我是靠谱客的博主缓慢诺言，最近开发中收集的这篇文章主要介绍C#实现窗体中的各个控件同比自动放缩大小，觉得挺不错的，现在分享给大家，希望可以做个参考。

概述

实现方式主要是利用panel控件为主题，对于每个控件的大小位置和字体这几个属性进行记录，然后根据窗体改变的大小同时放缩。

简要步骤如下：

1、创建C#窗体程序项目。
2、Panel放置到窗体。
3、设置属性dock为fill。
4、注意MinnumSize不能设置为0，改成大于0都行。

复制代码代码如下:

public partial class FrmDemo : Form

    {

        double dFrmWidth;

        double dFrmHeight;

        double dZoomHorizon;

        double dZoomVerticality;

        Dictionary<string, string> dicControlsAttribute = new Dictionary<string, string>();

        protected void GetAllInitiateContrlInfo(Control CrlContainer)

        {

            if (CrlContainer.Parent == this)

            {

                dFrmWidth = Convert.ToDouble(CrlContainer.Width);

                dFrmHeight = Convert.ToDouble(CrlContainer.Height);

            }

            foreach (Control item in CrlContainer.Controls)

            {

                if (item.Name.Trim() != "")

                    dicControlsAttribute.Add(item.Name, (item.Left + item.Width / 2) + "," + (item.Top + item.Height / 2)

                                             + "," + item.Width + "," + item.Height + "," + item.Font.Size);

                if ((item as UserControl) == null && item.Controls.Count > 0)

                    GetAllInitiateContrlInfo(item);

            }

        }

        private void ChangeControlsInitiate(Control CrlContainer)

        {

            dZoomHorizon = (Convert.ToDouble(CrlContainer.Width) / dFrmWidth);

            dZoomVerticality = (Convert.ToDouble(CrlContainer.Height) / dFrmHeight);

        }

        private void ChangeCurrentControlAttr(Control CrlContainer)

        {

            double[] dPosition = new double[5];

            foreach (Control item in CrlContainer.Controls)

            {

                if (item.Name.Trim() != "")

                {

                    if ((item as UserControl) == null && item.Controls.Count > 0)

                        ChangeCurrentControlAttr(item);

                    string[] strs = dicControlsAttribute[item.Name].Split(',');

                    for (int j = 0; j < 5; j++)

                    {

                        dPosition[j] = Convert.ToDouble(strs[j]);

                    }

                    double itemWidth = dPosition[2] * dZoomHorizon;

                    double itemHeight = dPosition[3] * dZoomVerticality;

                    item.Left = Convert.ToInt32(dPosition[0] * dZoomHorizon - itemWidth / 2);

                    item.Top = Convert.ToInt32(dPosition[1] * dZoomVerticality - itemHeight / 2);

                    item.Width = Convert.ToInt32(itemWidth);

                    item.Height = Convert.ToInt32(itemHeight);

                    //item.Font = new Font(item.Font.Name, float.Parse

                    //((dPosition[4] * Math.Min(dZoomHorizon, dZoomVerticality)).ToString()));

                    //字体也可以实现同比放缩。

                     }

            }

        }

        protected override void OnSizeChanged(EventArgs e)

        {

            base.OnSizeChanged(e);

            if (dicControlsAttribute.Count > 0)

            {

                ChangeControlsInitiate(this.Controls[0]);

                ChangeCurrentControlAttr(this.Controls[0]);

            }

        }

        public FrmDemo()

        {

            InitializeComponent();

            GetAllInitiateContrlInfo(this.Controls[0]);//构造函数里面调用即可。

        }

}
