概述

aop配合反射统一签名验证

直接上代码，作为记录。

CheckSignAspect.java

@Aspect   //定义一个切面
@Configuration
@Log4j2
public class CheckSignAspect {
    // 定义切点Pointcut
    @Pointcut("execution(* com.lsj.xxl.controller.*.*CheckSign(..))")
    public void excudeService() {
    }
    @Around("excudeService()")
    public Object doAround(ProceedingJoinPoint pjp) throws Throwable {
        String class_name = pjp.getTarget().getClass().getName();
        String method_name = pjp.getSignature().getName();
        String[] paramNames = getFieldsName(class_name, method_name);
        Object[] method_args = pjp.getArgs();
        SortedMap<String, String> map = logParam(paramNames, method_args);
        if (map != null) {
            String sign = map.get("sign").toUpperCase();
            map.remove("sign");
            String realSign = SignUtil.createSign("utf8", map);
            if (!realSign.equals(sign)) {
                return "签名校验错误";
            }
        }
        Object result = pjp.proceed();
        return result;
    }
    /**
     * 使用javassist来获取方法参数名称
     *
     * @param class_name  类名
     * @param method_name 方法名
     * @return
     * @throws Exception
     */
    private String[] getFieldsName(String class_name, String method_name) throws Exception {
        Class<?> clazz = Class.forName(class_name);
        String clazz_name = clazz.getName();
        ClassPool pool = ClassPool.getDefault();
        ClassClassPath classPath = new ClassClassPath(clazz);
        pool.insertClassPath(classPath);
        CtClass ctClass = pool.get(clazz_name);
        CtMethod ctMethod = ctClass.getDeclaredMethod(method_name);
        MethodInfo methodInfo = ctMethod.getMethodInfo();
        CodeAttribute codeAttribute = methodInfo.getCodeAttribute();
        LocalVariableAttribute attr = (LocalVariableAttribute) codeAttribute.getAttribute(LocalVariableAttribute.tag);
        if (attr == null) {
            return null;
        }
        String[] paramsArgsName = new String[ctMethod.getParameterTypes().length];
        int pos = Modifier.isStatic(ctMethod.getModifiers()) ? 0 : 1;
        for (int i = 0; i < paramsArgsName.length; i++) {
            paramsArgsName[i] = attr.variableName(i + pos);
        }
        return paramsArgsName;
    }
    /**
     * 打印方法参数值  基本类型直接打印，非基本类型需要重写toString方法
     *
     * @param paramsArgsName  方法参数名数组
     * @param paramsArgsValue 方法参数值数组
     */
    private SortedMap<String, String> logParam(String[] paramsArgsName, Object[] paramsArgsValue) {
        Map<String, String> map = new HashMap();
        if (ArrayUtils.isEmpty(paramsArgsName) || ArrayUtils.isEmpty(paramsArgsValue)) {
            log.info("该方法没有参数");
            return null;
        }
//        StringBuffer buffer = new StringBuffer();
        for (int i = 0; i < paramsArgsName.length; i++) {
            //参数名
            String name = paramsArgsName[i];
            //参数值
            Object value = paramsArgsValue[i];
//            if ("sign".equals(name)){
//                continue;
//            }
            if (isPrimite(value.getClass())) {
                map.put(name, String.valueOf(value));
            } else {
                map.put(name, value.toString());
            }
        }
        return new TreeMap<>(map);
    }
    /**
     * 判断是否为基本类型：包括String
     *
     * @param clazz clazz
     * @return true：是;     false：不是
     */
    private boolean isPrimite(Class<?> clazz) {
        if (clazz.isPrimitive() || clazz == String.class) {
            return true;
        } else {
            return false;
        }
    }
}

SignUtil.java

public class SignUtil {
    public static String createSign(String characterEncoding, SortedMap<String, String> parameters) {
        StringBuffer sb = new StringBuffer();
        for (Map.Entry<String, String> entry : parameters.entrySet()) {
            if (!Strings.isNullOrEmpty(entry.getValue()) && !"sign".equals(entry.getKey()) && !"key".equals(entry.getKey())) {
                sb.append(entry.getKey() + "=" + entry.getValue() + "&");
            }
        }
        String s = sb.toString();
        if (s.length() > 0) {
            s = s.substring(0, sb.toString().length() - 1);
        }
        System.out.println("待加密字符串:" + s);
        String sign = MD5Util.MD5Encode(s, characterEncoding).toUpperCase();
        return sign;
    }
}

测试

 @PostMapping("test1")
    public String bbCheckSign( @RequestParam("value") String value,
                            @RequestParam("bb")String bb,
                            @RequestParam("sign")String sign){
        return "ok";
    }

补充：

上述方式也可换为注解实现，具体修改代码如下：

添加注解

@Target(ElementType.METHOD)
@Retention(RetentionPolicy.RUNTIME )
public @interface CheckSign {
}

改变切点

@Pointcut("@annotation(com.lsj.xxl.annotation.CheckSign)")

接口统一签名校验

实现接口请求签名校验，时间戳判断，响应数据返回签名等内容。

这个签名校验，和返回签名可以用多种方法实现。

第一种aop 方式实现

自定义注解体

/**
 * @author xxx
 */
@Retention(value = RetentionPolicy.RUNTIME)
public @interface SignatureValidation {
}

aop实现

/**
 * @author xxx
 */
@Aspect
@Component
public class SignatureValidation {
    /**
     * 时间戳请求最小限制(600s)
     * 设置的越小，安全系数越高，但是要注意一定的容错性
     */
    private static final long MAX_REQUEST = 10 * 60 * 1000L;
    /**
     * 秘钥
     */
    private static final String SECRET= "test";
    /**
     * 验签切点(完整的找到设置的文件地址)
     */
    @Pointcut("execution(@com.xx.xxx.xxxxx.aop.SignatureValidation * *(..))")
    private void verifyUserKey() {
    }
    /**
     * 获取请求数据，并校验签名数据
     */
    @Before("verifyUserKey()")
    public void doBasicProfiling(JoinPoint point) {
        ServletRequestAttributes attributes = (ServletRequestAttributes) RequestContextHolder.getRequestAttributes();
        HttpServletRequest request = Objects.requireNonNull(attributes).getRequest();
        String sign = "" ;
        String timestamp = "" ;
        String version = "";
        SortedMap<String,String> sortedMap = new TreeMap<String,String>();
        for ( Object obj  :point.getArgs()) {
            JSONObject jsonObject =JSONUtil.parseObj(obj);
            if( !StrUtil.isEmptyIfStr(jsonObject.get("sign"))){
                sign=jsonObject.get("sign").toString();
            }
            if(!StrUtil.isEmptyIfStr(jsonObject.get("timestamp"))){
                timestamp=jsonObject.get("timestamp").toString();
                sortedMap.put("timestamp", timestamp);
            }
            if(!StrUtil.isEmptyIfStr(jsonObject.get("version"))){
                version=jsonObject.get("version").toString();
                sortedMap.put("version", version);
            }
            if(!StrUtil.isEmptyIfStr(jsonObject.get("data"))){
                String dataStr= jsonObject.get("data").toString();
                if(!JSONUtil.isJsonObj(dataStr)) {
                    if(JSONUtil.isJsonArray(dataStr)){
                        sortedMap.put("data", JSONUtil.parseArray(dataStr).toString());
                    }
                    sortedMap.put("data", dataStr);
                }
                else
                {
                    JSONObject dataJson= JSONUtil.parseObj(dataStr);
                    @SuppressWarnings("unchecked")
                    Set<String> keySet = dataJson.keySet();
                    String key = "";
                    Object value = null;
                    // 遍历json数据，添加到SortedMap对象
                    for (Iterator<String> iterator = keySet.iterator(); iterator.hasNext();) {
                        key = iterator.next();
                        value = dataJson.get(key);
                        String  valueStr="";
                        if(!StrUtil.isEmptyIfStr(value)){
                            valueStr=value.toString();
                        }
                        sortedMap.put(key, valueStr);
                    }
                }
            }
        }
        if (StrUtil.isEmptyIfStr(sign)) {
            throw new CustomException(BaseResultInfoEnum.ERROR_MISSING_SIGN_1009.getMsg(),BaseResultInfoEnum.ERROR_MISSING_SIGN_1009.getCode());
        }
        //新的签名
        String newSign = createSign(sortedMap,SECRET);
            if (!newSign.equals(sign.toUpperCase())) {
                throw new CustomException(BaseResultInfoEnum.ERROR_SIGN_1010.getMsg(),BaseResultInfoEnum.ERROR_SIGN_1010.getCode());
            }
    }
    /**
     *
     * @param point
     * @param responseObject 返回参数
     */
    @AfterReturning(pointcut="verifyUserKey()",returning="responseObject")
    public void afterReturning(JoinPoint point,Object responseObject) {
        HttpServletResponse response=((ServletRequestAttributes) RequestContextHolder.getRequestAttributes()).getResponse();
        if(responseObject instanceof ResponseModel){
            ResponseModel responseModel= (ResponseModel) responseObject;
            responseModel.setTimestamp(System.currentTimeMillis());
            responseModel.setVersion(0);
            String sign= Md5Utils.createSign(Md5Utils.createParameters(responseModel),SECRET);
            responseModel.setSign(sign);
        }
    }
}

md5签名

/**
 * @author xxx
 */
public class Md5Utils {
    /**
     * 生成签名
     * @param parameters
     * @param key 商户ID
     * @return
     */
    public static String createSign(SortedMap<String,String> parameters, String key){
        StringBuffer sb = new StringBuffer();
        Set es = parameters.entrySet();
        Iterator it = es.iterator();
        while(it.hasNext()) {
            Map.Entry entry = (Map.Entry)it.next();
            String k = (String)entry.getKey();
            Object v = entry.getValue();
            if(null != v && !"".equals(v)
                    && !"sign".equals(k) && !"key".equals(k)) {
                sb.append(k + "=" + v + "&");
            }
        }
        sb.append("key=" + key);
        String sign = SecureUtil.md5(sb.toString()).toUpperCase();
        return sign;
    }
    /**
     * 签名参数
     * @param responseModel 响应数据签名返回给调用者
     * @return
     */
    public  static SortedMap<String,String> createParameters(ResponseModel responseModel){
        SortedMap<String,String> sortedMap = new TreeMap<String,String>();
        if(responseModel!=null) {
            sortedMap.put("timestamp", Convert.toStr(responseModel.getTimestamp()) );
            sortedMap.put("version", Convert.toStr(responseModel.getVersion()));
            JSONObject json = JSONUtil.parseObj(responseModel, false);
            if(responseModel.getData()!=null) {
                sortedMap.put("data", json.get("data").toString());
            }
        }
        return sortedMap;
    }
}

使用，在控制中的方法上方注解即可

第二种拦截器

这里只做了时间判断，签名校验可以根据需要修改即可实现。

过滤器

import javax.servlet.*;
import javax.servlet.annotation.WebFilter;
import javax.servlet.http.HttpServletRequest;
import java.io.IOException;
/**
 * @author xx
 */
@WebFilter(urlPatterns = "/*",filterName = "channelFilter")
public class ChannelFilter implements Filter {
    @Override
    public void init(FilterConfig filterConfig) throws ServletException {
    }
    @Override
    public void doFilter(ServletRequest servletRequest, ServletResponse servletResponse, FilterChain filterChain) throws IOException, ServletException {
        ServletRequest requestWrapper = null;
        if(servletRequest instanceof HttpServletRequest) {
            requestWrapper = new RequestWrapper((HttpServletRequest) servletRequest);
        }
        if(requestWrapper == null) {
            filterChain.doFilter(servletRequest, servletResponse);
        } else {
            filterChain.doFilter(requestWrapper, servletResponse);
        }
    }
    @Override
    public void destroy() {
    }
}

拦截器配置

import org.springframework.boot.web.servlet.FilterRegistrationBean;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;
import org.springframework.web.servlet.HandlerInterceptor;
import org.springframework.web.servlet.config.annotation.CorsRegistry;
import org.springframework.web.servlet.config.annotation.InterceptorRegistry;
import org.springframework.web.servlet.config.annotation.WebMvcConfigurer;
/**
 * @author xxxx
 */
@Configuration
public class InterceptorConfig implements WebMvcConfigurer{
    @Override
    public void addInterceptors(InterceptorRegistry registry) {
        registry.addInterceptor(getHandlerInterceptor());
    }
    @Override
    public void addCorsMappings(CorsRegistry registry) {
        registry.addMapping("/**")
                .allowedHeaders("Content-Type", "x-requested-with", "X-Custom-Header")
                .allowedMethods("PUT", "POST", "GET", "DELETE", "OPTIONS")
                .allowedOrigins("*")
                .allowCredentials(true);
    }
    @Bean
    public FilterRegistrationBean repeatedlyReadFilter() {
        FilterRegistrationBean registration = new FilterRegistrationBean();
        ChannelFilter repeatedlyReadFilter = new ChannelFilter();
        registration.setFilter(repeatedlyReadFilter);
        registration.addUrlPatterns("/*");
        return registration;
    }
    @Bean
    public HandlerInterceptor getHandlerInterceptor() {
        return new TimestampInterceptor();
    }
}

RequestWrapper 请求流重写处理

import javax.servlet.ReadListener;
import javax.servlet.ServletInputStream;
import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletRequestWrapper;
import java.io.*;
/**
 * @author xxx
 */
public class RequestWrapper extends HttpServletRequestWrapper {
    private final String body;
    public RequestWrapper(HttpServletRequest request) {
        super(request);
        StringBuilder stringBuilder = new StringBuilder();
        BufferedReader bufferedReader = null;
        InputStream inputStream = null;
        try {
            inputStream = request.getInputStream();
            if (inputStream != null) {
                bufferedReader = new BufferedReader(new InputStreamReader(inputStream));
                char[] charBuffer = new char[128];
                int bytesRead = -1;
                while ((bytesRead = bufferedReader.read(charBuffer)) > 0) {
                    stringBuilder.append(charBuffer, 0, bytesRead);
                }
            } else {
                stringBuilder.append("");
            }
        } catch (IOException ex) {
        } finally {
            if (inputStream != null) {
                try {
                    inputStream.close();
                }
                catch (IOException e) {
                    e.printStackTrace();
                }
            }
            if (bufferedReader != null) {
                try {
                    bufferedReader.close();
                }
                catch (IOException e) {
                    e.printStackTrace();
                }
            }
        }
        body = stringBuilder.toString();
    }
    @Override
    public ServletInputStream getInputStream() throws IOException {
        final ByteArrayInputStream byteArrayInputStream = new ByteArrayInputStream(body.getBytes());
        ServletInputStream servletInputStream = new ServletInputStream() {
            @Override
            public boolean isFinished() {
                return false;
            }
            @Override
            public boolean isReady() {
                return false;
            }
            @Override
            public void setReadListener(ReadListener readListener) {
            }
            @Override
            public int read() throws IOException {
                return byteArrayInputStream.read();
            }
        };
        return servletInputStream;
    }
    @Override
    public BufferedReader getReader() throws IOException {
        return new BufferedReader(new InputStreamReader(this.getInputStream()));
    }
    public String getBody() {
        return this.body;
    }
}

拦截器这里可以实现请求来的签名处理，这里只处理时间了

import cn.hutool.core.util.StrUtil;
import cn.hutool.json.JSONObject;
import cn.hutool.json.JSONUtil;
import xxx.xxx.xxx.common.result.BaseResultInfoEnum;
import xxx.xxx.common.core.exception.CustomException;
import org.springframework.boot.autoconfigure.web.servlet.error.BasicErrorController;
import org.springframework.web.method.HandlerMethod;
import org.springframework.web.servlet.HandlerInterceptor;
import org.springframework.web.servlet.ModelAndView;
import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;
/**
 * @author xxx
 */
public class TimestampInterceptor implements HandlerInterceptor {
    /**
     * 时间戳请求最小限制(600s)
     * 设置的越小，安全系数越高，但是要注意一定的容错性
     */
    private static final long MAX_REQUEST = 10 * 60 * 1000L;
    @Override
    public boolean preHandle(HttpServletRequest request, HttpServletResponse response, Object handler) throws Exception {
        if (handler instanceof HandlerMethod) {
            HandlerMethod handlerMethod = (HandlerMethod) handler;
            if (handlerMethod.getBean() instanceof BasicErrorController) {
                return true;
            }
//            if ("GET".equals(request.getMethod())) {
//                return true;
//            }
            ValidateResponse validateResponse = new ValidateResponse(true, null);
            RequestWrapper myRequestWrapper = new RequestWrapper((HttpServletRequest) request);
            validateResponse= checkTimestamp(myRequestWrapper.getBody());
            if (!validateResponse.isValidate()) {
                throw validateResponse.getException();
            }
        }
        return true;
    }
    @Override
    public void postHandle(HttpServletRequest request, HttpServletResponse response, Object handler, ModelAndView modelAndView) {
    }
    @Override
    public void afterCompletion(HttpServletRequest request, HttpServletResponse response, Object handler, Exception ex) {
    }
    private  ValidateResponse  checkTimestamp(String requestBody) {
        try {
            JSONObject jsonObject = JSONUtil.parseObj(requestBody);
            String timestamp = "" ;
                if(!StrUtil.isEmptyIfStr(jsonObject.get("timestamp"))) {
                    timestamp=jsonObject.get("timestamp").toString();
                }
            if (StrUtil.isEmptyIfStr(timestamp)) {
                return new ValidateResponse(false, new CustomException(BaseResultInfoEnum.ERROR_MISSING_TIMESTAMP_1007.getMsg(), BaseResultInfoEnum.ERROR_MISSING_TIMESTAMP_1007.getCode()));
            }
            long now = System.currentTimeMillis();
            long time = Long.parseLong(timestamp);
            if (now - time > MAX_REQUEST) {
                return new ValidateResponse(false, new CustomException(BaseResultInfoEnum.ERROR_TIMESTAMP_TIMEOUT_1008.getMsg(), BaseResultInfoEnum.ERROR_TIMESTAMP_TIMEOUT_1008.getCode()));
            }
        } catch (Exception e) {
            e.printStackTrace();
        }
        return new ValidateResponse(true, null);
    }
    /**
     * 校验返回对象
     */
    private static class ValidateResponse {
        private boolean validate;
        private CustomException exception;
        public ValidateResponse(boolean validate, CustomException exception) {
            this.validate = validate;
            this.exception = exception;
        }
        public boolean isValidate() {
            return validate;
        }
        public Exception getException() {
            return exception;
        }
    }
}

返回给前端(或其他平台的)处理类

import comzzzz.xx.common.pojo.PageResponseModel;
import com.zzz.xxxx.common.pojo.ResponseModel;
import org.springframework.core.MethodParameter;
import org.springframework.http.MediaType;
import org.springframework.http.server.ServerHttpRequest;
import org.springframework.http.server.ServerHttpResponse;
import org.springframework.web.bind.annotation.ControllerAdvice;
import org.springframework.web.servlet.mvc.method.annotation.ResponseBodyAdvice;
/**
 * @author sunrh
 */
@ControllerAdvice
public class ResponseBodyTimestamp implements ResponseBodyAdvice {
    @Override
    public boolean supports(MethodParameter methodParameter, Class aClass) {
        return true;
    }
    @Override
    public Object beforeBodyWrite(Object o, MethodParameter methodParameter, MediaType mediaType, Class aClass, ServerHttpRequest serverHttpRequest, ServerHttpResponse serverHttpResponse) {
//就是这里处理返回签名数据
        if(o instanceof ResponseModel){
            ResponseModel responseModel= (ResponseModel) o;
            responseModel.setTimestamp(System.currentTimeMillis());
            return responseModel;
        }
        if(o instanceof PageResponseModel){
            PageResponseModel responseModel= (PageResponseModel) o;
            responseModel.setTimestamp(System.currentTimeMillis());
            return responseModel;
        }
        return o;
    }
}

最终实现的效果图
