在C#中使用二叉树实时计算海量用户积分排名的实现详解

  /// <summary>
  /// 树节点对象
  /// </summary>
  public class TreeNode
  {
    /// <summary>
    /// 节点的最小值
    /// </summary>
    public int ValueFrom { get; set; }

    /// <summary>
    /// 节点的最大值
    /// </summary>
    public int ValueTo { get; set; }

    /// <summary>
    /// 在节点范围内的数量
    /// </summary>
    public int Count { get; set; }

    /// <summary>
    /// 节点高度（树的层级）
    /// </summary>
    public int Height { get; set; }

    /// <summary>
    /// 父节点
    /// </summary>
    public TreeNode Parent { get; set; }

    /// <summary>
    /// 左子节点
    /// </summary>
    public TreeNode LeftChildNode { get; set; }

    /// <summary>
    /// 右子节点
    /// </summary>
    public TreeNode RightChildNode { get; set; }
  }

  public class RankBinaryTree
  {
    /// <summary>
    /// 根节点
    /// </summary>
    private TreeNode _root;

  }

   /// <summary>
    /// 构造函数初始化根节点
    /// </summary>
    /// <param name="max"></param>
    public RankBinaryTree(int max)
    {
      _root = new TreeNode() { ValueFrom = 0, ValueTo = max+1, Height = 1 };
      _root.LeftChildNode = CreateChildNode(_root, 0, max / 2);
      _root.RightChildNode = CreateChildNode(_root, max / 2, max);
    }

    /// <summary>
    /// 遍历创建子节点
    /// </summary>
    /// <param name="current"></param>
    /// <param name="min"></param>
    /// <param name="max"></param>
    /// <returns></returns>
    private TreeNode CreateChildNode(TreeNode current, int min, int max)
    {
      if (min == max) return null;
      var node = new TreeNode() { ValueFrom = min, ValueTo = max, Height = current.Height + 1 };
      node.Parent = current;
      int center = (min + max) / 2;
      if (min < max - 1)
      {
        node.LeftChildNode = CreateChildNode(node, min, center);
        node.RightChildNode = CreateChildNode(node, center, max);
      }
      return node;
    }

  /// <summary>
    /// 往树中插入一个值
    /// </summary>
    /// <param name="value"></param>
    public void Insert(int value)
    {
      InnerInsert(_root, value);
      _data.Add(value);
    }

    /// <summary>
    /// 子节点判断范围遍历插入
    /// </summary>
    /// <param name="node"></param>
    /// <param name="value"></param>
    private void InnerInsert(TreeNode node, int value)
    {
      if (node == null) return;
      //判断是否在这个节点范围内
      if (value >= node.ValueFrom && value < node.ValueTo)
      {
        //更新节点总数信息
        node.Count++;
        //更新左子节点
        InnerInsert(node.LeftChildNode, value);
        //更新右子节点
        InnerInsert(node.RightChildNode, value);
      }
    }

   /// <summary>
    /// 从树中获取总排名
    /// </summary>
    /// <param name="value"></param>
    /// <returns></returns>
    public int GetRank(int value)
    {
      if (value < 0) return 0;
      return InnerGet(_root, value);
    }

    /// <summary>
    /// 遍历子节点获取累计排名
    /// </summary>
    /// <param name="node"></param>
    /// <param name="value"></param>
    /// <returns></returns>
    private int InnerGet(TreeNode node, int value)
    {
      if (node.LeftChildNode == null || node.RightChildNode == null) return 1;
      if (value >= node.LeftChildNode.ValueFrom && value < node.LeftChildNode.ValueTo)
      {
        //当这个值存在于左子节点中时，要累加右子节点的总数（表示这个数在多少名之后）
        return node.RightChildNode.Count + InnerGet(node.LeftChildNode, value);
      }
      else
      {
        //如果在右子节点中就继续遍历
        return InnerGet(node.RightChildNode, value);
      }
    }
