Vue+tracking.js 实现前端人脸检测功能

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
<template>
 <div id="facelogin">
 <h1 class="title is-1">{{FaceisDetected}}</h1>
 <!-- <p>{{FaceisDetected}}</p> -->
 <div class="content-cam">
 <div class="camera-wrp sec">
 <video width="320" height="320" ref="videoDom" id="video_cam" preload autoplay loop muted></video>
 <canvas width="320" height="320" ref="canvasDOM" id="face_detect"></canvas>
 <div class="control-btn"></div>
 </div>
 <div class="images-wrp sec">
 <!-- <p class="title is-5">Image taken</p> -->
 <div
  :class="`img-item img-item-${index}`"
  v-for="(image, index) in images"
  :key="`img-wrp-${index}`"
  :style="`background-image: url('${image}')`"
 ></div>
 </div>
 </div>
 </div>
</template>

export default {
name: 'facelogin',
data() {
return {
count: 0,
isdetected: '请您保持脸部在画面中央',
videoEl: {},
canvasEL: {},
images: [],
trackCcv: false,
trackTracking: false,
autoCaptureTrackTraking: false,
userMediaConstraints: {
audio: false,
video: {
// ideal（应用最理想的）
width: {
min: 320,
ideal: 1280,
max: 1920
},
height: {
min: 240,
ideal: 720,
max: 1080
},
// frameRate受限带宽传输时，低帧率可能更适宜
frameRate: {
min: 15,
ideal: 30,
max: 60
},
// 摄像头翻转
facingMode: 'user'
}
}
}
},
computed: {
FaceisDetected() {
return this.isdetected
}
},
created() {
this.changeView()
},

 mounted() {
 // The getUserMedia interface is used for handling camera input.
 // Some browsers need a prefix so here we're covering all the options
 navigator.getMedia =
 navigator.getUserMedia ||
 navigator.webkitGetUserMedia ||
 navigator.mozGetUserMedia ||
 navigator.msGetUserMedia
 this.init()
 },
 methods: {
 async init() {
 this.videoEl = this.$refs.videoDom
 this.canvasEL = this.$refs.canvasDOM
 await navigator.mediaDevices
 .getUserMedia(this.userMediaConstraints)
 .then(this.getMediaStreamSuccess)
 .catch(this.getMediaStreamError)
 await this.onPlay()
 },
 async onPlay() {
 debugHelper.log('onPlay')


 this.onTrackTracking()
 },
 changeView() {
 this.setTitle('刷脸登陆')
 this.setBackDisabled(false)
 this.setBackIcon('arrow_back')
 msgbus.vm.setBottomNavVisible(false)
 msgbus.vm.setBottomBtnVisible(false)
 msgbus.vm.setMsgInputVisible({ value: false })
 },


 onTrackTracking() {
 const context = this
 const video = this.videoEl
 const canvas = this.canvasEL
 const canvasContext = canvas.getContext('2d')
 let tracker = new tracking.ObjectTracker('face')


 video.pause()
 video.src = ''
 tracker.setInitialScale(4)
 tracker.setStepSize(2)
 tracker.setEdgesDensity(0.1)
 tracking.track('#video_cam', tracker, { camera: true })
 tracker.on('track', function(event) {
 const { autoCaptureTrackTraking } = context
 canvasContext.clearRect(0, 0, canvas.width, canvas.height)
 event.data.forEach(function({ x, y, width, height }) {
  canvasContext.strokeStyle = '#a64ceb'
  canvasContext.strokeRect(x, y, width, height)
  canvasContext.font = '11px Helvetica'
  canvasContext.fillStyle = '#fff'
 })


 if (!isEmpty(event.data) && context.count <= 10) {
  if (context.count < 0) context.count = 0
  context.count += 1
  //debugHelper.log(context.count)
  if (context.count > 10) {
  context.isdetected = '已检测到人脸，正在登录'
  //context.$router.push({ name: 'pwdlogin' })
  }
 } else {
  context.count -= 1
  if (context.count < 0) context.isdetected = '请您保持脸部在画面中央'
  //this.isdetected = '已检测到人脸，正在登录'
 }

 })
 },
 onDownloadFile(item) {
 const link = document.createElement('a')
 link.href = item
 link.download = `cahyo-${new Date().toISOString()}.png`
 link.click()


 link.remove()
 },
 onTakeCam() {
 const canvas = document.createElement('canvas')
 const video = this.$el.querySelector('#video_cam')
 const canvasContext = canvas.getContext('2d')


 if (video.videoWidth && video.videoHeight) {
 const isBiggerW = video.videoWidth > video.videoHeight
 const fixVidSize = isBiggerW ? video.videoHeight : video.videoWidth
 let offsetLeft = 0
 let offsetTop = 0


 if (isBiggerW) offsetLeft = (video.videoWidth - fixVidSize) / 2
 else offsetTop = (video.videoHeight - fixVidSize) / 2


 // make canvas size 300px
 canvas.width = canvas.height = 300
 const { width, height } = canvas


 canvasContext.drawImage(
  video,
  offsetLeft,
  offsetTop,
  fixVidSize,
  fixVidSize,
  0,
  0,
  width,
  height
 )
 const image = canvas.toDataURL('image/png')
 this.images.push(image)
 }
 },
 onDetectFace(param, index) {
 const imgItem = document.querySelector(`.img-item-${index}`)
 const image = new Image()
 image.src = param


 const tracker = new tracking.ObjectTracker('face')
 tracker.setStepSize(1.7)
 tracking.track(image, tracker)


 tracker.on('track', function(event) {
 event.data.forEach(function(rect) {
  window.plot(rect.x, rect.y, rect.width, rect.height)
 })
 })


 window.plot = function(x, y, w, h) {
 const rect = document.createElement('div')
 document.querySelector(`.img-item-${index}`).appendChild(rect)
 rect.classList.add('rect')
 rect.style.width = w + 'px'
 rect.style.height = h + 'px'
 rect.style.left = x + 'px'
 rect.style.top = y + 'px'
 rect.style.border = '2px solid yellow'
 rect.style.position = 'absolute'
 }
 },
 getMediaStreamSuccess(stream) {
 window.stream = stream // make stream available to browser console
 this.videoEl.srcObject = stream
 debugHelper.log('getMediaStreamSuccess1')
 //this.$store.commit('setVideoCanvasObject', this.videoEl)
 debugHelper.log('getMediaStreamSuccess2')
 },
 // 视频媒体流失败
 getMediaStreamError(error) {
 alert('视频媒体流获取错误' + error)
 },
 // 结束媒体流
 stopMediaStreamTrack() {
 clearInterval(this.timeInterval)
 if (typeof window.stream === 'object') {
 this.videoEl.srcObject = null
 //this.$store.commit('setVideoCanvasObject', '')
 window.stream.getTracks().forEach(track => track.stop())
 }
 },
