【C/C++】BITMAP格式分析

1
2
3
4
5
6
7
typedef struct tagBITMAPFILEHEADER {
        WORD    bfType;
        DWORD   bfSize;
        WORD    bfReserved1;
        WORD    bfReserved2;
        DWORD   bfOffBits;
} BITMAPFILEHEADER, FAR *LPBITMAPFILEHEADER, *PBITMAPFILEHEADER;

1
2
3
4
5
6
7
8
9
10
11
12
13
typedef struct tagBITMAPINFOHEADER{
        DWORD      biSize;
        LONG       biWidth;
        LONG       biHeight;
        WORD       biPlanes;
        WORD       biBitCount;
        DWORD      biCompression;
        DWORD      biSizeImage;
        LONG       biXPelsPerMeter;
        LONG       biYPelsPerMeter;
        DWORD      biClrUsed;
        DWORD      biClrImportant;
} BITMAPINFOHEADER, FAR *LPBITMAPINFOHEADER, *PBITMAPINFOHEADER;

1
2
3
4
5
6
typedef struct tagRGBQUAD {
        BYTE    rgbBlue;             //该颜色蓝色分量
        BYTE    rgbGreen;            //该绿色蓝色分量
        BYTE    rgbRed;              //该红色蓝色分量
        BYTE    rgbReserved;         //保留
} RGBQUAD;

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
#include <stdio.h>
#include <stdlib.h>
#include <windows.h>

#pragma pack(push)
#pragma pack(1)

//24位真彩色
struct RGB
{
    BYTE			b;
    BYTE			g;
    BYTE			r;
};

#pragma pack(pop)

void imgOpr(RGB &a, RGB &b)
{
    b.b = a.b;
    b.g = a.g;
    b.r = a.r;
}

//二维数组申请img[m][n]
RGB ** RGB_new(int m, int n)
{
	int					i;
	RGB					**img;

	img = new RGB * [m];

	for (i = 0; i < m; i ++)
	{
		img[i] = new RGB [n];
	}

	return img;
}

//释放img[m][n]
void RGB_delete(RGB **img, int m, int n)
{
	int					i;

	for (i = 0; i < m; i ++)
	{
		delete [] img[i];
	}

	delete [] img;
}

int main()
{
    BITMAPFILEHEADER	bfh;
    BITMAPINFOHEADER	bih;

	RGB					**img1;
    RGB					**img2;
	BYTE				*tmp;

	int					i, j;
    int					height, width;
	int					m, n;

    FILE				*fp, *fq;
	errno_t				err;

	err = fopen_s(&fp, "D:\Work\Debug\7.bmp", "rb");

	if (err == 0)
	{
		printf("The input file was opened!n");
	}
	else
	{
		printf("The input file was not opened!n");
		return 1;
	}

	err = fopen_s(&fq, "D:\Work\Debug\2.bmp", "wb");

	if (err == 0)
	{
		printf("The output file was opened!n");
	}
	else
	{
		printf("The output file was not opened!n");
		return 1;
	}

    fread(&bfh, sizeof(BITMAPFILEHEADER), 1, fp);
    fread(&bih, sizeof(BITMAPINFOHEADER), 1, fp);

	height = bih.biHeight;
    width = bih.biWidth;

	img1 = RGB_new(height, width);
	img2 = RGB_new(width, height);

	//计算每行图像字节数，必须是4的整倍数，不够需要填充
	m = (bih.biWidth * bih.biBitCount + 31) / 32 * 4;
	n = (bih.biHeight * bih.biBitCount + 31) / 32 * 4;

	tmp = new BYTE [n];
	memset(tmp, 0x0, n);

    //对图片进行操作
	for (i = 0; i < height; i ++)
	{
		//跳过调色板数据段，并寻址
		fseek(fp, bfh.bfOffBits + i * m, SEEK_SET);
		fread(img1[i], sizeof(RGB), width, fp);

		for (j = 0; j < width; j ++)
		{
			//将数组 img 赋值给 img2
			imgOpr(img1[i][j], img2[j][i]);
		}
	}

	//更新BITMAPINFOHEADER结构体
	bih.biHeight = width;
	bih.biWidth = height;
	bih.biSizeImage = n * width;

	//将修改后的图片保存到文件
	fwrite(&bfh, sizeof(BITMAPFILEHEADER), 1, fq);
	fwrite(&bih, sizeof(BITMAPINFOHEADER), 1, fq);

	for (i = 0; i < width; i ++)
	{
		memcpy(tmp, img2[i], sizeof(RGB) * height);
		fwrite(tmp, 1, n, fq);
	}

    fclose(fp);
    fclose(fq);

	//释放
	RGB_delete(img1, height, width);
	RGB_delete(img2, width, height);

	delete [] tmp;

	system("pause");

    return 0;
}
