Extension DLLs for 礦ision2
Last update:04.11.2004
These DLLs are for the 8051 simulation part only.
The following DLLs are available:
How to install the extension DLLs
The DLLs work only with 礦ision2 V2.30 or higher versions.
1. Copy the DLLs in the subdirectory keilc51bin.
2. Open the file TOOLS.ini in subdirectory keil and include the following part in the section [C51]:
AGSI1=SCOPE.DLL ("Scope simulation")
AGSI2=LCD.DLL ("LCD simulation")
AGSI2=LED.DLL ("LED simulation")
AGSI3=I2C.DLL ("I2C simulation")
AGSI4=Statemachine.dll ("8051 statemachine")
AGSI5=Signalgenerator.dll ("Signal generator")
AGSI6=Timemeasure.dll ("Timemeasure")
AGSI7=TCPIP.dll ("TCPIP connection")
!!!!If 礦ision2 is open during the procedure you have to restart it.
How the extension DLLs work
After starting the simulation you will find the following new entries in the folder Peripherals:
Scope
LCD
LED
I2C-Simul
8051 statemachine
Signal generator
Scope
 | ||||||
| category | filename | date | short text | Downl. | Ques | Counter |
| Buecher | scope.zip | 2002-10-12 | Scope V0.21 DLL for 礦ision2 (>=V2.20a) |  |  | 7019 |
Examples
| ||||||
| category | filename | date | short text | Downl. | Ques | Counter |
| ||||||
| Software | Scope_Example1.zip | 2002-10-12 | Scope Examples Nr.1 This example includes a port measurement (P1). | | | 4176 |
 Software | inc_c51b.ZIP | 2002-10-12 | H-Files for the libraries and general definitions. (For book C51 part 1, checked with 礦ision2 V2.10) | | | 9255 |
| ||||||
| ||||||
| Software | Scope_Example2.zip | 2002-10-12 | Scope Examples Nr 2 This example includes a timer measurement. You can analyse Port1, Pin0 using the function ti/T. | | | 3100 |
| Software | inc_c51b.ZIP | 2002-10-12 | H-Files for the libraries and general definitions. (For book C51 part 1, checked with 礦ision2 V2.10) | | | 9255 |
| ||||||
| ||||||
| Software | Scope_Example3.zip | 2002-10-12 | Scope Examples Nr 3 Includes an example for a timer measurement (T0) and a trigger sequence (TF0). | | | 2833 |
| Software | inc_c51b.ZIP | 2002-10-12 | H-Files for the libraries and general definitions. (For book C51 part 1, checked with 礦ision2 V2.10) | | | 9255 |
|
LCD simulation(HD44780)
| ||||||
| category | filename | date | short text | Downl. | Ques | Counter |
| Buecher | lcd.zip | 2003-12-13 | LCD V0.2 DLL for 礦ision2 (>=V2.20a) | | | 14751 |
Examples
| ||||||
| category | filename | date | short text | Downl. | Ques | Counter |
| Software | Lcd_demo.zip | 2002-10-12 | LCD Examples Example for the LCD simulation (4-bit mode). | | | 10613 |
I2C simulation (7bit address)
The following restictions are included in this DLL :
-
You can only use one device from each derivate.
-
If you make a reset in the simulator the I睠 simulation will not work correctly anymore.
Both problems are caused by the Keil AGSI interface.
Simulation DLL:
| ||||||
| category | filename | date | short text | Downl. | Ques | Counter |
| Buecher | i2c.ZIP | 2003-01-06 | I睠-Bus V0.15 DLL for 礦ision2 (>=V2.30) | | | 9521 |
The following devices are supported:
| ||||||
| category | filename | date | short text | Downl. | Ques | Counter |
| I睠 | DS1621.zip | 2002-11-03 | DS1621 Digital Thermometer and Thermostat | | | 3533 |
| I睠 | LM75_docu.ZIP | 2002-11-01 | LM75 Digital Temperature Sensor (I睠-Bus) and Thermal watchdog with Two-Wire Interface | | | 2862 |
| I睠 | lm75a.ZIP | 2002-11-01 | LM75A Digital temperature sensor and termal Watchdog |  | | 3572 |
| I睠 | PCA8581_C.zip | 2002-11-01 | PCF8581 128 Byte EEPROM | | | 1690 |
| I睠 | PCF8570_PCF8571.ZIP | 2002-11-01 | PCF8570 256 x 8-bit static low-voltage RAM | | | 1458 |
| I睠 | PCF8574.ZIP | 2002-11-01 | PCF8574 Remote 8-bit I/O expander | | | 2255 |
| I睠 | PCF8575.ZIP | 2002-11-01 | PCF8575 Remote 16-bit I/O expander | | | 1724 |
| I睠 | PCF8583.ZIP | 2002-11-03 | PCF8583 Clock/calendar with 240 x 8-bit RAM | | | 3291 |
| I睠 | PCF8591_5.zip | 2002-11-01 | PCF8591 8-bit A/D and D/A converter with I睠 bus interface. | | | 2021 |
| I睠 | M24C01_16.ZIP | 2002-11-01 | M24C01 - M24C16 1-16K bit Serial I睠 Bus EEPROM | | | 3747 |
| I睠 | M24C32.ZIP | 2002-11-01 | 32 kBit Serial I睠 Bus EEPROM | | | 2600 |
If you need another I睠 device please send me an email.
Examples
| ||||||
| category | filename | date | short text | Downl. | Ques | Counter |
| Software | I2C_Timing.zip | 2002-10-12 | I睠-Bus Examples Example 1 includes a timing check for SDA and SCL | | | 4084 |
| ||||||
| Software | PCF8583_V7.ZIP | 2002-11-03 | Example for the PCF8583 with time/date, timer/alarm timer and event counter mode | | | 3269 |
| Software | Chip_Inc.zip | 2002-11-03 | | | 6152 | |
| Software | I2C_Lib.zip | 2002-11-03 | Basic functions for the I睠 control. You will find a complete description in the book C51 Teil2. !! This book is only in german available. !!! | | | 9647 |
|
Signal generator
| ||||||
| category | filename | date | short text | Downl. | Ques | Counter |
| Buecher | SignalGenerator.zip | 2003-05-11 | Signal generator V0.11 DLL for 礦ision2 (>=V2.20a) | | | 4992 |
Examples
| ||||||
| category | filename | date | short text | Downl. | Ques | Counter |
| ||||||
| Software | 517AD_Example_V7.zip | 2002-10-12 | Signal Generator Examples Example 1 Evaluation of 80C517 A/D converter. | | | 2458 |
| Software | Inc_C51b_T2.zip | 2002-10-12 | H-Files for libraries and definitions from Book 2 (C51 part 2) | | | 8388 |
| ||||||
| ||||||
| Software | Encoder_Example_V7.zip | 2002-10-12 | Signal Generator Examples Example 2 Evaluation of a 90?Digital Contacting Encoder. | | | 2196 |
| Software | Inc_C51b_T2.zip | 2002-10-12 | H-Files for libraries and definitions from Book 2 (C51 part 2) | | | 8388 |
| ||||||
| ||||||
| Software | hyst_Example_V7.zip | 2002-10-12 | Signal Generator Examples Example 3 Evaluation of the characteristic hysteresis curve. | | | 1865 |
| Software | Inc_C51b_T2.zip | 2002-10-12 | H-Files for libraries and definitions from Book 2 (C51 part 2) | | | 8388 |
|
LED simulation
| ||||||
| category | filename | date | short text | Downl. | Ques | Counter |
| Buecher | led.ZIP | 2002-10-12 | LED simulation V0.11 Single and multi collored LEDs and 7-Segment displays will be supported. A connection to SFR, Memory and virtual registers can be made. If a byte address is used the LED is on, if content of byte address is != 0. | | | 7511 |
Examples
| ||||||
| category | filename | date | short text | Downl. | Ques | Counter |
| Software | Traffic_Example.ZIP | 2002-10-12 | LED Examples Example 1 For project Traffic.uv2 (KeilExamples) a LED example is available. For a brief instruction see attached Readme.txt. | | | 4533 |
8051 statemachine
| ||||||
| category | filename | date | short text | Downl. | Ques | Counter |
| Buecher | 8051Statemachine.ZIP | 2003-01-12 | 8051 state machine V 0.11 The statemachine.dll simulates a "12 cycle core". It can show the internal 8051 instruction. Connect to 礦ision2 (>=V2.30 or C51 >=V7.0). | | | 5680 |
Time Measurement
| ||||||
| category | filename | date | short text | Downl. | Ques | Counter |
| Buecher | TimeMeasure.zip | 2003-05-11 | Time Measurement V0.10 DLL for 礦ision2 (>=V2.20a) | | | 4067 |
TCP/IP connection
This is a restricted version. You can only send 50 commands via TCP/IP.
Full-Version: 25 Euro. Order with email.
| ||||||
| category | filename | date | short text | Downl. | Ques | Counter |
| ||||||
| Buecher | tcpip.zip | 2004-04-11 | TCP/IP V0.10 Connection for the 礦ision simulator (CD >= 11.03) | | | 2810 |
| Buecher | TCPIP_Doc.zip | 2004-04-11 | Documentation for the TCP/IP connection with the 礦ision simulation (V0.1) only in German available. | | | 4111 |
|
