Unity UGUI实现卡片椭圆方向滚动

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
using UnityEngine;
using System.Collections;
using UnityEngine.UI;
using DG.Tweening;
public class CardMove : MonoBehaviour {
 GameObject[] sprites;
 int halfSize;
 Vector2 screenCenterPos;
 public float startAngle;//中间卡牌的角度
 public float deltaAngle;//相邻卡牌的角度差值
 public float moveSpeed;//移动动画的速度

 public Vector3 center;//椭圆中心点
 public float A = 1;//long axis
 public float B = 1;//short axis
 int cardcount;
 // Use this for initialization
 void Start () {
  init ();
 }

 // Update is called once per frame
 void Update () {

 }
 /// <summary>
 /// 初始化卡牌显示位置
 /// </summary>
 void init(){
  screenCenterPos = new Vector2 (Screen.width*0.5f,Screen.height*0.5f);
  cardcount = transform.childCount;
   halfSize = (cardcount - 1) / 2;
  sprites=new GameObject[cardcount];
  for (int i = 0; i < cardcount; i++) {
   sprites [i] = transform.GetChild (i).gameObject;
   setPosition (i,false);
   setDeeps (i);

  }

 }
 /// <summary>
 /// 椭圆的半长轴为A，半短轴为B，计算椭圆上一点的位置
 /// x=A*cos(angle),y=B*sin(angle)
 /// </summary>
 /// <param name="index">Index.</param>
 /// <param name="userTweener">是否使用tween动画.</param>
 void setPosition(int index,bool userTweener=true){
  //计算每一张卡片在椭圆上相对中间卡牌的角度
  float angle = 0;
  if(index<halfSize){//left
   angle=startAngle-(halfSize-index)*deltaAngle;

  }else if(index>halfSize){//right

   angle = startAngle + (index - halfSize) * deltaAngle;
  }else{//medim
   angle=startAngle;
  }


  //通过卡牌的角度，计算对应的位置
  float xpos = A*Mathf.Cos((angle/180)*Mathf.PI);//+center.x;
  float ypos = B*Mathf.Sin((angle/180)*Mathf.PI);//+center.y;
  Debug.Log ("index="+index+",xpos="+xpos+",ypos="+ypos);

  Vector2 pos = new Vector2 (xpos,ypos);
//  Debug.Log ("screenPos="+screenPos+",wordPos="+wordPos);

//通过doTween控制卡片移动动画
  if(!userTweener){
   sprites [index].GetComponent<Image> ().rectTransform.DOMove(new Vector2(screenCenterPos.x+pos.x,screenCenterPos.y+pos.y),0f);
  }else
   sprites [index].GetComponent<Image> ().rectTransform.DOMove(new Vector2(screenCenterPos.x+pos.x,screenCenterPos.y+pos.y),1f);

 }
 /// <summary>
 /// 计算每一张卡片的层级
 /// </summary>
 /// <param name="index">Index.</param>
 void setDeeps(int index){
  int deep = 0;
  if (index < halfSize) {//左侧卡牌层级，从左侧到中间，层级依此递增
   deep=index;
  } else if (deep > halfSize) {//右侧卡牌层级，从中间到右侧，层级依此递减
   deep=sprites.Length-(index+1);
  } else {
   deep = halfSize;
  }

  sprites [index].GetComponent<RectTransform> ().SetSiblingIndex (deep);
 }
 /// <summary>
 /// 左侧按钮点击，向左移动
 /// </summary>
 public void OnLeftBtnClick(){
  int length = sprites.Length;

  GameObject temp=sprites[0];
  for (int i = 0; i < length; i++) {//移动卡片在数组中的位置，依此向前移动一位
   if (i == length - 1)
    sprites [i] = temp;
   else
    sprites [i] = sprites [i + 1];
  }

  for (int i = 0; i < length; i++) {//跟新数组卡片需要显示的位置和层级
   setPosition (i);
   setDeeps (i);
  }
 }

 /// <summary>
 /// 右侧按钮点击，向右移动
 /// </summary>
 public void RightBtnClick(){
  int length = sprites.Length;

  GameObject temp=sprites[length-1];
  for (int i = length-1; i >=0; i--) {
   if (i == 0)
    sprites [i] = temp;
   else
    sprites [i] = sprites [i - 1];
  }
  for (int i = 0; i < length; i++) {
   setPosition (i);
   setDeeps (i);
  }
 }
}
