Android实现两圆点之间来回移动加载进度

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
package com.kincai.testcustomview_dotalternatelyprogress;

import android.content.Context;
import android.content.res.TypedArray;
import android.graphics.Canvas;
import android.graphics.Paint;
import android.support.annotation.Nullable;
import android.support.v4.content.ContextCompat;
import android.util.AttributeSet;
import android.util.Log;
import android.view.View;

/**
 * Copyright (C) 2015 The KINCAI Open Source Project
 * .
 * Create By KINCAI
 * .
 * Time 2017-06-16 21:44
 * .
 * Desc 两个源点来回移动
 */

public class DotAlternatelyView extends View {
 private final String TAG = this.getClass().getSimpleName();
 private Paint mPaint = new Paint();
 /**
  * 可视为左边圆点颜色值
  */
 private int mLeftColor;
 /**
  * 可视为右边圆点颜色值
  */
 private int mRightColor;
 /**
  * 圆点半径
  */
 private int mDotRadius;
 /**
  * 圆点间距
  */
 private int mDotSpacing;
 /**
  * 圆点位移量
  */
 private float mMoveDistance;
 /**
  * 圆点移动率
  */
 private float mMoveRate;
 /**
  * 以刚开始左边圆点为准 向右移
  */
 private final int DOT_STATUS_RIGHT = 0X101;
 /**
  * 以刚开始左边圆点为准 圆点移动方向-向左移
  */
 private final int DOT_STATUS_LEFT = 0X102;
 /**
  * 以刚开始左边圆点为准，圆点移动方向
  */
 private int mDotChangeStatus = DOT_STATUS_RIGHT;
 /**
  * 圆点透明度变化最大(也就是透明度在255-mAlphaChangeTotal到255之间)
  */
 private int mAlphaChangeTotal = 130;
 /**
  * 透明度变化率
  */
 private float mAlphaChangeRate;
 /**
  * 透明度改变量
  */
 private float mAlphaChange;

 public DotAlternatelyView(Context context) {
  this(context, null);
 }

 public DotAlternatelyView(Context context, @Nullable AttributeSet attrs) {
  this(context, attrs, 0);
 }

 public DotAlternatelyView(Context context, @Nullable AttributeSet attrs, int defStyleAttr) {
  super(context, attrs, defStyleAttr);
  TypedArray typedArray = context.obtainStyledAttributes(attrs, R.styleable.DotAlternatelyView, defStyleAttr, 0);
  initAttributes(typedArray);
  typedArray.recycle();
  init();
 }

 private void initAttributes(TypedArray Attributes) {
  mLeftColor = Attributes.getColor(R.styleable.DotAlternatelyView_dot_dark_color, ContextCompat.getColor(getContext(), R.color.colorPrimary));
  mRightColor = Attributes.getColor(R.styleable.DotAlternatelyView_dot_light_color, ContextCompat.getColor(getContext(), R.color.colorAccent));
  mDotRadius = Attributes.getDimensionPixelSize(R.styleable.DotAlternatelyView_dot_radius, DensityUtils.dp2px(getContext(), 3));
  mDotSpacing = Attributes.getDimensionPixelSize(R.styleable.DotAlternatelyView_dot_spacing, DensityUtils.dp2px(getContext(), 6));
  mMoveRate = Attributes.getFloat(R.styleable.DotAlternatelyView_dot_move_rate, 1.2f);
 }

 /**
  * 初始化
  */
 private void init() {
  //移动总距离/移动率 = alpha总变化/x
  //x = 移动率 * alpha总变化 / 移动总距离
  mAlphaChangeRate = mMoveRate * mAlphaChangeTotal / (mDotRadius * 2 + mDotSpacing);
  mPaint.setColor(mLeftColor);
  mPaint.setAntiAlias(true);
  mPaint.setStyle(Paint.Style.FILL);
  Log.e(TAG, " aaaa " + mAlphaChangeRate);
 }

 @Override
 protected void onMeasure(int widthMeasureSpec, int heightMeasureSpec) {
  //测量宽高
  int widthMode = MeasureSpec.getMode(widthMeasureSpec);
  int widthSize = MeasureSpec.getSize(widthMeasureSpec);
  int heightMode = MeasureSpec.getMode(heightMeasureSpec);
  int heightSize = MeasureSpec.getSize(heightMeasureSpec);
  int width;
  int height;

  if (widthMode == MeasureSpec.EXACTLY) {
   width = widthSize;
   Log.e(TAG, "onMeasure MeasureSpec.EXACTLY widthSize=" + widthSize);
  } else {
   //指定最小宽度所有圆点加上间距的宽度, 以最小半径加上间距算总和再加上最左边和最右边变大后的距离
   width = (mDotRadius * 2) * 2 + mDotSpacing;
   Log.e(TAG, "onMeasure no MeasureSpec.EXACTLY widthSize=" + widthSize + " width=" + width);
   if (widthMode == MeasureSpec.AT_MOST) {
    width = Math.min(width, widthSize);
    Log.e(TAG, "onMeasure MeasureSpec.AT_MOST width=" + width);
   }

  }

  if (heightMode == MeasureSpec.EXACTLY) {
   height = heightSize;
   Log.e(TAG, "onMeasure MeasureSpec.EXACTLY heightSize=" + heightSize);
  } else {
   height = mDotRadius * 2;
   Log.e(TAG, "onMeasure no MeasureSpec.EXACTLY heightSize=" + heightSize + " height=" + height);
   if (heightMode == MeasureSpec.AT_MOST) {
    height = Math.min(height, heightSize);
    Log.e(TAG, "onMeasure MeasureSpec.AT_MOST height=" + height);
   }

  }
  setMeasuredDimension(width, height);
 }

 @Override
 protected void onDraw(Canvas canvas) {
  //左边圆点起点x轴
  int startPointX = getWidth() / 2 - (2 * mDotRadius * 2 + mDotSpacing) / 2 + mDotRadius;
  //左边圆点起点y轴
  int startPointY = getHeight() / 2;
  //向右移 位移要增加对应透明度变化量也需要增加 反之都需要减小
  if (mDotChangeStatus == DOT_STATUS_RIGHT) {
   mMoveDistance += mMoveRate;
   mAlphaChange += mAlphaChangeRate;
  } else {
   mAlphaChange -= mAlphaChangeRate;
   mMoveDistance -= mMoveRate;
  }
  Log.e(TAG, "mAlphaChange " + mAlphaChange);
  //当移动到最右 那么需要改变方向 反过来
  if (mMoveDistance >= mDotRadius * 2 + mDotSpacing && mDotChangeStatus == DOT_STATUS_RIGHT) {
   mDotChangeStatus = DOT_STATUS_LEFT;
   mMoveDistance = mDotRadius * 2 + mDotSpacing;
   mAlphaChange = mAlphaChangeTotal;
  } else if (mMoveDistance <= 0 && mDotChangeStatus == DOT_STATUS_LEFT) { //当移动到最座 那么需要改变方向 反过来
   mDotChangeStatus = DOT_STATUS_RIGHT;
   mMoveDistance = 0f;
   mAlphaChange = 0f;
  }

  //因为两个圆点可能会给定不同的颜色来显示 所以提供两种颜色设置mLeftColor和mRightColor
  mPaint.setColor(mLeftColor);
  mPaint.setAlpha((int) (255 - mAlphaChange));
  canvas.drawCircle(startPointX + mMoveDistance, startPointY, mDotRadius, mPaint);
  mPaint.setColor(mRightColor);
  mPaint.setAlpha((int) (255 - mAlphaChange));
  canvas.drawCircle(startPointX + mDotRadius * 2 - mMoveDistance + mDotSpacing, startPointY, mDotRadius, mPaint);

  invalidate();
 }
}
