SpringFox Swagger2注解基本用法

66 阅读 0 评论 44 点赞

我是靠谱客的博主迷人云朵，最近开发中收集的这篇文章主要介绍SpringFox Swagger2注解基本用法，觉得挺不错的，现在分享给大家，希望可以做个参考。

概述

一切参数说明，参考官方API文档：http://docs.swagger.io/swagger-core/current/apidocs/index.html?io/swagger/annotations

在实体和API注释这块，有些注释不一定在页面上表现，但是接口返回的数据上全部都有返回。

Swagger2出自SpringFOX，官网：https://github.com/springfox/springfox，而与https://swagger.io/不同，所以在https://swagger.io/上是找不到Swagger2的开发文档。

在Swagger2的GitHUb页面上也没提供相关的详细文档，不过可以参考示例代码库https://github.com/springfox/springfox-demos进行参考。

不过下面这些网址还能找到关于Swagger的先关API文档，并且兼容Swagger2的：

http://docs.swagger.io/swagger-core/current/apidocs/index.html

https://github.com/swagger-api/swagger-core（旧版示例）

https://github.com/swagger-api/swagger-core/wiki/Annotations-1.5.X#quick-annotation-overview

https://github.com/swagger-api/swagger-samples（新版示例）

下面是收集的一些常用注解，如果要更多的用法，可以参照上面官网提供的文档：

名称	描述
@Api	将类标记为Swagger资源。
@ApiImplicitParam	表示API操作中的单个参数。
@ApiImplicitParams	允许多个ApiImplicitParam对象列表的包装器。
@ApiModel	提供有关Swagger型号的其他信息。
@ApiModelProperty	添加和操作模型属性的数据。
@ApiOperation	描述针对特定路径的操作或通常的HTTP方法。
@ApiParam	为操作参数添加额外的元数据。
@ApiResponse	描述操作的可能响应。
@ApiResponses	允许多个ApiResponse对象列表的包装器。
@Authorization	声明在资源或操作上使用授权方案。
@AuthorizationScope	描述OAuth2授权范围。
@ResponseHeader	表示可以作为响应的一部分提供的头。

示例代码：

SwaggerConfig 配置

import com.google.common.base.Predicate;
import org.springframework.beans.factory.annotation.Value;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;
import org.springframework.http.ResponseEntity;
import springfox.documentation.service.ApiInfo;
import springfox.documentation.spi.DocumentationType;
import springfox.documentation.spring.web.plugins.Docket;
import springfox.documentation.swagger2.annotations.EnableSwagger2;

import static com.google.common.base.Predicates.or;
import static springfox.documentation.builders.PathSelectors.regex;

/**
 * SwaggerConfig
 */
@Configuration
@EnableSwagger2
public class SwaggerConfig {

    @Value("${server.servlet-path}")
    private String pathMapping;

    private ApiInfo initApiInfo() {
        ApiInfo apiInfo = new ApiInfo("XXX项目 Platform API",//大标题
                initContextInfo(),//简单的描述
                "1.0.0",//版本
                "服务条款",
                "后台开发团队",//作者
                "The Apache License, Version 2.0",//链接显示文字
                "http://www.baidu.com"//网站链接
        );

        return apiInfo;
    }

    private String initContextInfo() {
        StringBuffer sb = new StringBuffer();
        sb.append("REST API 设计在细节上有很多自己独特的需要注意的技巧，并且对开发人员在构架设计能力上比传统 API 有着更高的要求。")
                .append("<br/>")
                .append("本文通过翔实的叙述和一系列的范例，从整体结构，到局部细节，分析和解读了为了提高易用性和高效性，REST API 设计应该注意哪些问题以及如何解决这些问题。");

        return sb.toString();
    }


    @Bean
    public Docket restfulApi() {
        System.out.println("http://localhost:8080" + pathMapping + "/swagger-ui.html");

        return new Docket(DocumentationType.SWAGGER_2)
                .groupName("RestfulApi")
//                .genericModelSubstitutes(DeferredResult.class)
                .genericModelSubstitutes(ResponseEntity.class)
                .useDefaultResponseMessages(true)
                .forCodeGeneration(false)
                .pathMapping(pathMapping) // base，最终调用接口后会和paths拼接在一起
                .select()
                .paths(doFilteringRules())
                .build()
                .apiInfo(initApiInfo());
    }

    /**
     * 设置过滤规则
     * 这里的过滤规则支持正则匹配
     * @return
     */
    private Predicate<String> doFilteringRules() {
        return or(
                regex("/hello.*"),
                regex("/vehicles.*")
        );
    }
}

Controller 的配置

import com.reachauto.hkr.cxn.swagger.bean.ChangeRentalShopParameter;
import io.swagger.annotations.*;
import org.slf4j.Logger;
import org.slf4j.LoggerFactory;
import org.springframework.ui.ModelMap;
import org.springframework.web.bind.annotation.*;

import java.util.Date;

@Api(value = "API - VehiclesController", description = "车辆模块接口详情")
@RestController
@RequestMapping("/vehicles")
public class VehiclesController {

    private static Logger logger = LoggerFactory.getLogger(VehiclesController.class);


    @ApiOperation(value = "查询车辆接口", notes = "此接口描述xxxxxxxxxxxxx<br/>xxxxxxx<br>值得庆幸的是这儿支持html标签<hr/>", response = String.class)
    @ApiImplicitParams({
            @ApiImplicitParam(name = "vno", value = "车牌", required = false,
                    dataType = "string", paramType = "query", defaultValue = "辽A12345"),
            @ApiImplicitParam(name = "page", value = "page", required = false,
                    dataType = "Integer", paramType = "query",defaultValue = "1"),
            @ApiImplicitParam(name = "count", value = "count", required = false,
                    dataType = "Integer", paramType = "query",defaultValue = "10")
    })
    @ApiResponses(value = {
            @ApiResponse(code = 200, message = "Successful — 请求已完成"),
            @ApiResponse(code = 400, message = "请求中有语法问题，或不能满足请求"),
            @ApiResponse(code = 401, message = "未授权客户机访问数据"),
            @ApiResponse(code = 404, message = "服务器找不到给定的资源；文档不存在"),
            @ApiResponse(code = 500, message = "服务器不能完成请求")}
    )
    @ResponseBody
    @RequestMapping(value = "", method = RequestMethod.GET)
    public ModelMap findVehicles(@RequestParam(value = "vno", required = false) String vno,
                                 @RequestParam(value = "page", required = false) Integer page,
                                 @RequestParam(value = "count", required = false) Integer count)
            throws Exception {

        logger.info("http://localhost:8501/api/v1/vehicles");
        logger.info("## {},{},{}", vno, page, count);
        logger.info("## 请求时间：{}", new Date());

        ModelMap map = new ModelMap();
        map.addAttribute("vno", vno);
        map.addAttribute("page", page);
        return map;
    }


    @ApiOperation(value = "根据车牌查询车辆", notes = "这种类型的查询是精确查询,其结果只有一条数据", response = String.class)
    @ApiImplicitParams({
            @ApiImplicitParam(name = "vno", value = "车牌", required = false,
                    dataType = "string", paramType = "path", defaultValue = "辽A12345")
    })
    @ApiResponses(value = {
            @ApiResponse(code = 200, message = "Successful — 请求已完成"),
            @ApiResponse(code = 400, message = "请求中有语法问题，或不能满足请求"),
            @ApiResponse(code = 401, message = "未授权客户机访问数据"),
            @ApiResponse(code = 404, message = "服务器找不到给定的资源；文档不存在"),
            @ApiResponse(code = 500, message = "服务器不能完成请求")}
    )
    @ResponseBody
    @RequestMapping(value = "vno={vno}", method = RequestMethod.GET)
    public ModelMap getVno(@PathVariable(value = "vno") String vno)
            throws Exception {

        logger.info("http://localhost:8501/api/v1/vehicles/vno={}", vno);
        logger.info("## 请求时间：{}", new Date());

        ModelMap map = new ModelMap();
        map.addAttribute("vno", vno);

        return map;
    }

    @ApiOperation(value = "车辆位置查询接口", notes = "根据车牌查询车辆位置信息", response = String.class)
    @ApiImplicitParams({
            @ApiImplicitParam(name = "vno", value = "车牌", required = false,
                    dataType = "string", paramType = "path", defaultValue = "辽A12345")
    })
    @ApiResponses(value = {
            @ApiResponse(code = 200, message = "Successful — 请求已完成"),
            @ApiResponse(code = 400, message = "请求中有语法问题，或不能满足请求"),
            @ApiResponse(code = 401, message = "未授权客户机访问数据"),
            @ApiResponse(code = 404, message = "服务器找不到给定的资源；文档不存在"),
            @ApiResponse(code = 500, message = "服务器不能完成请求")}
    )
    @ResponseBody
    @RequestMapping(value = "vno={vno}/location", method = RequestMethod.GET)
    public ModelMap getLocation(@PathVariable(value = "vno") String vno)
            throws Exception {
        logger.info("getLocation");
        logger.info("## 请求时间：{}", new Date());

        ModelMap map = new ModelMap();
        map.addAttribute("vno", vno);

        return map;
    }


    @ApiOperation(value = "根据车辆id查询", notes = "精确查询,最常规的方式,支持POST和GET方式", response = String.class)
    @ApiImplicitParams({
            @ApiImplicitParam(name = "id", value = "id", required = false,
                    dataType = "string", paramType = "path", defaultValue = "12344444")
    })
    @ApiResponses(value = {
            @ApiResponse(code = 200, message = "Successful — 请求已完成"),
            @ApiResponse(code = 400, message = "请求中有语法问题，或不能满足请求"),
            @ApiResponse(code = 401, message = "未授权客户机访问数据"),
            @ApiResponse(code = 404, message = "服务器找不到给定的资源；文档不存在"),
            @ApiResponse(code = 500, message = "服务器不能完成请求")}
    )
    @ResponseBody
    @RequestMapping(value = "{id}", method = {RequestMethod.GET,RequestMethod.POST})
    public ModelMap getById(@PathVariable(value = "id") String id)
            throws Exception {

        logger.info("http://localhost:8501/api/v1/vehicles/{}", id);
        logger.info("## 请求时间：{}", new Date());

        ModelMap map = new ModelMap();
        map.addAttribute("{RequestMethod.GET,RequestMethod.POST}", id);

        return map;
    }

    @ApiOperation(value = "根据车辆id查询", notes = "精确查询,最常规的方式,支持POST和GET方式", response = String.class)
    @ApiImplicitParams({
            @ApiImplicitParam(name = "id", value = "id", required = false,
                    dataType = "string", paramType = "path", defaultValue = "12344444")
    })
    @ApiResponses(value = {
            @ApiResponse(code = 200, message = "Successful — 请求已完成"),
            @ApiResponse(code = 400, message = "请求中有语法问题，或不能满足请求"),
            @ApiResponse(code = 403, message = "服务器拒绝请求"),
            @ApiResponse(code = 401, message = "未授权客户机访问数据"),
            @ApiResponse(code = 404, message = "服务器找不到给定的资源；文档不存在"),
            @ApiResponse(code = 500, message = "服务器不能完成请求")}
    )
    @ResponseBody
    @RequestMapping(value = "{id}", method = {RequestMethod.DELETE})
    public ModelMap delById(@PathVariable(value = "id") String id)
            throws Exception {

        logger.info("http://localhost:8501/api/v1/vehicles/{}", id);
        logger.info("## 请求时间：{}", new Date());

        ModelMap map = new ModelMap();
        map.addAttribute("RequestMethod.DELETE", id);
        return map;
    }

    @ApiOperation(value = "网点挂靠", notes = "嘻嘻嘻嘻嘻嘻嘻嘻嘻嘻嘻嘻嘻嘻嘻嘻", response = String.class)
    @ApiResponses(value = {
            @ApiResponse(code = 200, message = "Successful — 请求已完成"),
            @ApiResponse(code = 400, message = "请求中有语法问题，或不能满足请求"),
            @ApiResponse(code = 401, message = "未授权客户机访问数据"),
            @ApiResponse(code = 404, message = "服务器找不到给定的资源；文档不存在"),
            @ApiResponse(code = 500, message = "服务器不能完成请求")}
    )
    @ResponseBody
    @RequestMapping(value = "change_rentalshop", method = {RequestMethod.PUT,RequestMethod.PATCH})
    public ModelMap changeRentalShop(@RequestBody ChangeRentalShopParameter parameter)
            throws Exception {

        logger.info("http://localhost:8501/api/v1/vehicles/change_rentalshop | {}", parameter);
        logger.info("## 请求时间：{}", new Date());
        ModelMap map = new ModelMap();
        map.addAttribute("网点挂靠", new Date());

        return map;
    }
}

Application 启动模块

import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.EnableAutoConfiguration;
import org.springframework.context.annotation.ComponentScan;
import org.springframework.context.annotation.Configuration;

@Configuration
@EnableAutoConfiguration
@ComponentScan
public class Application {
    public static void main(String[] args) {
        SpringApplication.run(Application.class, args);
    }
}
