我是靠谱客的博主 自然流沙,最近开发中收集的这篇文章主要介绍基于Vue+Openlayer实现动态加载geojson的方法,觉得挺不错的,现在分享给大家,希望可以做个参考。

概述

加载1个或多个要素

<template>
  <div id="map" style="width: 100vw; height: 100vh"></div>
</template>
<script>
import "ol/ol.css";
import TileLayer from "ol/layer/Tile";
import VectorLayer from "ol/layer/Vector";
import VectorSource from "ol/source/Vector";
import XYZ from "ol/source/XYZ";
import { Map, View, Feature, ol } from "ol";
import { Style, Stroke, Fill } from "ol/style";
import { Polygon, MultiPolygon } from "ol/geom";

import areaGeo from "@/assets/chengdu.json";

export default {
  data() {
    return {
      map: {},
      areaLayer: {},
    };
  },
  mounted() {
    this.initMap(); //初始化地图方法
    this.addArea(areaGeo); //添加区域图层方法
    this.pointMove();
    this.getFeatureByClick();
  },
  methods: {
    pointMove() {
      // 设置鼠标划过矢量要素的样式
      this.map.on("pointermove", (e) => {
        const isHover = this.map.hasFeatureAtPixel(e.pixel);
        this.map.getTargetElement().style.cursor = isHover ? "pointer" : "";
      });
    },
    getFeatureByClick() {
      this.map.on("click", (e) => {
        let features = this.map.getFeaturesAtPixel(e.pixel);
        this.map.getView().fit(features[0].getGeometry(), {
          duration: 1500,
          padding: [100, 100, 100, 100],
        });
      });
    },
    /**
     * 设置区域
     */
    addArea(geo = {}) {
      if (Object.keys(geo).length == 0 && geo.features.length == 0) return;

      // 设置图层
      this.areaLayer = new VectorLayer({
        source: new VectorSource({
          features: [],
        }),
      });
      // 添加图层
      this.map.addLayer(this.areaLayer);

      let features = geo.features;

      for (let i in features) {
        let areaFeature = {};

        if (features[i].geometry.type == "MultiPolygon") {
          areaFeature = new Feature({
            geometry: new MultiPolygon(features[i].geometry.coordinates),
          });
        } else if (features[i].geometry.type == "Polygon") {
          areaFeature = new Feature({
            geometry: new Polygon(features[i].geometry.coordinates),
          });
        }
        areaFeature.setStyle(
          new Style({
            fill: new Fill({ color: "#4e98f444" }),
            stroke: new Stroke({
              width: 3,
              color: [71, 137, 227, 1],
            }),
          })
        );
        areaFeature.setProperties(features[i].properties);
        this.areaLayer.getSource().addFeature(areaFeature);
      }
    },
    /**
     * 初始化地图
     */
    initMap() {
      this.map = new Map({
        target: "map",
        layers: [
          new TileLayer({
            source: new XYZ({
              url: "http://map.geoq.cn/ArcGIS/rest/services/ChinaOnlineStreetPurplishBlue/MapServer/tile/{z}/{y}/{x}",
            }),
          }),
        ],
        view: new View({
          projection: "EPSG:4326",
          center: [103, 31],
          zoom: 7,
        }),
      });
    },
  },
};
</script>

到此这篇关于Vue+Openlayer动态加载geojson的文章就介绍到这了,更多相关Vue Openlayer加载geojson内容请搜索靠谱客以前的文章或继续浏览下面的相关文章希望大家以后多多支持靠谱客!

最后

以上就是自然流沙为你收集整理的基于Vue+Openlayer实现动态加载geojson的方法的全部内容,希望文章能够帮你解决基于Vue+Openlayer实现动态加载geojson的方法所遇到的程序开发问题。
