Android实现Recycleview悬浮粘性头部外加右侧字母导航

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
public class ContactModel {
 private String index;
 private String name;

 public ContactModel(String name){
  this.index = NewFirstLetterUtil.getFirstLetter(name);
  this.name = name;
 }

 public String getIndex() {
  return index;
 }

 public String getName() {
  return name;
 }

}

1
2
3
4
5
6
7
8
List<ContactModel> contacts = new ArrayList<>();
   for (int i=0;i<mTrainCityList.size();i++){
   // ContactModel contactModel = new ContactModel(mTrainCityList.get(i).getCityName());
   contacts.add(new ContactModel(mTrainCityList.get(i).getCityName()));
   Collections.sort(contacts, new LetterComparator());
     }
    mContactModels.addAll(contacts);
    mShowModels.addAll(mContactModels);

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
private void setNewAdapter() {

   ContactsAdapter mAdapter = new ContactsAdapter(mShowModels);
   mMainRecycleview.setLayoutManager(new LinearLayoutManager(this));
   final StickyRecyclerHeadersDecoration headersDecor = new StickyRecyclerHeadersDecoration(mAdapter);
   mMainRecycleview.addItemDecoration(headersDecor);

   mAdapter.setOnItemClickListtener(new ContactsAdapter.OnItemClickListtener() {
    @Override
    public void onItemClick(int pos) {
     // Toast.makeText(TrainNewStartActivity.this,"惦记的pos:"+pos+"数据:"+mShowModels.get(pos).getName(),Toast.LENGTH_SHORT).show();
     Intent intent = new Intent();
     intent.putExtra("data", mShowModels.get(pos).getName());
     Log.d("lwp","data:"+mShowModels.get(pos).getName());
     setResult(RESULT_OK, intent);
     finish();
    }
   });
   mMainRecycleview.setAdapter(mAdapter);
   mMain_side_bar.setLazyRespond(false);
   // 侧边设置相关
   mMain_side_bar.setOnSelectIndexItemListener(new WaveSideBarView.OnSelectIndexItemListener() {
    @Override
    public void onSelectIndexItem(String letter) {
     for (int i = 0; i< mContactModels.size(); i++) {
      if (mContactModels.get(i).getIndex().equals(letter)) {
       ((LinearLayoutManager) mMainRecycleview.getLayoutManager()).scrollToPositionWithOffset(i, 0);
       return;
      }
     }
    }
   });
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
public class ContactsAdapter extends RecyclerView.Adapter<ContactsAdapter.ContactsViewHolder> implements StickyRecyclerHeadersAdapter {

 private List<ContactModel> contacts;
 private static final String TAG = "ContactsAdapter";
 private ContactModel contact;

 public ContactsAdapter(List<ContactModel> contacts) {
  this.contacts = contacts;
 }

 @Override
 public ContactsViewHolder onCreateViewHolder(ViewGroup parent, int viewType) {
  LayoutInflater inflater = LayoutInflater.from(parent.getContext());
  View view = inflater.inflate(R.layout.layaout_item_contacts, null);
  return new ContactsViewHolder(view);
 }

 @Override
 public void onBindViewHolder(ContactsViewHolder holder, final int position) {
  contact = contacts.get(position);
  Log.e(TAG, "onBindViewHolder: index:" + contact.getIndex());
  if (position == 0 || !contacts.get(position-1).getIndex().equals(contact.getIndex())) {
   holder.tvIndex.setVisibility(View.GONE);
   holder.tvIndex.setText(contact.getIndex());
  } else {
   holder.tvIndex.setVisibility(View.GONE);
  }
  holder.tvName.setText(contact.getName());
  holder.tvName.setOnClickListener(new View.OnClickListener() {
   @Override
   public void onClick(View v) {
    Log.d("lwp","惦记的pos:"+position);
    onItemClickListtener.onItemClick(position);
   }
  });
 }

 public interface OnItemClickListtener{
  void onItemClick(int pos);
 }

 public OnItemClickListtener onItemClickListtener;

 public void setOnItemClickListtener(OnItemClickListtener onItemClickListtener) {
  this.onItemClickListtener = onItemClickListtener;
 }

 @Override
 public long getHeaderId(int position) {
  if (contacts.get(position).getIndex().equals("A")){
   return 0;
  }else if (contacts.get(position).getIndex().equals("B")){
   return 1;
  }else if (contacts.get(position).getIndex().equals("C")){
   return 2;
  }else if (contacts.get(position).getIndex().equals("D")){
   return 3;
  }else if (contacts.get(position).getIndex().equals("E")){
   return 4;
  }else if (contacts.get(position).getIndex().equals("F")){
   return 5;
  }else if (contacts.get(position).getIndex().equals("G")){
   return 6;
  }else if (contacts.get(position).getIndex().equals("H")){
   return 7;
  }else if (contacts.get(position).getIndex().equals("I")){
   return 8;
  }else if (contacts.get(position).getIndex().equals("J")){
   return 9;
  }else if (contacts.get(position).getIndex().equals("K")){
   return 10;
  }else if (contacts.get(position).getIndex().equals("L")){
   return 11;
  }else if (contacts.get(position).getIndex().equals("M")){
   return 12;
  }else if (contacts.get(position).getIndex().equals("N")){
   return 13;
  }else if (contacts.get(position).getIndex().equals("O")){
   return 14;
  }else if (contacts.get(position).getIndex().equals("P")){
   return 15;
  }else if (contacts.get(position).getIndex().equals("Q")){
   return 16;
  }else if (contacts.get(position).getIndex().equals("R")){
   return 17;
  }else if (contacts.get(position).getIndex().equals("S")){
   return 18;
  }else if (contacts.get(position).getIndex().equals("T")){
   return 19;
  }else if (contacts.get(position).getIndex().equals("U")){
   return 20;
  }else if (contacts.get(position).getIndex().equals("V")){
   return 21;
  }else if (contacts.get(position).getIndex().equals("Y")){
   return 22;
  }else if (contacts.get(position).getIndex().equals("X")){
   return 23;
  }else if (contacts.get(position).getIndex().equals("Y")){
   return 24;
  }else if (contacts.get(position).getIndex().equals("Z")){
   return 25;
  }else {
   return -1;
  }

 }

 @Override
 public RecyclerView.ViewHolder onCreateHeaderViewHolder(ViewGroup parent) {
  View view = LayoutInflater.from(parent.getContext())
    .inflate(R.layout.view_header, parent, false);
  return new RecyclerView.ViewHolder(view) {
  };
 }

 @Override
 public void onBindHeaderViewHolder(RecyclerView.ViewHolder holder, int position) {
  TextView textView = (TextView) holder.itemView;
  textView.setText(String.valueOf(contacts.get(position).getIndex()));
 }

 @Override
 public int getItemCount() {
  return contacts.size();
 }

 class ContactsViewHolder extends RecyclerView.ViewHolder {
  TextView tvIndex;
  ImageView ivAvatar;
  TextView tvName;

  ContactsViewHolder(View itemView) {
   super(itemView);
   tvIndex = (TextView) itemView.findViewById(R.id.tv_index);
   ivAvatar = (ImageView) itemView.findViewById(R.id.iv_avatar);
   tvName = (TextView) itemView.findViewById(R.id.tv_name);
  }
 }
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
 android:orientation="vertical"
 android:layout_width="match_parent"
 android:layout_height="match_parent">

 <TextView
  android:id="@+id/tv_index"
  android:layout_width="match_parent"
  android:layout_height="wrap_content"
  android:paddingLeft="12dp"
  android:text="A"
  android:textSize="14sp"
  android:background="#E0E0E0"/>

 <RelativeLayout
  android:layout_width="match_parent"
  android:layout_height="wrap_content"
  android:background="?android:attr/selectableItemBackground">
  <ImageView
   android:id="@+id/iv_avatar"
   android:layout_width="40dp"
   android:layout_height="40dp"
   android:visibility="gone"
   android:layout_margin="10dp"
   />

  <TextView
   android:id="@+id/tv_name"
   android:layout_marginLeft="12dp"
   android:layout_width="wrap_content"
   android:layout_height="34dp"
   android:layout_toRightOf="@+id/iv_avatar"
   android:text="南尘"
   android:gravity="center_vertical"
   android:textColor="#424242"
   android:textSize="16sp"
   android:layout_centerVertical="true" />
 </RelativeLayout>

 <View
  android:layout_width="match_parent"
  android:layout_height="1dp"
  android:layout_marginLeft="15dp"
  android:background="#e8e8e8" />
</LinearLayout>

1
2
3
4
5
6
7
8
9
10
11
12
13
14
<?xml version="1.0" encoding="utf-8"?>

<TextView
 xmlns:android="http://schemas.android.com/apk/res/android"
 xmlns:tools="http://schemas.android.com/tools"
 android:orientation="horizontal"
 android:layout_width="match_parent"
 android:layout_height="wrap_content"
 android:paddingLeft="12dp"
 android:textSize="14sp"
 android:textStyle="bold"
 android:background="#E0E0E0"
 tools:text="Animals starting with A"
 />

1
2
compile 'com.github.nanchen2251:WaveSideBar:1.0.6'
compile 'com.timehop.stickyheadersrecyclerview:library:0.4.3@aar'
