概述
目录
一些参考博客：
tensorflow2.0 和tensorflow1.0的区别
第一种方式：为自定义各种模块
需要导入的模块有:
构建网络的命令为:
函数 DNN_model（）的定义如下:
第二种方式:序列化定义 Dense Net(缺点：每一层难操作)
第三种方式:使用Keras的API 显式定义 Dense Net(这种策略好)
说明
一些参考博客：
在 TensorFlow 2.x 版本中，可以使用三种方式来构建 Keras 模型，分别是 Sequential ， 函数式 (Functional) API 以及自定义模型 (Subclassed)。
1、Tensorflow学习笔记2-Keras六步法搭建神经网络模型https://blog.csdn.net/qq_44711932/article/details/107940180
2、TensorFlow2.0(二)--Keras构建神经网络分类模型https://blog.csdn.net/qq_42580947/article/details/105296103
3、TensorFlow2神经网络训练 https://blog.csdn.net/zhouchen1998/article/details/102572264
4、TensorFlow2.0 (6) 自构建神经网络层—— transformer 实例讲解 https://blog.csdn.net/xm961217/article/details/107787737
5、TensorFlow 2.x 常用API https://blog.csdn.net/myarrow/article/details/108800167
6、tensorflow2.0自定义模型的三种方法总结 https://blog.csdn.net/weixin_45147782/article/details/108588178
7、全连接层tf.keras.layers.Dense()介绍https://blog.csdn.net/qq_38251616/article/details/115632249
8、tensorflow2.0中Layer的__init__()，build(), call()函数 https://blog.csdn.net/qq_32623363/article/details/104128497
9、tensorflow2 中关于自定义层的build() 和 call()一点探究 https://blog.csdn.net/weixin_37598106/article/details/106693120
10、Keras学习笔记12——keras.initializers https://blog.csdn.net/winter_python/article/details/108706123
看了很多教程，无论是序列方法还是subclass方法，都是逐层定义网络的方法，且需要自己手动设定每层的维度。这里介绍一种提供输入维度，输出维度，隐藏层数目列表，构建全连接神经网络（DNN）的一种方式。
tensorflow2.0 和tensorflow1.0的区别
本人在训练网络的时候发现tensorflow2.X 比之前在TensorFlow1.X上慢了好多。如下为一些相关的博客。
1、tensorflow2.0 和tensorflow1.0的区别 https://blog.csdn.net/qq_38978225/article/details/108942427
2、tensorflow2.0 与tensorflow1.0的性能区别 https://blog.csdn.net/luoganttcc/article/details/93497326
第一种方式：为自定义各种模块
需要导入的模块有:
import os
import sys
import tensorflow as tf
import numpy as np
import matplotlib
import platform
import shutil
import time
import Model_base构建网络的命令为:
model = DNN_model(indim=input_dim, outdim=out_dim, hidden_list=hidden_layer,
init_opt2model=init_model, name2DNN_Model=name2base_model, opt2regular_WB=regular_wb_model,
penalty2WB=penalty2weight_biases, actName=actFun)这里:
indim 为输入维度;
outdim 为输出维度；
hidden_list 为隐藏层神经元数目，为元组或者列表。如hidden_list=(20,30,30,40,10) or hidden_list=[20,30,30,40,10]
init_opt2model 为初始化网络weights和biases的方式；
name2DNN_model为要使用的网络模式
opt2regular_WB为正则化权重和偏置的方式
penalty2WB 正则化权重和偏置的系数
actName：隐藏层之间的激活函数
scope2w和scope2b: 为weight和bias指定命名空间。为了使DNN_model 派生不同的网络。如果只派生一个网络，可省略。
如:
DNN1 = DNN_model(。。。。）
DNN2 = DNN_model(。。。。）
注：我们每个*DNN网络都是线性输出，可以调整。如需要调整，对actName2out赋一个字符串，指定要使用的激活函数，如：relu,leakly_relu,tanh,elu,sigmoid等
函数 DNN_model（）的定义如下:
class DNN_model(tf.keras.Model):
def __init__(self, indim=1, outdim=1, hidden_list=None, init_opt2model='DNN_Base', name2DNN_Model='DNN',
opt2regular_WB='L1', penalty2WB=0.001, actName='tanh', actName2out='linear', scope2w='Weight',
scope2b='Bias'):
super(DNN_model, self).__init__()
self.indim = indim
self.outdim = outdim
self.hidden_list = hidden_list
self.init_opt2model = init_opt2model
self.name2DNN_Model = name2DNN_Model
self.opt2regular_WB = opt2regular_WB
self.penalty2WB = penalty2WB
self.actName = actName
self.actName2out = actName2out
init_NN = Model_base.Xavier_init_NN(indim=self.indim, outdim=self.outdim, hiddens=self.hidden_list,
flag2Weight=scope2w, flag2Bias=scope2b)
self.Weigths, self.Biases = init_NN.init_WB()
self.DNN = Model_base.DNN(indim=self.indim, outdim=self.outdim, hiddens=self.hidden_list, Ws=self.Weigths,
Bs=self.Biases, actName=self.actName, actName2Out=self.actName2out)
def call(self, inputs, training=None, mask=None):
out = self.DNN(inputs)
return out构建这个模块所要使用的基本操作如下: 我们定义为一个Model_base.py文件
# -*- coding: utf-8 -*-
"""
Created on 2021.06.15
@author: LXA
"""
import tensorflow as tf
import numpy as np
# ------------------------------------- my activations ----------------------------------
class my_actFunc(tf.keras.layers.Layer):
def __init__(self, actName='linear'):
super(my_actFunc, self).__init__()
self.actName = actName
def call(self, x_input):
if str.lower(self.actName) == 'relu':
out_x = tf.nn.relu(x_input)
elif str.lower(self.actName) == 'leaky_relu':
out_x = tf.nn.leaky_relu(x_input)
elif str.lower(self.actName) == 'tanh':
out_x = tf.nn.relu(x_input)
elif str.lower(self.actName) == 'elu':
out_x = tf.nn.elu(x_input)
elif str.lower(self.actName) == 'sin':
out_x = tf.sin(x_input)
elif str.lower(self.actName) == 'sigmoid':
out_x = tf.nn.sigmoid(x_input)
else:
out_x = x_input
return out_x
# ----------------------------- initialize weights and bias -----------------------------
class Xavier_init_NN(tf.keras.layers.Layer):
def __init__(self, indim=20, outdim=1, flag2Weight='Weight', flag2Bias='Bias', hiddens=None):
super(Xavier_init_NN, self).__init__()
self.outdim = outdim
self.indim = indim
self.flag2w = flag2Weight
self.flag2b = flag2Bias
self.hiddens = hiddens
def Xavier_init_weight(self, in_size=1, out_size=1, flag2Weight='Weight'):
stddev_W = (2.0 / (in_size + out_size)) ** 0.5
w_init = tf.random_normal_initializer(mean=0.0, stddev=stddev_W)
Weight = tf.Variable(initial_value=w_init(shape=(in_size, out_size), dtype='float32'), name=str(flag2Weight),
trainable=True)
return Weight
def Xavier_init_bias(self, in_size=1, out_size=1, flag2Bias='Bias'):
stddev_B = (2.0 / (in_size + out_size)) ** 0.5
b_init = tf.random_normal_initializer(mean=0.0, stddev=stddev_B)
Bias = tf.Variable(initial_value=b_init(shape=(out_size,), dtype='float32'), name=str(flag2Bias),
trainable=True)
return Bias
def init_WB(self):
W_list=[]
B_list=[]
n_hiddens = len(self.hiddens)
w_in = self.Xavier_init_weight(in_size=self.indim, out_size=(self.hiddens)[0],
flag2Weight=self.flag2w + str(0))
b_in = self.Xavier_init_bias(in_size=self.indim, out_size=(self.hiddens)[0],
flag2Bias=self.flag2b + str(0))
W_list.append(w_in)
B_list.append(b_in)
for i_hiddens in range(n_hiddens-1):
w = self.Xavier_init_weight(in_size=(self.hiddens)[i_hiddens], out_size=(self.hiddens)[i_hiddens+1],
flag2Weight=self.flag2w + str(i_hiddens+1))
b = self.Xavier_init_bias(in_size=(self.hiddens)[i_hiddens], out_size=(self.hiddens)[i_hiddens+1],
flag2Bias=self.flag2b + str(i_hiddens+1))
W_list.append(w)
B_list.append(b)
w_out = self.Xavier_init_weight(in_size=(self.hiddens)[-1], out_size=self.outdim,
flag2Weight=self.flag2w + str(n_hiddens))
b_out = self.Xavier_init_bias(in_size=(self.hiddens)[-1], out_size=self.outdim,
flag2Bias=self.flag2b + str(n_hiddens))
W_list.append(w_out)
B_list.append(b_out)
return W_list, B_list
class Singlelayer(tf.keras.layers.Layer):
def __init__(self, weight2layer=None, bias2layer=None):
super(Singlelayer, self).__init__()
self.w = weight2layer
self.b = bias2layer
def call(self, inputs): # Defines the computation from inputs to outputs
return tf.matmul(inputs, self.w) + self.b
# ----------------------------------- Regular wights and biases -----------------------------------------------
def regular_weight_biases(regular_model='L1', weights=None, biases=None):
layers = len(weights)
if regular_model == 'L1':
regular_w = 0
regular_b = 0
for i_layer1 in range(layers):
regular_w = regular_w + tf.reduce_sum(tf.abs(weights[i_layer1]), keep_dims=False)
regular_b = regular_b + tf.reduce_sum(tf.abs(biases[i_layer1]), keep_dims=False)
elif regular_model == 'L2':
regular_w = 0
regular_b = 0
for i_layer1 in range(layers):
regular_w = regular_w + tf.reduce_sum(tf.square(weights[i_layer1]), keep_dims=False)
regular_b = regular_b + tf.reduce_sum(tf.square(biases[i_layer1]), keep_dims=False)
else:
regular_w = 0.0
regular_b = 0.0
return regular_w + regular_b
# ---deep neural network with resnet(one-step skip connection for two consecutive layers if have equal neurons）---
class DNN(tf.keras.layers.Layer):
def __init__(self, indim=1, outdim=1, hiddens=None, Ws=None, Bs=None, actName='tanh', actName2Out='linear'):
super(DNN, self).__init__()
self.outdim = outdim
self.indim = indim
self.hiddens = hiddens
self.Ws = Ws
self.Bs = Bs
self.actFunc = actName
self.actFunc2out = actName2Out
def call(self, x_input):
n_hiddens = len(self.hiddens)
# Win = (self.Ws)[0]
hiddenLayer = Singlelayer(weight2layer=(self.Ws)[0], bias2layer=(self.Bs)[0])
activation_in = my_actFunc(actName=self.actFunc)
out2hidden = hiddenLayer(x_input)
out2hidden = activation_in(out2hidden)
activation_hidden = my_actFunc(actName=self.actFunc)
hidden_record = self.hiddens[0]
for iLayer in range(n_hiddens-1):
# W = (self.Ws)[iLayer+1]
out_pre = out2hidden
hiddenLayer = Singlelayer(weight2layer=(self.Ws)[iLayer+1], bias2layer=(self.Bs)[iLayer+1])
out2hidden = hiddenLayer(out2hidden)
out2hidden = activation_hidden(out2hidden)
if self.hiddens[iLayer + 1] == hidden_record:
out2hidden = out2hidden + out_pre
hidden_record = self.hiddens[iLayer + 1]
# Wout = (self.Ws)[-1]
hiddenLayer = Singlelayer(weight2layer=(self.Ws)[-1], bias2layer=(self.Bs)[-1])
activation_out = my_actFunc(actName=self.actFunc2out)
out2hidden = hiddenLayer(out2hidden)
out_result = activation_out(out2hidden)
return out_result下面为如何使用这个模型。
if __name__ == "__main__":
input_dim = 2
out_dim = 1
hidden_layer = (5, 10, 10, 15, 20)
init_model = 'DNN'
name2base_model = 'DNN'
regular_wb_model = 'L1'
penalty2weight_biases = 0.01
actFun = 'tanh'
model = DNN_model(indim=input_dim, outdim=out_dim, hidden_list=hidden_layer,
init_opt2model=init_model, name2DNN_Model=name2base_model, opt2regular_WB=regular_wb_model,
penalty2WB=penalty2weight_biases, actName=actFun)
batch_size = 100
x = np.random.rand(batch_size, input_dim)
y = model(x)
print(y)第二种方式:序列化定义 Dense Net(缺点：每一层难操作)
当然，使用tf.keras,layers 一样可以构建网络。我们看一下:
# -*- coding: utf-8 -*-
"""
Created on 2021.06.16
@author: LXA
"""
import tensorflow as tf
import numpy as np
class my_actFunc(tf.keras.layers.Layer):
def __init__(self, actName='linear'):
super(my_actFunc, self).__init__()
self.actName = actName
def call(self, x_input):
if str.lower(self.actName) == 'relu':
out_x = tf.nn.relu(x_input)
elif str.lower(self.actName) == 'leaky_relu':
out_x = tf.nn.leaky_relu(x_input)
elif str.lower(self.actName) == 'tanh':
out_x = tf.nn.tanh(x_input)
elif str.lower(self.actName) == 'elu':
out_x = tf.nn.elu(x_input)
elif str.lower(self.actName) == 'sin':
out_x = tf.sin(x_input)
elif str.lower(self.actName) == 'sigmoid':
out_x = tf.nn.sigmoid(x_input)
else:
out_x = x_input
return out_x
class Dense_seqNet(tf.keras.Model):
"""
Args:
indim: the dimension for input data
outdim: the dimension for output
hidden_units: the number of units for hidden layer, a list or a tuple
name2Model: the name of using DNN type, DNN , ScaleDNN or FourierDNN
actName2in: the name of activation function for input layer
actName: the name of activation function for hidden layer
actName2out: the name of activation function for output layer
if name2Model is not wavelet NN, actName2in is not same as actName; otherwise, actName2in is same as actName
"""
def __init__(self, indim=1, outdim=1, hidden_units=None, name2Model='DNN', actName2in='linear', actName='tanh', actName2out='linear'):
super(Dense_seqNet, self).__init__()
self.indim = indim
self.outdim = outdim
self.hidden_units = hidden_units
self.num2NN_layers = len(hidden_units)+1
self.name2Model = name2Model
self.actFunc_in = my_actFunc(actName=actName2in)
self.actFunc = my_actFunc(actName=actName)
self.actFunc_out = my_actFunc(actName=actName2out)
self.dense_layers = []
for i_layer in range(len(hidden_list)):
dense_hidden = tf.keras.layers.Dense(hidden_list[i_layer])
self.dense_layers.append(dense_hidden)
def call(self, inputs, training=None, mask=None):
dense_in = self.dense_layers[0]
H = dense_in(inputs)
H = self.actFunc_in(H)
for i_layer in range(1, self.num2NN_layers-1):
dense_layer = self.dense_layers[i_layer]
H = dense_layer(H)
H = self.actFunc(H)
dense_out = self.dense_layers[-1]
H =dense_out(H)
H_out = self.actFunc_out(H)
return H_out使用:
if __name__ == "__main__":
input_dim = 2
out_dim = 1
hidden_layer = (5, 10, 10, 15, 20)
regular_wb_model = 'L1'
penalty2weight_biases = 0.01
actFun = 'tanh'
Model_name = 'DNN'
model = Dense_seqNet(indim=input_dim, outdim=out_dim, hidden_units=hidden_layer, name2Model=Model_name,
actName2in=actFun, actName=actFun)
var_List0 = model.trainable_variables # 无数据传入时，变量列表为空
batch_size = 10
x = np.random.rand(batch_size, input_dim)
y = model(x)
var_List1 = model.trainable_variables # 数据传入时，变量列表中才有变量
print(y)这里有一个问题，
var_List0 = model.trainable_variables是空的，也就是说model中没有可训练的变量。我还没有搞明白！！！
对于拟合问题，可以使用model.fit来训练网络，但是对于其他的不能使用MSE-loss的问题，这个就比较麻烦了。这里的关键是如何得到 trainable_variables！！！！
第三种方式:使用Keras的API 显式定义 Dense Net(这种策略好)
下面看第三种方式。显式地定义每一层的权重和偏置。然后逐层迭代计算
# -*- coding: utf-8 -*-
"""
Created on 2021.06.16
@author: LXA
"""
import tensorflow as tf
import numpy as np
class my_actFunc(tf.keras.layers.Layer):
def __init__(self, actName='linear'):
super(my_actFunc, self).__init__()
self.actName = actName
def call(self, x_input):
if str.lower(self.actName) == 'relu':
out_x = tf.nn.relu(x_input)
elif str.lower(self.actName) == 'leaky_relu':
out_x = tf.nn.leaky_relu(x_input)
elif str.lower(self.actName) == 'tanh':
out_x = tf.nn.tanh(x_input)
elif str.lower(self.actName) == 'elu':
out_x = tf.nn.elu(x_input)
elif str.lower(self.actName) == 'sin':
out_x = tf.sin(x_input)
elif str.lower(self.actName) == 'sigmoid':
out_x = tf.nn.sigmoid(x_input)
else:
out_x = x_input
return out_x
class Dense_Net(tf.keras.Model):
"""
Args:
indim: the dimension for input data
outdim: the dimension for output
hidden_units: the number of units for hidden layer, a list or a tuple
name2Model: the name of using DNN type, DNN , ScaleDNN or FourierDNN
actName: the name of activation function for hidden layer
actName2out: the name of activation function for output layer
scope2W: the namespace for weight
scope2B: the namespace for bias
repeat_high_freq: repeating the high-frequency component of scale-transformation factor or not
"""
def __init__(self, indim=1, outdim=1, hidden_units=None, name2Model='DNN', actName='tanh', actName2out='linear',
scope2W='Weight', scope2B='Bias', repeat_high_freq=True):
super(Dense_Net, self).__init__()
self.indim = indim
self.outdim = outdim
self.hidden_units = hidden_units
self.name2Model = name2Model
self.actName = actName
self.actName2out = actName2out
self.actFunc = my_actFunc(actName=actName)
self.actFunc_out = my_actFunc(actName=actName2out)
self.repeat_high_freq = repeat_high_freq
self.Ws = []
self.Bs = []
Win = self.add_weight(shape=(indim, hidden_units[0]), initializer=tf.keras.initializers.GlorotNormal,
trainable=True, name=str(scope2W)+'_in')
Bin = self.add_weight(shape=(hidden_units[0],), initializer=tf.keras.initializers.GlorotNormal, trainable=True,
name=str(scope2B)+'_in')
self.Ws.append(Win)
self.Bs.append(Bin)
for i_layer in range(len(hidden_units)-1):
W = self.add_weight(shape=(hidden_units[i_layer], hidden_units[i_layer + 1]),
initializer=tf.keras.initializers.GlorotNormal,
trainable=True, name=str(scope2W) + str(i_layer))
B = self.add_weight(shape=(hidden_units[i_layer + 1],),
initializer=tf.keras.initializers.GlorotNormal,
trainable=True, name=str(scope2B) + str(i_layer))
self.Ws.append(W)
self.Bs.append(B)
Wout = self.add_weight(shape=(hidden_units[-1], outdim), initializer=tf.keras.initializers.GlorotNormal,
trainable=True, name=str(scope2W) + '_out')
Bout = self.add_weight(shape=(outdim,), initializer=tf.keras.initializers.GlorotNormal, trainable=True,
name=str(scope2B) + '_out')
self.Ws.append(Wout)
self.Bs.append(Bout)
def get_regular_sum2WB(self, regular_model):
layers = len(self.hidden_units)+1
if regular_model == 'L1':
regular_w = 0
regular_b = 0
for i_layer in range(layers):
regular_w = regular_w + tf.reduce_sum(tf.abs(self.Ws[i_layer]), keep_dims=False)
regular_b = regular_b + tf.reduce_sum(tf.abs(self.Bs[i_layer]), keep_dims=False)
elif regular_model == 'L2':
regular_w = 0
regular_b = 0
for i_layer in range(layers):
regular_w = regular_w + tf.reduce_sum(tf.square(self.Ws[i_layer]), keep_dims=False)
regular_b = regular_b + tf.reduce_sum(tf.square(self.Bs[i_layer]), keep_dims=False)
else:
regular_w = tf.constant(0.0)
regular_b = tf.constant(0.0)
return regular_w + regular_b
def call(self, inputs, training=None, mask=None):
# ------ dealing with the input data ---------------
H = tf.add(tf.matmul(inputs, self.Ws[0]), self.Bs[0])
H = self.actFunc(H)
# ---resnet(one-step skip connection for two consecutive layers if have equal neurons）---
hidden_record = self.hidden_units[0]
for i_layer in range(len(self.hidden_units)-1):
H_pre = H
H = tf.add(tf.matmul(H, self.Ws[i_layer+1]), self.Bs[i_layer+1])
H = self.actFunc(H)
if self.hidden_units[i_layer + 1] == hidden_record:
H = H + H_pre
hidden_record = self.hidden_units[i_layer + 1]
H = tf.add(tf.matmul(H, self.Ws[-1]), self.Bs[-1])
out_result = self.actFunc_out(H)
return out_resultif __name__ == "__main__":
input_dim = 3
out_dim = 1
hidden_layer = (5, 10, 10, 15, 20)
name2base_model = 'DNN'
actFun = 'tanh'
model = DNN_base.Dense_Net(indim=input_dim, outdim=out_dim, hidden_units=hidden_layer, name2Model=name2base_model,
actName=actFun)
var_List0 = model.trainable_variables # 不为空
batch_size = 10
x = np.random.rand(batch_size, input_dim)
freq = [1, 2, 3, 4, 5, 6, 7, 8]
y = model(x, scale=freq)
print(y)说明
以上代码为本人的工作，只是抽取了一些简单的模块作为展示，因此函数中的一些参变量是多余的，可自行删除。刚从tensorflow1转为TensorFlow2，本人水平还比较弱，代码难免有错误和考虑不全面的地方，欢迎指正。
注：以上代码所需要的环境及配置方法：Anaconda,python,Numpy,Tensorflow2等配置
最后
以上就是酷酷鲜花为你收集整理的tensorflow 2.X 自动构建任意层的深度神经网络(DNN)一些参考博客：tensorflow2.0 和tensorflow1.0的区别第一种方式：为自定义各种模块第二种方式:序列化定义 Dense Net(缺点：每一层难操作)第三种方式:使用Keras的API 显式定义 Dense Net(这种策略好)说明的全部内容，希望文章能够帮你解决tensorflow 2.X 自动构建任意层的深度神经网络(DNN)一些参考博客：tensorflow2.0 和tensorflow1.0的区别第一种方式：为自定义各种模块第二种方式:序列化定义 Dense Net(缺点：每一层难操作)第三种方式:使用Keras的API 显式定义 Dense Net(这种策略好)说明所遇到的程序开发问题。
如果觉得靠谱客网站的内容还不错，欢迎将靠谱客网站推荐给程序员好友。
本图文内容来源于网友提供，作为学习参考使用，或来自网络收集整理，版权属于原作者所有。
发表评论 取消回复
