:
   data = self.server.rpop(self.key)
  if data:
   return self._decode_request(data)
class SpiderPriorityQueue(Base):
 """Per-spider priority queue abstraction using redis' sorted set"""
 def __len__(self):
  """Return the length of the queue"""
  return self.server.zcard(self.key)
 def push(self, request):
  """Push a request"""
  data = self._encode_request(request)
  score = -request.priority
  # We don't use zadd method as the order of arguments change depending on
  # whether the class is Redis or StrictRedis, and the option of using
  # kwargs only accepts strings, not bytes.
  self.server.execute_command('ZADD', self.key, score, data)
 def pop(self, timeout=0):
  """
  Pop a request
  timeout not support in this queue class
  """
  # use atomic range/remove using multi/exec
  pipe = self.server.pipeline()
  pipe.multi()
  pipe.zrange(self.key, 0, 0).zremrangebyrank(self.key, 0, 0)
  results, count = pipe.execute()
  if results:
   return self._decode_request(results[0])
class SpiderStack(Base):
 """Per-spider stack"""
 def __len__(self):
  """Return the length of the stack"""
  return self.server.llen(self.key)
 def push(self, request):
  """Push a request"""
  self.server.lpush(self.key, self._encode_request(request))
 def pop(self, timeout=0):
  """Pop a request"""
  if timeout > 0:
   data = self.server.blpop(self.key, timeout)
   if isinstance(data, tuple):
    data = data[1]
  else:
   data = self.server.lpop(self.key)
  if data:
   return self._decode_request(data)
__all__ = ['SpiderQueue', 'SpiderPriorityQueue', 'SpiderStack']

"""A pickle wrapper module with protocol=-1 by default."""
try:
 import cPickle as pickle # PY2
except ImportError:
 import pickle
def loads(s):
 return pickle.loads(s)
def dumps(obj):
return pickle.dumps(obj, protocol=-1)

from scrapy.utils.misc import load_object
from scrapy.utils.serialize import ScrapyJSONEncoder
from twisted.internet.threads import deferToThread
from . import connection
default_serialize = ScrapyJSONEncoder().encode
class RedisPipeline(object):
 """Pushes serialized item into a redis list/queue"""
 def __init__(self, server,
     key='%(spider)s:items',
     serialize_func=default_serialize):
  self.server = server
  self.key = key
  self.serialize = serialize_func
 @classmethod
 def from_settings(cls, settings):
  params = {
   'server': connection.from_settings(settings),
  }
  if settings.get('REDIS_ITEMS_KEY'):
   params['key'] = settings['REDIS_ITEMS_KEY']
  if settings.get('REDIS_ITEMS_SERIALIZER'):
   params['serialize_func'] = load_object(
    settings['REDIS_ITEMS_SERIALIZER']
   )
  return cls(**params)
 @classmethod
 def from_crawler(cls, crawler):
  return cls.from_settings(crawler.settings)
 def process_item(self, item, spider):
  return deferToThread(self._process_item, item, spider)
 def _process_item(self, item, spider):
  key = self.item_key(item, spider)
  data = self.serialize(item)
  self.server.rpush(key, data)
  return item
 def item_key(self, item, spider):
  """Returns redis key based on given spider.
  Override this function to use a different key depending on the item
  and/or spider.
  """
  return self.key % {'spider': spider.name}

import importlib
import six
from scrapy.utils.misc import load_object
from . import connection
# TODO: add SCRAPY_JOB support.
class Scheduler(object):
 """Redis-based scheduler"""
 def __init__(self, server,
     persist=False,
     flush_on_start=False,
     queue_key='%(spider)s:requests',
     queue_cls='scrapy_redis.queue.SpiderPriorityQueue',
     dupefilter_key='%(spider)s:dupefilter',
     dupefilter_cls='scrapy_redis.dupefilter.RFPDupeFilter',
     idle_before_close=0,
     serializer=None):
  """Initialize scheduler.
  Parameters
  ----------
  server : Redis
   The redis server instance.
  persist : bool
   Whether to flush requests when closing. Default is False.
  flush_on_start : bool
   Whether to flush requests on start. Default is False.
  queue_key : str
   Requests queue key.
  queue_cls : str
   Importable path to the queue class.
  dupefilter_key : str
   Duplicates filter key.
  dupefilter_cls : str
   Importable path to the dupefilter class.
  idle_before_close : int
   Timeout before giving up.
  """
  if idle_before_close < 0:
   raise TypeError("idle_before_close cannot be negative")
  self.server = server
  self.persist = persist
  self.flush_on_start = flush_on_start
  self.queue_key = queue_key
  self.queue_cls = queue_cls
  self.dupefilter_cls = dupefilter_cls
  self.dupefilter_key = dupefilter_key
  self.idle_before_close = idle_before_close
  self.serializer = serializer
  self.stats = None
 def __len__(self):
  return len(self.queue)
 @classmethod
 def from_settings(cls, settings):
  kwargs = {
   'persist': settings.getbool('SCHEDULER_PERSIST'),
   'flush_on_start': settings.getbool('SCHEDULER_FLUSH_ON_START'),
   'idle_before_close': settings.getint('SCHEDULER_IDLE_BEFORE_CLOSE'),
  }
  # If these values are missing, it means we want to use the defaults.
  optional = {
   # TODO: Use custom prefixes for this settings to note that are
   # specific to scrapy-redis.
   'queue_key': 'SCHEDULER_QUEUE_KEY',
   'queue_cls': 'SCHEDULER_QUEUE_CLASS',
   'dupefilter_key': 'SCHEDULER_DUPEFILTER_KEY',
   # We use the default setting name to keep compatibility.
   'dupefilter_cls': 'DUPEFILTER_CLASS',
   'serializer': 'SCHEDULER_SERIALIZER',
  }
  for name, setting_name in optional.items():
   val = settings.get(setting_name)
   if val:
    kwargs[name] = val
  # Support serializer as a path to a module.
  if isinstance(kwargs.get('serializer'), six.string_types):
   kwargs['serializer'] = importlib.import_module(kwargs['serializer'])
  server = connection.from_settings(settings)
  # Ensure the connection is working.
  server.ping()
  return cls(server=server, **kwargs)
 @classmethod
 def from_crawler(cls, crawler):
  instance = cls.from_settings(crawler.settings)
  # FIXME: for now, stats are only supported from this constructor
  instance.stats = crawler.stats
  return instance
 def open(self, spider):
  self.spider = spider
  try:
   self.queue = load_object(self.queue_cls)(
    server=self.server,
    spider=spider,
    key=self.queue_key % {'spider': spider.name},
    serializer=self.serializer,
   )
  except TypeError as e:
   raise ValueError("Failed to instantiate queue class '%s': %s",
        self.queue_cls, e)
  try:
   self.df = load_object(self.dupefilter_cls)(
    server=self.server,
    key=self.dupefilter_key % {'spider': spider.name},
    debug=spider.settings.getbool('DUPEFILTER_DEBUG'),
   )
  except TypeError as e:
   raise ValueError("Failed to instantiate dupefilter class '%s': %s",
        self.dupefilter_cls, e)
  if self.flush_on_start:
   self.flush()
  # notice if there are requests already in the queue to resume the crawl
  if len(self.queue):
   spider.log("Resuming crawl (%d requests scheduled)" % len(self.queue))
 def close(self, reason):
  if not self.persist:
   self.flush()
 def flush(self):
  self.df.clear()
  self.queue.clear()
 def enqueue_request(self, request):
  if not request.dont_filter and self.df.request_seen(request):
   self.df.log(request, self.spider)
   return False
  if self.stats:
   self.stats.inc_value('scheduler/enqueued/redis', spider=self.spider)
  self.queue.push(request)
  return True
 def next_request(self):
  block_pop_timeout = self.idle_before_close
  request = self.queue.pop(block_pop_timeout)
  if request and self.stats:
   self.stats.inc_value('scheduler/dequeued/redis', spider=self.spider)
  return request
 def has_pending_requests(self):
  return len(self) > 0

from scrapy import signals
from scrapy.exceptions import DontCloseSpider
from scrapy.spiders import Spider, CrawlSpider
from . import connection
class RedisMixin(object):
 """Mixin class to implement reading urls from a redis queue."""
 redis_key = None # If empty, uses default '<spider>:start_urls'.
 # Fetch this amount of start urls when idle.
 redis_batch_size = 100
 # Redis client instance.
 server = None
 def start_requests(self):
  """Returns a batch of start requests from redis."""
  return self.next_requests()
 def setup_redis(self, crawler=None):
  """Setup redis connection and idle signal.
  This should be called after the spider has set its crawler object.
  """
  if self.server is not None:
   return
  if crawler is None:
   # We allow optional crawler argument to keep backwrads
   # compatibility.
   # XXX: Raise a deprecation warning.
   assert self.crawler, "crawler not set"
   crawler = self.crawler
  if not self.redis_key:
   self.redis_key = '%s:start_urls' % self.name
  self.log("Reading URLs from redis key '%s'" % self.redis_key)
  self.redis_batch_size = self.settings.getint(
   'REDIS_START_URLS_BATCH_SIZE',
   self.redis_batch_size,
  )
  self.server = connection.from_settings(crawler.settings)
  # The idle signal is called when the spider has no requests left,
  # that's when we will schedule new requests from redis queue
  crawler.signals.connect(self.spider_idle, signal=signals.spider_idle)
 def next_requests(self):
  """Returns a request to be scheduled or none."""
  use_set = self.settings.getbool('REDIS_START_URLS_AS_SET')
  fetch_one = self.server.spop if use_set else self.server.lpop
  # XXX: Do we need to use a timeout here?
  found = 0
  while found < self.redis_batch_size:
   data = fetch_one(self.redis_key)
   if not data:
    # Queue empty.
    break
   yield self.make_request_from_data(data)
   found += 1
  if found:
   self.logger.debug("Read %s requests from '%s'", found, self.redis_key)
 def make_request_from_data(self, data):
  # By default, data is an URL.
  if '://' in data:
   return self.make_requests_from_url(data)
  else:
   self.logger.error("Unexpected URL from '%s': %r", self.redis_key, data)
 def schedule_next_requests(self):
  """Schedules a request if available"""
  for req in self.next_requests():
   self.crawler.engine.crawl(req, spider=self)
 def spider_idle(self):
  """Schedules a request if available, otherwise waits."""
  # XXX: Handle a sentinel to close the spider.
  self.schedule_next_requests()
  raise DontCloseSpider
class RedisSpider(RedisMixin, Spider):
 """Spider that reads urls from redis queue when idle."""
 @classmethod
 def from_crawler(self, crawler):
  obj = super(RedisSpider, self).from_crawler(crawler)
  obj.setup_redis(crawler)
  return obj
class RedisCrawlSpider(RedisMixin, CrawlSpider):
 """Spider that reads urls from redis queue when idle."""
 @classmethod
 def from_crawler(self, crawler):
  obj = super(RedisCrawlSpider, self).from_crawler(crawler)
  obj.setup_redis(crawler)
  return obj

{
 priority0:队列0
 priority1:队列2
 priority2:队列2
}
