概述

网关的核心功能

动态路由

灰度发布

授权认证

性能监控

系统日志

数据缓存

限流熔断

目前业内的技术方案

Zuul
基于Java开发，核心网关功能都比较简单，但是比如灰度发布、限流、动态路由之类的，很多都要自己做二次开发
高并发能力不强，部署到一些机器上去，还要基于Tomcat来部署，Spring Boot用Tomcat把网关系统跑起来；Java语言开发，可以直接把控源码，可以做二次开发封装各种需要的功能

Kong
依托于Nginx实现，OpenResty，lua实现的模块，现成的一些插件，可以直接使用

Nginx+lua、自研网关
Nginx抗高并发的能力很强，少数几台机器部署一下，就可以抗很高的并发

动态路由

一般新增修改网关需要重启服务让网关生效，那会很麻烦，生产环境绝对不能这么做

可以基于二次开发，重写刷新网关路由配置

可以简单弄一个web项目

对配置的网关弄一个增删改查的功能

如果开发某个服务之后，可以在这个功能里面配置一下

表设计

CREATE TABLE `gateway_api_route` (
   `id` varchar(50) NOT NULL,
   `path` varchar(255) NOT NULL,
   `service_id` varchar(50) DEFAULT NULL,
   `url` varchar(255) DEFAULT NULL,
   `retryable` tinyint(1) DEFAULT NULL,
   `enabled` tinyint(1) NOT NULL,
   `strip_prefix` int(11) DEFAULT NULL,
   `api_name` varchar(255) DEFAULT NULL,
   PRIMARY KEY (`id`)
 ) ENGINE=InnoDB DEFAULT CHARSET=utf8

INSERT INTO gateway_api_route (id, path, service_id, retryable, strip_prefix, url, enabled) VALUES ('order-service', '/order/**', 'order-service',0,1, NULL, 1);

核心代码
@Configuration
public class DynamicRouteConfiguration {

    @Autowired
    private ZuulProperties zuulProperties;
    @Autowired
    private ServerProperties server;
    @Autowired
    private JdbcTemplate jdbcTemplate;

    @Bean
    public DynamicRouteLocator routeLocator() {
    	DynamicRouteLocator routeLocator = new DynamicRouteLocator(
    			this.server.getServletPrefix(), this.zuulProperties);
        routeLocator.setJdbcTemplate(jdbcTemplate);
        return routeLocator;
    }

}
----
public class DynamicRouteLocator extends SimpleRouteLocator implements RefreshableRouteLocator {

    private JdbcTemplate jdbcTemplate;
    private ZuulProperties properties;

    public void setJdbcTemplate(JdbcTemplate jdbcTemplate) {
        this.jdbcTemplate = jdbcTemplate;
    }

    public DynamicRouteLocator(String servletPath, ZuulProperties properties) {
        super(servletPath, properties);
        this.properties = properties;
    }

    @Override
    public void refresh() {
        doRefresh();
    }

    @Override
    protected Map<String, ZuulProperties.ZuulRoute> locateRoutes() {
        LinkedHashMap<String, ZuulProperties.ZuulRoute> routesMap = new LinkedHashMap<>();
        // 加载application.yml中的路由表
        routesMap.putAll(super.locateRoutes());
        // 加载db中的路由表
        routesMap.putAll(locateRoutesFromDB());

        // 统一处理一下路由path的格式
        LinkedHashMap<String, ZuulProperties.ZuulRoute> values = new LinkedHashMap<>();
        for (Map.Entry<String, ZuulProperties.ZuulRoute> entry : routesMap.entrySet()) {
            String path = entry.getKey();
            if (!path.startsWith("/")) {
                path = "/" + path;
            }
            if (StringUtils.hasText(this.properties.getPrefix())) {
                path = this.properties.getPrefix() + path;
                if (!path.startsWith("/")) {
                    path = "/" + path;
                }
            }
            values.put(path, entry.getValue());
        }

        System.out.println("路由表：" + values);

        return values;
    }

    private Map<String, ZuulProperties.ZuulRoute> locateRoutesFromDB() {
        Map<String, ZuulProperties.ZuulRoute> routes = new LinkedHashMap<>();

        List<GatewayApiRoute> results = jdbcTemplate.query(
        		"select * from gateway_api_route where enabled = true ",
        		new BeanPropertyRowMapper<>(GatewayApiRoute.class));

        for (GatewayApiRoute result : results) {
            if (StringUtils.isEmpty(result.getPath()) ) {
                continue;
            }
            if (StringUtils.isEmpty(result.getServiceId()) && StringUtils.isEmpty(result.getUrl())) {
                continue;
            }
            ZuulProperties.ZuulRoute zuulRoute = new ZuulProperties.ZuulRoute();
            try {
                BeanUtils.copyProperties(result, zuulRoute);
            } catch (Exception e) {
            	e.printStackTrace();
            }
            routes.put(zuulRoute.getPath(), zuulRoute);
        }

        return routes;
    }

}

---
public class GatewayApiRoute {

	private String id;
	private String path;
	private String serviceId;
	private String url;
	private boolean stripPrefix = true;
	private Boolean retryable;
	private Boolean enabled;
}
---
@Component
@Configuration
@EnableScheduling
public class RefreshRouteTask {

	@Autowired
    private ApplicationEventPublisher publisher;
    @Autowired
    private RouteLocator routeLocator;

    @Scheduled(fixedRate = 5000)
    private void refreshRoute() {
        System.out.println("定时刷新路由表");
        RoutesRefreshedEvent routesRefreshedEvent = new RoutesRefreshedEvent(routeLocator);
        publisher.publishEvent(routesRefreshedEvent);
    }

}
---

@SpringBootApplication
@EnableZuulProxy
public class ZuulGatewayApplication {

	public static void main(String[] args) {
		SpringApplication.run(ZuulGatewayApplication.class, args);
	}

}
