cd speexdsp-SpeexDSP-1.2.1/
./autogen.sh
#./autogen.sh: 11: autoreconf: not found报错，安装依赖
sudo apt-get install -y autoconf automake libtool
./configure --prefix=${BUILD_LIBS} --disable-oggtest
make
make install

1
2
3
INCLUDEPATH += $$PWD/include
LIBS += -L$$PWD/lib -lspeexdsp -ldl

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
#ifndef chwAUDIOPROC_chwRtcAec_H_
#define chwAUDIOPROC_chwRtcAec_H_
#include <stdint.h>
#include <stdlib.h>
typedef struct{
	void *session;
	void (*init)(void* session, int32_t sampleRate, int32_t pchannel,int32_t pframeSize,int32_t echopath);
	void (*closeAec)(void* session);

	void (*echoCapture)(void* session,short *rec, short *out);
	void (*preprocessRun)(void* session,short *pcm);
	void (*echoStateReset)(void* session);
	void (*echoPlayback)(void* session,short *play);
	void (*echoCancellation)(void* session,const short *rec, const short *play,
			short *out);
}chwRtcAec;

#define chw_delete(a) {if( (a)) {delete (a); (a) = NULL;}}
#define chw_deleteA(a) {if( (a)) {delete[] (a); (a) = NULL;}}
#define chw_free(a) {if( (a)) {free((a)); (a) = NULL;}}

#ifdef __cplusplus
extern "C"{
#endif
void chw_rtcaec_init(void* context, int32_t sampleRate, int32_t pchannel,int32_t pframeSize,int32_t echopath);
void chw_rtcaec_preprocess_run(void* context,short *pcm);
void chw_create_rtcaec(chwRtcAec* aec);
void chw_destroy_rtcaec(chwRtcAec* aec);
#ifdef __cplusplus
}
#endif
#endif /* chwAUDIOPROC_chwAECSPEEX_H_ */

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
#include "chwRtcAec.h"
#include <speex/speex_echo.h>
#include <speex/speex_preprocess.h>
#include <stdio.h>
#include <string.h>
typedef struct chwRtcAec{
	int32_t channel;
	int32_t frameSize;
	int32_t sampleRate;
	int32_t echoPath;
	SpeexEchoState *state;
	SpeexPreprocessState *preprocState;

}chwRtcAecContext;
///m_aec->session,16000,1,320,10
void chw_rtcaec_init(void* context, int32_t sampleRate, int32_t pchannel,int32_t pframeSize,int32_t echopath)
{
    if(context==NULL) return;
    chwRtcAecContext* aec=(chwRtcAecContext*)context;
    aec->frameSize = pframeSize;
    aec->sampleRate = sampleRate;
    aec->channel = pchannel;
    aec->echoPath=echopath;
    int32_t frame_size = aec->frameSize;//(aec->frameSizeInMS * aec->sampleRate * 1.0) / 1000;
    int32_t filter_length = aec->frameSize * aec->echoPath;//20;//30;//aec->echoPath;//(aec->frameSizeInMS * aec->sampleRate * 1.0) / 1000;

    /** 创建一个新的多通道回波取消器状态
     * @param frame_size 一次要处理的样本数(应对应10-20 ms)
     * @param filter_length 要取消的回波样本数（一般应对应100-500 ms）
     * @param aec->channel 麦克风通道数
     * @param aec->channel 扬声器通道数
     * @return 新创建的回波取消器状态
     */
    if(!aec->state) aec->state = speex_echo_state_init_mc(frame_size, filter_length, aec->channel,aec->channel);
    //frame_size *= 2; // length read each time

    /** 将创建一个新的预处理状态。您必须为每个已处理的通道创建一个状态。
     * @param frame_size 一次要处理的样品数（应对应10-20 ms）。必须为：与用于剩余回声消除的回波消除器的值相同。
     * @param sampling_rate 用于输入的采样率。
     * @return 返回新创建的预处理器状态
    */
    if(!aec->preprocState) aec->preprocState = speex_preprocess_state_init(frame_size, aec->sampleRate);

    speex_echo_ctl(aec->state, SPEEX_ECHO_SET_SAMPLING_RATE, &aec->sampleRate);//设置采样率
    speex_preprocess_ctl(aec->preprocState, SPEEX_PREPROCESS_SET_ECHO_STATE,aec->state);//设置相应的回波消除器状态，以便可进行残余回波抑制（无残余回波抑制时为NULL）
    int32_t i = 1;
    //speex_preprocess_ctl(aec->preprocState, SPEEX_PREPROCESS_SET_VAD, &i);
    int32_t noiseSuppress = -25;
    i = 1;
    speex_preprocess_ctl(aec->preprocState, SPEEX_PREPROCESS_SET_DENOISE,	&i);//设置预处理器去噪状态
    speex_preprocess_ctl(aec->preprocState, SPEEX_PREPROCESS_SET_NOISE_SUPPRESS,	&noiseSuppress);//设置噪声的最大衰减，单位为dB（负数）
    i=0;
    speex_preprocess_ctl(aec->preprocState, SPEEX_PREPROCESS_SET_AGC, &i);//设置预处理器自动增益控制状态
    i=sampleRate;
    speex_preprocess_ctl(aec->preprocState, SPEEX_PREPROCESS_SET_AGC_LEVEL, &i);//设置预处理器自动增益控制级别（浮动）
    i=0;
    speex_preprocess_ctl(aec->preprocState, SPEEX_PREPROCESS_SET_DEREVERB, &i);//设置预处理器dereverb状态
    float f=.0;
    speex_preprocess_ctl(aec->preprocState, SPEEX_PREPROCESS_SET_DEREVERB_DECAY, &f);//设置预处理器dereverb decay
    f=.0;
    speex_preprocess_ctl(aec->preprocState, SPEEX_PREPROCESS_SET_DEREVERB_LEVEL, &f);//设置EverB级别的预处理器
}

void chw_rtcaec_close(void* context){
	if(context==NULL) return;
	chwRtcAecContext* aec=(chwRtcAecContext*)context;
    if(aec->state) speex_echo_state_destroy(aec->state);//销毁回声消除状态
    if(aec->preprocState) speex_preprocess_state_destroy(aec->preprocState);//销毁预处理器状态
	aec->state = NULL;
	aec->preprocState = NULL;
}

void chw_rtcaec_echo_capture(void* context,short *rec, short *out) {
	if(context==NULL) return;
	chwRtcAecContext* aec=(chwRtcAecContext*)context;
    /** 使用内部回放缓冲区执行回声取消，这会延迟两帧
     * 来解释大多数声卡引入的延迟（但它可能是关闭的！）
     * @param aec->state 回声消除器状态
     * @param rec 麦克风信号（近端+远端回声）
     * @param out 返回去除回声的近端信号
    */
	if(aec->state) speex_echo_capture(aec->state, rec, out);
}

void chw_rtcaec_preprocess_run(void* context,short *pcm)
{
	if(context==NULL) return;
	chwRtcAecContext* aec=(chwRtcAecContext*)context;
    /** 对帧进行预处理
     * @param aec->preprocState 预处理器状态
     * @param Pcm 音频样本向量（进和出）。必须与在speex_preprocess_state_init()中指定的大小相同。
     * @return 语音业务的Bool值（1表示语音，0表示噪音/静音），仅当VAD打开时使用。
    */
	if(aec->preprocState) speex_preprocess_run(aec->preprocState, pcm);
}

void chw_rtcaec_echo_state_reset(void* context) {
	if(context==NULL) return;
	chwRtcAecContext* aec=(chwRtcAecContext*)context;
    /** 将回声取消器重置到其原始状态
     * @param aec->state 回声消除状态
     */
	if(aec->state) speex_echo_state_reset(aec->state);
}
void chw_rtcaec_echo_playback(void* context,short *play) {
	if(context==NULL) return;
	chwRtcAecContext* aec=(chwRtcAecContext*)context;
    /** 让回声取消器知道一个帧刚刚排队到声卡上
     * @param aec->state 回声消除状态
     * @param play 信号播放到扬声器（从远端接收）
    */
	if(aec->state) speex_echo_playback(aec->state, play);
}
void chw_rtcaec_echo_cancellation(void* context,const short *rec, const short *play,
		short *out) {
	if(context==NULL) return;
	chwRtcAecContext* aec=(chwRtcAecContext*)context;
    /** 根据发送到扬声器的音频执行回声取消帧(没有添加延迟以此形式播放）
     * @param aec->state 回声消除状态
     * @param rec 来至麦克风的信号（近端+远端回声）
     * @param play 信号播放到扬声器（从远端接收）
     * @param out 返回消除回声的近端信号
     */
	if(aec->state) speex_echo_cancellation(aec->state, rec, play, out);
}

void chw_create_rtcaec(chwRtcAec* aec){
	if(aec==NULL) return;
	aec->session=(chwRtcAecContext*)calloc(sizeof(chwRtcAecContext),1);
	aec->init=chw_rtcaec_init;
	aec->closeAec=chw_rtcaec_close;
	aec->echoCancellation=chw_rtcaec_echo_cancellation;
	aec->echoCapture=chw_rtcaec_echo_capture;
	aec->echoPlayback=chw_rtcaec_echo_playback;
	aec->echoStateReset=chw_rtcaec_echo_state_reset;
	aec->preprocessRun=chw_rtcaec_preprocess_run;
}
void chw_destroy_rtcaec(chwRtcAec* aec){
	if(aec==NULL) return;

	chw_rtcaec_close((chwRtcAecContext*)aec->session);
	chw_free(aec->session);
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
#include "spxmainwindow.h"
#include "ui_spxmainwindow.h"

#include <QFile>
#define HEADLEN 44
#define SAMPLE_RATE   (48000)
#define SAMPLES_PER_FRAME  (1024)
#define FRAME_SIZE   (SAMPLES_PER_FRAME * 1000/ SAMPLE_RATE)
#define FRAME_BYTES  (SAMPLES_PER_FRAME)

spxMainWindow::spxMainWindow(QWidget *parent)
    : QMainWindow(parent)
    , ui(new Ui::spxMainWindow)
{
    ui->setupUi(this);

    pcm=new short[4096/2];
    m_aec = NULL;
    m_aec=(chwRtcAec*)calloc(sizeof(chwRtcAec),1);
    chw_create_rtcaec(m_aec);
    chw_rtcaec_init(m_aec->session,44100,1,1024,10);//注意传参的采样率、帧大小、通道数一定要和采集时一致

    dealAudio();
}

spxMainWindow::~spxMainWindow()
{
    chw_destroy_rtcaec(m_aec);
    chw_free(m_aec);
    chw_deleteA(pcm);
    delete ui;
}
//消除噪声处理，以wav文件为例
void spxMainWindow::dealAudio()
{
    size_t len = 0;
    QFile inFile, outFile;
    inFile.setFileName("./test.wav");
    outFile.setFileName("./outtest.wav");

    char headBuf[HEADLEN];
    char dataBuf[FRAME_BYTES * 2];

    QByteArray readBuf;
    if(inFile.open(QIODevice::ReadOnly))
        inFile.read(headBuf,HEADLEN);//wav头部
    if(outFile.open(QIODevice::WriteOnly))
        outFile.write(headBuf,HEADLEN);

    while(inFile.atEnd() == false)
    {
        len = inFile.read(dataBuf,SAMPLES_PER_FRAME);
        if(len == 0) break;

        chw_rtcaec_preprocess_run(m_aec->session,(short*)dataBuf);
        outFile.write(dataBuf,SAMPLES_PER_FRAME);
    }

    inFile.flush();
    inFile.close();
    outFile.flush();
    outFile.close();
}
//回声消除，播放对方音频后调用
void spxMainWindow::dealEchoPlay(short* pbuf,int32_t plen)
{
    if(m_aec) m_aec->echoPlayback(m_aec->session,pbuf);
}
//回声采样和去噪，采集本端音频后，编码前调用
void spxMainWindow::putEchoBuffer( uint8_t *pBuffer,int32_t plen)
{
    if (m_aec)
    {
        m_aec->echoCapture(m_aec->session, (short*) pBuffer, pcm);
        m_aec->preprocessRun(m_aec->session, pcm);
        m_audioFrame.data = (uint8_t*)pcm;
        m_audioFrame.len = plen;
//        m_resample.resample(m_resample.context,&m_audioFrame);
    }
}

1
2
3
4
waining:no playback frame available(your application is buggy and/or got xruns)，#ifndef DISABLE_WARNINGS
warning: Had to discard a playback frame (your application is buggy and/or got xruns)
warning: Auto-filling the buffer (your application is buggy and/or got xruns)

1
2
#define DISABLE_WARNINGS
