function varargout = jiemian(varargin)
% JIEMIAN M-file for jiemian.fig
%      JIEMIAN, by itself, creates a new JIEMIAN or raises the existing
%      singleton*.
%
%      H = JIEMIAN returns the handle to a new JIEMIAN or the handle to
%      the existing singleton*.
%
%      JIEMIAN('CALLBACK',hObject,eventData,handles,...) calls the local
%      function named CALLBACK in JIEMIAN.M with the given input arguments.
%
%      JIEMIAN('Property','Value',...) creates a new JIEMIAN or raises the
%      existing singleton*.  Starting from the left, property value pairs are
%      applied to the GUI before jiemian_OpeningFcn gets called.  An
%      unrecognized property name or invalid value makes property application
%      stop.  All inputs are passed to jiemian_OpeningFcn via varargin.
%
%      *See GUI Options on GUIDE's Tools menu.  Choose "GUI allows only one
%      instance to run (singleton)".
%
% See also: GUIDE, GUIDATA, GUIHANDLES

% Edit the above text to modify the response to help jiemian

% Last Modified by GUIDE v2.5 03-Nov-2012 02:26:28

% Begin initialization code - DO NOT EDIT
    gui_Singleton = 1;
    gui_State = struct('gui_Name',       mfilename, ...
        'gui_Singleton',  gui_Singleton, ...
        'gui_OpeningFcn', @jiemian_OpeningFcn, ...
        'gui_OutputFcn',  @jiemian_OutputFcn, ...
        'gui_LayoutFcn',  [] , ...
        'gui_Callback',   []);
    if nargin && ischar(varargin{1})
        gui_State.gui_Callback = str2func(varargin{1});
    end
    if nargout
        [varargout{1:nargout}] = gui_mainfcn(gui_State, varargin{:});
    else
        gui_mainfcn(gui_State, varargin{:});
    end
% End initialization code - DO NOT EDIT


% --- Executes just before jiemian is made visible.
function jiemian_OpeningFcn(hObject, eventdata, handles, varargin)
% This function has no output args, see OutputFcn.
% hObject    handle to figure
% eventdata  reserved - to be defined in a future version of MATLAB
% handles    structure with handles and user data (see GUIDATA)
% varargin   command line arguments to jiemian (see VARARGIN)

% Choose default command line output for jiemian
    handles.output = hObject;

% Update handles structure
    guidata(hObject, handles);
    clc;
    axes(handles.axes2);
    imshow(imread('logo.jpg'));
    global file;
    global I;
    global vid;
    global P;P=0;
    global n;n=0;
    set(handles.edit1,'String','10');
    set(handles.edit2,'String','0');
    set(handles.edit3,'String','0');
    set(handles.edit4,'String','0');
    set(handles.edit5,'String','0');


% UIWAIT makes jiemian wait for user response (see UIRESUME)
% uiwait(handles.figure1);


% --- Outputs from this function are returned to the command line.
function varargout = jiemian_OutputFcn(hObject, eventdata, handles)
% varargout  cell array for returning output args (see VARARGOUT);
% hObject    handle to figure
% eventdata  reserved - to be defined in a future version of MATLAB
% handles    structure with handles and user data (see GUIDATA)

% Get default command line output from handles structure
    varargout{1} = handles.output;


% --- Executes on button press in pushbutton1.
function pushbutton1_Callback(hObject, eventdata, handles)
% hObject    handle to pushbutton1 (see GCBO)
% eventdata  reserved - to be defined in a future version of MATLAB
% handles    structure with handles and user data (see GUIDATA)
set(handles.edit6,'String','...');
hold off;
global n;n=0;
set(handles.radiobutton1,'value',1);
set(handles.edit1,'String','10');
set(handles.edit3,'String','0');
set(handles.edit4,'String','0');
set(handles.edit5,'String','0');
global P;
if P==8
    global vid;
    axes(handles.axes1);
    I=getsnapshot(vid);
    imshow(I);
    set(handles.edit7,'String','“摄像头拍摄图像”');
else
    [filename,pathname]=uigetfile({'*.jpg';'*.bmp';'*.tif';'*.*'},'打开图像...');
    if isequal(filename,0)|isequal(pathname,0)
        errordlg('图像文件未找到','File Error');
    else
        global file;
        global I;
        P=1;
        file=[pathname,filename];
        I=imread(file);
        axes(handles.axes1);
        imshow(I);
        set(handles.edit7,'String','“元件的原始图像”');
    end
end
set(handles.edit6,'String','OK');


% --- Executes on button press in pushbutton2.
function pushbutton2_Callback(hObject, eventdata, handles)
% hObject    handle to pushbutton2 (see GCBO)
% eventdata  reserved - to be defined in a future version of MATLAB
% handles    structure with handles and user data (see GUIDATA)
set(handles.edit6,'String','...');
hold off;
global file;
global I;
global P;
global n;n=0;
set(handles.radiobutton1,'value',1);
set(handles.edit3,'String','0');
set(handles.edit4,'String','0');
set(handles.edit5,'String','0');
if P==8
    axes(handles.axes1);
    cla reset;
else if P == 0
        errordlg('请先打开图像！','Warning...');
    else
        P=1;
        I=imread(file);
        axes(handles.axes1);
        imshow(I);
        set(handles.edit7,'String','“元件的原始图像”');
    end
end
set(handles.edit6,'String','OK');


% --- Executes on button press in pushbutton3.
function pushbutton3_Callback(hObject, eventdata, handles)
% hObject    handle to pushbutton3 (see GCBO)
% eventdata  reserved - to be defined in a future version of MATLAB
% handles    structure with handles and user data (see GUIDATA)
set(handles.edit6,'String','...');
global P;
if P == 0
    errordlg('请先打开图像！','Warning...');
else
    [filename,pathname]=uiputfile({'*.jpg';'*.bmp';'*.tif';'*.*'},'保存图片...','Undefined');
    if ~isequal(filename,0)
        str = [pathname filename];
        px=getframe(handles.axes1);
        cdata = getappdata(gcf,'Timg');
        imwrite(px.cdata,str);
    else errordlg('保存失败！','Warning...');
    end;
end
set(handles.edit6,'String','OK');


% --- Executes on button press in pushbutton4.
function pushbutton4_Callback(hObject, eventdata, handles)
% hObject    handle to pushbutton4 (see GCBO)
% eventdata  reserved - to be defined in a future version of MATLAB
% handles    structure with handles and user data (see GUIDATA)
set(handles.edit6,'String','...');
global P;
P=0;
set(handles.edit3,'String','0');
set(handles.edit4,'String','0');
set(handles.edit5,'String','0');
axes(handles.axes1);
cla reset;
closepreview;
set(handles.edit7,'String','“请先打开图像”');
set(handles.edit6,'String','OK');


% --- Executes on button press in pushbutton5.
function pushbutton5_Callback(hObject, eventdata, handles)
% hObject    handle to pushbutton5 (see GCBO)
% eventdata  reserved - to be defined in a future version of MATLAB
% handles    structure with handles and user data (see GUIDATA)
set(handles.edit6,'String','...');
global I;
global P;
switch P
    case 7,errordlg('图像已经完成二值化，请直接测距或复位！','Warning...');
    case 6,errordlg('图像已经增强对比度，请放弃该操作或复位！','Warning...');
    case 5,errordlg('已经截取目标，请放弃该操作或复位！','Warning...');
    case 4,errordlg('已经选取标定目标，请放弃该操作或复位！','Warning...');
    case 3,errordlg('图像已经完成几何校正，请放弃该操作或复位！','Warning...');
    case 2,errordlg('图像已经完成中值滤波，请放弃该操作或复位！','Warning...');
    case 1,P=2;
        I=rgb2gray(I);                                          %转化为灰度
        I=medfilt2(I,[3 3]);                                     %中值滤波
        axes(handles.axes1);
        imshow(I);
        set(handles.edit7,'String','“中值滤波后的元件图像”');
    case 0,errordlg('请先打开图像！','Warning...');
end
