10-5 共享存储 --- PV、PVC和StorageClass（下）

给node gluster-01 02 03 打标签

kubectl label node gluster-01 storagenode=glusterfs

kubectl label node gluster-02 storagenode=glusterfs

kubectl label node gluster-03 storagenode=glusterfs

创建服务

kubectl apply -f glusterfs-daemonset.yaml

查看服务是否已经成功启动

kubectl get pods -o wide

这里如果创建慢的话也需要先执行

docker pull gluster/gluster-centos:latest

通过heketi 初始化磁盘

创建heketi-security.yaml

apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: heketi-clusterrolebinding
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: heketi-clusterrole
subjects:
- kind: ServiceAccount
  name: heketi-service-account
  namespace: default


---


apiVersion: v1
kind: ServiceAccount
metadata:
  name: heketi-service-account
  namespace: default


---


apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
  name: heketi-clusterrole
rules:
- apiGroups:
  - ""
  resources:
  - pods
  - pods/status
  - pods/exec
  verbs:
  - get
  - list
  - watch
  - cre

创建heketi-deployment.yaml

kind: Service
apiVersion: v1
metadata:
  name: heketi
  labels:
    glusterfs: heketi-service
    deploy-heketi: support
  annotations:
    description: Exposes Heketi Service
spec:
  selector:
    name: heketi
  ports:
  - name: heketi
    port: 80
    targetPort: 8080


---


apiVersion: v1
kind: ConfigMap
metadata:
  name: tcp-services
  namespace: ingress-nginx
data:
  "30001": default/heketi:80


---


kind: Deployment
apiVersion: extensions/v1beta1
metadata:
  name: heketi
  labels:
    glusterfs: heketi-deployment
  annotations:
    description: Defines how to deploy Heketi
spec:
  replicas: 1
  template:
    metadata:
      name: heketi
      labels:
        name: heketi
        glusterfs: heketi-pod
    spec:
      serviceAccountName: heketi-service-account
      containers:
      - image: heketi/heketi:dev
        imagePullPolicy: Always
        name: heketi
        env:
        - name: HEKETI_EXECUTOR
          value: "kubernetes"
        - name: HEKETI_DB_PATH
          value: "/var/lib/heketi/heketi.db"
        - name: HEKETI_FSTAB
          value: "/var/lib/heketi/fstab"
        - name: HEKETI_SNAPSHOT_LIMIT
          value: "14"
        - name: HEKETI_KUBE_GLUSTER_DAEMONSET
          value: "y"
        ports:
        - containerPort: 8080
        volumeMounts:
        - name: db
          mountPath: /var/lib/heketi
        readinessProbe:
          timeoutSeconds: 3
          initialDelaySeconds: 3
          httpGet:
            path: /hello
            port: 8080
        livenessProbe:
          timeoutSeconds: 3
          initialDelaySeconds: 30
          httpGet:
            path: /hello
            port: 8080
      volumes:
      - name: db
        hostPath:
          path: "/heketi-da

创建

kubectl apply -f heketi-security.yaml

kubectl apply -f heketi-deployment.yaml

kubectl get pods -o wide

服务启动在01上去01上查看

docker ps |grep heketi

docker exec -it be85ba51835d bash

执行

export HEKETI_CLI_SERVER=http://localhost:8080

修改topology.json如下修改ip和设备名

{
  "clusters": [
    {
      "nodes": [
        {
          "node": {
            "hostnames": {
              "manage": [
                "gluster-01"
              ],
              "storage": [
                "192.168.10.165"
              ]
            },
            "zone": 1
          },
          "devices": [
            {
              "name": "/dev/sdc",
              "destroydata": false
            }
          ]
        },
        {
          "node": {
            "hostnames": {
              "manage": [
                "gluster-02"
              ],
              "storage": [
                "192.168.10.166"
              ]
            },
            "zone": 1
          },
          "devices": [
            {
              "name": "/dev/sdc",
              "destroydata": false
            }
          ]
        },
        {
          "node": {
            "hostnames": {
              "manage": [
                "gluster-03"
              ],
              "storage": [
                "192.168.10.167"
              ]
            },
            "zone": 1
          },
          "devices": [
            {
              "name": "/dev/sdc",
              "destroydata": false
            }
          ]
        }
      ]
    }
  ]
}

在刚刚登陆的容器里创建一个文件topology.json内容如上所示

在容器里执行初始化

#heketi-cli topology load --json tolopogy.json

新版本的heketi在创建gfs集群时需要带上参数，声明用户名及密码，相应值在heketi.json文件中配置

heketi-cli -s $HEKETI_CLI_SERVER --user admin --secret 'My Secret' topology load --json=topology.json

heketi-cli --user admin --secret 'My Secret' topology info

查看集群信息

端口起来了

进入glusterd容器查看集群状态

创建glusterfs-storage-class.yaml

apiVersion: storage.k8s.io/v1
kind: StorageClass
metadata:
  name: glusterfs-storage-class
provisioner: kubernetes.io/glusterfs
parameters:
# ingress地址 和 需要暴露的端口
  resturl: "http://192.168.10.150:30001"
  restauthenabled: "false"

kubectl apply -f glusterfs-storage-class.yaml

创建一个pvc

glusterfs-pvc.yaml

kind: PersistentVolumeClaim
apiVersion: v1
metadata:
  name: glusterfs-pvc
spec:
  storageClassName: glusterfs-storage-class
  accessModes:
    - ReadWriteOnce
  resources:
    requests:
      storage: 1Gi

中途遇到了报错 pvc一直处于pending状态查看状态报错如下。环境因为测试已经铲掉几次可能gluster的ip 已经变化了。

修改 glusterfs-storage-class.yaml如下

apiVersion: storage.k8s.io/v1
kind: StorageClass
metadata:
  name: glusterfs-storage-class
provisioner: kubernetes.io/glusterfs
parameters:
  resturl: "http://192.168.10.150:30001"
# 此处需要根据自己的clusterid修改
  clusterid: "5565c348a317750e6432c6d27fc2dd30"
  restauthenabled: "true"
  restuser: "admin"
  secretNamespace: "default"
  secretName: "heketi-secret"
  gidMin: "40000"
  gidMax: "50000"
  volumetype: "replicate:3"

通过进入heketi容器使用heketi-cli --user admin --secret 'My Secret' topology info 命令获取clusterid

查看pv和pvc

kubectl get pv

kubectl get pvc

查看pvc的信息

kubectl get pvc glusterfs-pvc -o yaml

创建pod

web-deploy.yaml

#deploy
apiVersion: apps/v1
kind: Deployment
metadata:
  name: web-deploy
spec:
  strategy:
    rollingUpdate:
      maxSurge: 25%
      maxUnavailable: 25%
    type: RollingUpdate
  selector:
    matchLabels:
      app: web-deploy
  replicas: 2
  template:
    metadata:
      labels:
        app: web-deploy
    spec:
      containers:
      - name: web-deploy
        image: harbor.pdabc.com/kubernetes/springboot-web:v1
        ports:
        - containerPort: 8080
        volumeMounts:
          - name: gluster-volume
            mountPath: "/mooc-data"
            readOnly: false
      volumes:
      - name: gluster-volume
        persistentVolumeClaim:
          claimName: glusterfs-pvc

kubectl apply -f web-deploy.yaml
