Android自定义控件仿iOS滑块SwitchButton

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
public class SwitchButton extends View implements View.OnTouchListener {
 private Bitmap bg_on, bg_off, slipper_btn;
 /**
 * 按下时的x和当前的x
 */
 private float downX, nowX;
 /**
 * 记录用户是否在滑动
 */
 private boolean onSlip = false;
 /**
 * 当前的状态
 */
 private boolean nowStatus = false;
 /**
 * 监听接口
 */
 private OnChangedListener listener;
 /**
 * 一个滑动的距离临界值，判断是滑动还是点击
 * getScaledTouchSlop()：
 * Distance in pixels a touch can wander before we think the user is scrolling
 * */
 private int mTouchSlop=new ViewConfiguration().getScaledTouchSlop();

 public SwitchButton(Context context) {
 super(context);
 init();
 }
 public SwitchButton(Context context, AttributeSet attrs) {
 super(context, attrs);
 init();
 }
 public void init(){
 //载入图片资源
 bg_on = BitmapFactory.decodeResource(getResources(), R.mipmap.switch_on_on);
 bg_off = BitmapFactory.decodeResource(getResources(), R.mipmap.switch_off_off);
 slipper_btn = BitmapFactory.decodeResource(getResources(), R.mipmap.switch_ball_ball);
 setOnTouchListener(this);
 }
 protected void onDraw(Canvas canvas) {
 super.onDraw(canvas);
 Matrix matrix = new Matrix();
 Paint paint = new Paint();
 float x = 0;
 //根据nowX设置背景，开或者关状态
 if (nowX < (bg_on.getWidth()/2)){
 canvas.drawBitmap(bg_off, matrix, paint);//画出关闭时的背景
 }else{
 canvas.drawBitmap(bg_on, matrix, paint);//画出打开时的背景
 }
 if (onSlip) {//是否是在滑动状态,
 if(nowX >= bg_on.getWidth())//是否划出指定范围,不能让滑块跑到外头,必须做这个判断
 x = bg_on.getWidth() - slipper_btn.getWidth()/2;//减去滑块1/2的长度
 else
 x = nowX - slipper_btn.getWidth()/2;
 }else {
 if(nowStatus){//根据当前的状态设置滑块的x值
 x = bg_on.getWidth() - slipper_btn.getWidth();
 }else{
 x = 0;
 }
 }
 //对滑块滑动进行异常处理，不能让滑块出界
 if (x < 0 ){
 x = 0;
 }
 else if(x > bg_on.getWidth() - slipper_btn.getWidth()){
 x = bg_on.getWidth() - slipper_btn.getWidth();
 }
 //画出滑块
 canvas.drawBitmap(slipper_btn, x, 0, paint);
 }

 @Override
 public boolean onTouch(View v, MotionEvent event) {
 switch(event.getAction()){
 case MotionEvent.ACTION_DOWN:{
 if (event.getX() > bg_off.getWidth() || event.getY() > bg_off.getHeight()){
 return false;
 }else{
 onSlip = true;
 downX = event.getX();
 nowX = downX;
 }
 break;
 }
 case MotionEvent.ACTION_MOVE:{
 nowX = event.getX();
 break;
 }
 case MotionEvent.ACTION_UP:{
 DebugLog.e("mTouchSlop:"+mTouchSlop);
 onSlip = false;
 nowX = event.getX();
 float float_distance=nowX - downX;
 int int_disatnce=(int)float_distance;
 DebugLog.e("int_disatnce:"+int_disatnce);
 /**
 * 滑动距离太短，认定是点击事件
 */
 if(Math.abs(int_disatnce)<mTouchSlop){
 if(this.isChecked()){
 this.setChecked(false);
 nowX = 0;
 }else{
 this.setChecked(true);
 nowX = bg_on.getWidth() - slipper_btn.getWidth();
 }
 }else{
 /**
 * 滑动距离足够，认为是滑动事件
 */
 if(event.getX() >= (bg_on.getWidth()/2)){
 nowStatus = true;
 nowX = bg_on.getWidth() - slipper_btn.getWidth();
 }else{
 nowStatus = false;
 nowX = 0;
 }
 }
 if(listener != null){
 listener.OnChanged(SwitchButton.this, nowStatus);
 }
 break;
 }
 }
 //刷新界面
 invalidate();
 return true;
 }
 /**
 * 为WiperSwitch设置一个监听，供外部调用的方法
 * @param listener
 */
 public void setOnChangedListener(OnChangedListener listener){
 this.listener = listener;
 }
 /**
 * 设置滑动开关的初始状态，供外部调用
 * @param checked
 */
 public void setChecked(boolean checked){
 if(checked){
 nowX = bg_off.getWidth();
 }else{
 nowX = 0;
 }
 nowStatus = checked;
 }
 public boolean isChecked() {
 return nowStatus;
 }
 /**
 * 回调接口
 *
 */
 public interface OnChangedListener {
 public void OnChanged(SwitchButton wiperSwitch, boolean checkState);
 }
}

1
2
3
4
5
<com.uestcneon.chuji.changjianglife.share.SwitchButton
 android:id="@+id/user_privacy_state"
 android:layout_width="wrap_content"
 android:layout_height="20dp"
 android:layout_marginLeft="30dp" />
