nginx配置静态文件服务器详解

251 阅读 0 评论 166 点赞

我是靠谱客的博主呆萌鸵鸟，这篇文章主要介绍nginx配置静态文件服务器详解，现在分享给大家，希望可以做个参考。

本文主要介绍一些Nginx做图片服务器的简单配置，但不包括Nginx的安装部署以及实现原理。

配置步骤

下载nginx

Windows nginx安装教程及简单实践

配置nginx\nginx-1.13.4\conf\nginx.conf文件

复制代码

#user nobody;
worker_processes 1;

#error_log logs/error.log;
#error_log logs/error.log notice;
#error_log logs/error.log info;

#pid    logs/nginx.pid;

events {
  worker_connections 1024;
}

http {
  include    mime.types;
  default_type application/octet-stream;

log_format main '$remote_addr - $remote_user [$time_local] "$request" '
           '$status $body_bytes_sent "$http_referer" '
           '"$http_user_agent" "$http_x_forwarded_for"';

access_log logs/access.log main;

sendfile    on;
  #tcp_nopush   on;

#keepalive_timeout 0;
  keepalive_timeout 65;

#gzip on;

server {
    listen    80;
    server_name localhost;

#charset koi8-r;

#access_log logs/host.access.log main;

    location ~ .*\.(gif|jpg|jpeg|png)$ {
      expires 24h;
      root d://pinkylam_server//;#指定图片存放路径
      access_log d://pinkylam_server//images.log;#日志存放路径
      proxy_store on;
      proxy_store_access user:rw group:rw all:rw;
      proxy_temp_path   d://pinkylam_server//;#图片访问路径
      proxy_redirect   off;
      proxy_set_header  Host 127.0.0.1;
      client_max_body_size 10m;
      client_body_buffer_size 1280k;
      proxy_connect_timeout 900;
      proxy_send_timeout  900;
      proxy_read_timeout  900;
      proxy_buffer_size  40k;
      proxy_buffers   40 320k;
      proxy_busy_buffers_size 640k;
      proxy_temp_file_write_size 640k;
      if ( !-e $request_filename)
      {
        proxy_pass http://127.0.0.1;
      }
    }

location / {
      root  html;
      index index.html index.htm;
    }

#error_page 404       /404.html;

# redirect server error pages to the static page /50x.html
    #
    error_page  500 502 503 504 /50x.html;
    location = /50x.html {
      root  html;
    }
  }
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
#user nobody;
worker_processes 1;

#error_log logs/error.log;
#error_log logs/error.log notice;
#error_log logs/error.log info;

#pid    logs/nginx.pid;


events {
  worker_connections 1024;
}


http {
  include    mime.types;
  default_type application/octet-stream;

  log_format main '$remote_addr - $remote_user [$time_local] "$request" '
           '$status $body_bytes_sent "$http_referer" '
           '"$http_user_agent" "$http_x_forwarded_for"';

  access_log logs/access.log main;

  sendfile    on;
  #tcp_nopush   on;

  #keepalive_timeout 0;
  keepalive_timeout 65;

  #gzip on;

  server {
    listen    80;
    server_name localhost;

    #charset koi8-r;

    #access_log logs/host.access.log main;

    location ~ .*\.(gif|jpg|jpeg|png)$ {
      expires 24h;
      root d://pinkylam_server//;#指定图片存放路径
      access_log d://pinkylam_server//images.log;#日志存放路径
      proxy_store on;
      proxy_store_access user:rw group:rw all:rw;
      proxy_temp_path   d://pinkylam_server//;#图片访问路径
      proxy_redirect   off;
      proxy_set_header  Host 127.0.0.1;
      client_max_body_size 10m;
      client_body_buffer_size 1280k;
      proxy_connect_timeout 900;
      proxy_send_timeout  900;
      proxy_read_timeout  900;
      proxy_buffer_size  40k;
      proxy_buffers   40 320k;
      proxy_busy_buffers_size 640k;
      proxy_temp_file_write_size 640k;
      if ( !-e $request_filename)
      {
        proxy_pass http://127.0.0.1;
      }
    }

    location / {
      root  html;
      index index.html index.htm;
    }

    #error_page 404       /404.html;

    # redirect server error pages to the static page /50x.html
    #
    error_page  500 502 503 504 /50x.html;
    location = /50x.html {
      root  html;
    }
  }
}
